Dive Rite BC1063 Manuale utente

Dive Rite

Basic Harness

Item # BC1063

This harness utilizes nylon webbing

for strength and comfort.

It also features tubular webbing

sleeves to minimize wear wherever

the harness would normally be in

contact with a metal backplate.

Packaging contains:

1) 11 ft of 2” harness webbing,

with stainless-steel grommet

2) 2 tubular sleeves (4” each)

3) 2 tubular sleeves (5" each)

4) 4 Stainless-steel Belt Slides

5) 2 Stainless-steel D-rings

6) 2 Stainless-steel bent D-rings

7) 1 Stainless-steel waist-strap

release buckle

This Dive Rite Harness fits on

all Dive Rite backplates.

Great for technical diving,

where simplicity is

the key!

* * Crotch Strap not included * *

175 NW Washington Street

Lake City, FL 32055 USA

www.diverite.com

v1.0

Threading Basic Harness

Shoulder Strap Routing

www.diverite.com

v1.0

1) Begin by threading 2 tubular sleeves onto the harness

webbing. These will end up where the harness goes through

the upper shoulder strap slots, as shown in figure A.

2) Thread the harness webbing through the upper shoulder

strap slots (figure A), positioning the webbing so the grommet

is over the upper tank bolt hole on the plate.

3) Thread the remaining 2 tubular sleeves onto the harness

webbing, ending up where the harness goes through the

waist slots, as shown in figure C.

4) Install one 2” belt-slide and one 2” bend D-ring on each

side of the webbing, as shown in figure B.

5) Then thread one tail of the webbing though the waist slot

(back through the inner slot, then forward through the outer

slot). Repeat this step for the opposite tail (see figure C).

6) Again install one 2” belt-slide and one 2” D-ring on each

side of the webbing, as shown in figure B.

7) Locate and install crotch strap. Refer to Figure D.

8) Using same side as the crotch strap loop, install waist

strap release buckle using slots on buckle.

TOP

BACK

STEP



STEP

FRONT

Waist Strap

Routing
