Dirt Devil DD2503 Manuale utente

CYCLONE

VACUUM CLEANER 800W

220-240V~50/60HZ

ITEM: 871125247530

A.I.&E. Adriaan Mulderweg 9-11

5657 EM Eindhoven, The Netherlands

DD2503

YEAR

GUARANTEE

7,5M

2,2L

4,3KG

78dB

Points de collecte sur www.quefairedemesdechets.fr

Cet appareil,

ses accessoires,

piles et cordons

se recyclent

À DÉPOSER

EN MAGASIN À DÉPOSER

EN DÉCHÈTERIE

FRFR

INSTRUCTION MANUAL

2.2 LITER

aINSTRUCTION MANUAL

BAGLESS SINGLE CYCLONE

VACUUM CLEANER

ITEM NO: 871125247530

MODEL: V8221

IMPORTANT SAFETY INSTRUCTIONS

This appliance should only be used for domestic cleaning and not for

commercial or industrial use. Please ensure that this guide is fully

understood before

operating the appliance.

WARNING: DANGER TO THE PERSON!

IMPORTANT: Damage to the appliance! In addition we offer the

following safety advice.

LOCATION

• Do not use or keep this product outside when it is raining.

• Do not store the appliance near hot ovens or heating appliances.

• Store your vacuum cleaner in a cool, dry area. If lters have been

cleaned as per user guide instructions ensure they are thoroughly dry

before storing away.

MAINS LEAD

• Do not allow the mains lead to become strained or run this

appliance over it.

• If the electrical cable becomes damaged, the complete cable

assembly must be replaced. Do not attempt this task yourself.

Contact the local retailers.

• Agency service: To ensure the continued safe and efcient

operation of this appliance we recommend that any servicing

or repairs are

only carried out by an authorized Agency service

engineer.

CHILDREN

• This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved.

• Children shall not play with the appliance

• This appliance can be used by children aged from 8 years and above.

Scan QR-Code for

extended manual

PERSONAL SAFETY

• The plug must be removed from the wall socket before cleaning or

maintaining the appliance.

• Never modify the cleaner in any way.

• Never use in the presence of explosive liquids or vapors.

• Never pick up inammable or poisonous liquids such as petrol,

copier toner or other volatile substances. Never pick up acids,

asbestos or asbestos dust.

• Repairs to electrical appliances are only to be undertaken by

trained personnel.

• Unprofessional repairs can be dangerous for users.

• The appliance must never be left running when unsupervised.

PRODUCT SAFETY

• Never use the appliance without the lters being installed.

• Never use the appliance to vacuum hot ashes, broken glass, sharp

objects or liquids.

• To protect against re, electric shock and personal injury do not

immerse cord, plug or cleaner in water or other liquid.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety.

• Cleaning and user maintenance shall not be made by children

without supervision

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied persons in

order to avoid a hazard.

• Always switch off the vacuum cleaner before

disconnecting or connecting the hose and accessories.

• Keep all openings clear and free from debris as this may

affect the airow/suction.

• Do not use the appliance to clean animals or people.

ELECTRICAL REQUIREMENTS

• Check that the voltage on the rating plate corresponds with your

house electricity supply which must be A.C (alternating current).

PRODUCT DESCRIPTION

FEATURES

1. Dirt container lid 7. Dirt container release button

2. Dirt container 8. Carry handle

3. Separator and shroud 9. Parking slot

4. Post-motor lter cover 10. Cord rewind button

5. Hose entry point 11. On/Off button

6. Post-motor lter (hidden)

HOW TO INSTALL / OPERATE THE MACHINE

Before you start

• Always switch off and unplug the vacuum cleaner before

connecting or disconnecting the hose/attachments, or removing

and emptying the dirt container.

• The vacuum cleaner is equipped with a thermal cut-out. If for

any reason the vacuum cleaner does overheat the thermostat

will automatically turn the vacuum cleaner off. If this happens,

switch the vacuum cleaner off and unplug from electrical

socket. Remove and empty the dirt container and also check

the vacuum cleaner for blockages. Allow the vacuum cleaner

to cool for approximately 1 hour (if you have cleaned the lters

please wait 24 hours for the lters to fully dry before putting

back into the machine).

• Clean the pre-motor lter every time the dirt container is

emptied and replace the lters every 12 months.

• If the vacuum cleaner is blocked, switch off and unplug before

removing the blockage.

• When using the accessories always make sure the brush bar is

switched to the off position.

ASSEMBLING YOUR MACHINE

1. Press both buttons at the end of hose and insert into hose entry

point.

2. Insert hose grip into telescopic extension tube.

3. Press button on telescopic extension tube and adjust to required

length.

4. Insert the other end of the telescopic tube into the oorhead.

USING YOUR ACCESSORIES

5. Push the accessory onto the telescopic

extension tube or hose end.

HOW TO USE

IMPORTANT: The base of the vacuum cleaner should always be

positioned at on the oor when starting and in use. The dirt

container should be locked into place before lifting the vacuum

cleaner by the carry handle.

IMPORTANT: The power cord must always be completely

unwound, do not pull further than the yellow marker.

Hard oors

Carpets

6. Unwind the power cord. Do not pull further than the yellow marker.

7. Plug into mains and press the On/Off button to switch the machine

on.

8. For use on carpets, click rocker switch forward. For use on hard

oors click rocker switch back.

9. Raise brushed for carpets.

10.Lower brushes for hard oors.

11. Slide vent cover on hose grip open to reduce suction if required.

Note: Brushes on the oorhead should be visible when using on

hard oors.

EMPTYING AND CLEANING THE DIRT CONTAINER

IMPORTANT: Unplug and switch off vacuum cleaner before

performing maintenance or troubleshooting checks.

12.Press dirt container release button. Lift to remove dirt

container from machine.

13.Hold dirt container over the bin. Press release clip at the

bottom of the container, the dirt release door will open allowing

dirt/debris to fallout.

Note: Don’t over ll the dirt container to avoid blocking

the air ow through the vacuum cleaner.

CLEANING THE PRE-MOTOR FILTER

Note: Clean the pre-motor lter every time the dirt container

is emptied and replace the lters every 12 months.

14.Turn the dirt container lid anti-clockwise to remove.

15.Lift to remove the pre-motor lter out of dirt container.

16.Tap the lter against a bin to remove excess debris.

17.Wash pre-motor lter under running water (4

0°C Max)

18.Leave to dry for 14 hours or until fully dry before placing back

in the machine.

CLEANING THE SEPARATOR

19.Turn the dirt container lid anti-clockwise to remove.

20.Lift to remove the pre-motor lter out of dirt container.

21.Using central grips lift to remove separator from dirt container.

22.Twist grips clockwise and remove cap from separator.

23.Tap the separator against a bin to remove any dirt of debris.

Note: For any stubborn dirt / debris remaining in the

separator, use a soft brush to remove.

REFITTING THE SEPARATOR

IMPORTANT: Incorrect tting of the separator will reduce

suction.

24.Replace the separator cap, twist clockwise to lock.

25.Replace separator into dirt container, make sure the rectangular

hole in the dirt container lines up with the rectangular hole on the

separator.

POST-MOTOR FILTER MAINTENANCE

IMPORTANT: The exhaust lter is designed to offer long life with

no maintenance. The lter should be checked periodically and

when heavily discolored it should be replaced. Please do not

wash, scrub or brush the lter as this will damage the delicate

lter media.

26.Turn the post-motor lter cover anti-clockwise to remove.

27.Pull to remove post-motor lter.

28.Check the post-motor lter for discoloration.

29.Push post-motor lter into wheel and re-t.

30.Line up the lter cover tabs with the wheel and turn clockwise. The

lter cover will be locked into place when the center trim is in the

horizontal position.

PET ODOR FILTER MAINTENANCE

IMPORTANT: Do not wash, scrub or brush the ped odor lter as

this will damage it. Replace lters at least every 6-9 months.

31.Turn the post-motor lter cover anti-clockwise to remove.

32.Pull to remove post-motor lter to gain access to the pet odor lter.

33.Tap the pet odor lter against a bin to remove any dirt or debris.

STORE YOUR VACUUM CLEANER

CAUTION: Make sure to hold the cord with your other hand to

prevent injury when re-winding.

34.Unplug from the mains and hold the rewind button into the vacuum

cleaner.

35.Place oorhead into parking slot located at the back of the vacuum

cleaner for storage and carrying.

REMOVING BLOCKAGES FROM THE HOSE

36.Remove the hose from the vacuum cleaner and telescopic

extension tube. Remove any blockage by inserting a wire

coat hanger into the hose.

NOTE: To test for a blockage in the hose, drop a small ball

of paper into the hose. The paper will drop through if the

hose is clear.
