DivineTribe Ceramic Donut v3 Manuale utente

I want to use it now!

The atomizer works best with slow low draw hits. The donut takes a

couple seconds from cold to make vapor. Let off the fire button a few

seconds

before

you stop drawing. This helps keep the air holes open by

cooling any reclaim left in the atomizer. Load small bb size or –

smaller ON the donut. sually three to five 10 15s hits on that bb. –

DO NOT load a lot of material at once it will just leak out the air –

holes and into the base. DO NOT suck like a vacuum cleaner you'll –

just get splatter all over the cap. Now to setup your mod.

My mod has TCR mode –Stellar!

●10mm donut TCR 240 20-24 watts

●13mm donut TCR 475 30-35 watts

The above settings should allow the temperature on the screen to be

pretty close to the donut. For the best results using TC, lock your

atomizer resistance at room temperature. Don't be afraid to tweak

these settings higher TCR number will make the donut hotter than –

the screen number and a lower TCR number will make the donut temp

lower than screen number.

My mod does TC but not TCR –Your best bet here is to use Ni

mode at 20-30 watts and a temperature limit somewhat lower than

the desired donut temperature. The ideal TCR number for the donut

is between 230 and 500 while the TCR number for Ni is around

600. A temperature between 280-360 should yield donut temps

between 360 and 420. Lock your atomizer resistance when cold.

My mod doesn't do temp control (TC) At least 12-16watts are –

needed to make enough heat to vaporize oil, but getting to 400F will

take 5 seconds or so. 20-30 watts heats the donut faster but you

M ST pulse the fire button to keep from blowing the donut. If you

are using a mod in wattage mod only, you probably already know this.

Advanced TC configuration (ArcticFox Firmware)

For those with an eLeaf, Joyetech or Wismec mod and are pretty

handy with computers. A windows computer or windows virtual machine

is required to run the NFE toolbox which provides for configuring and

loading the ArcticFox firmware (AFF) onto your mod. Also provided is

a device monitor for real time monitoring of the mod in use. AFF

allows a profile based configuration with intelligent switching of up to 8

atomizers. AFF also has support for PI regulator temperature control

and fully customizable screen output. All configurations can be

performed on the mod or via the NFE Toolbox interface. If all of this

still makes sense and sounds like a good idea proceed, you won't look –

back.

The process of reflashing the firmware is very simple. Instructions can

be found at the NFE Team Forum. Make sure to use the required

version of the NFE Tools that go with the version of AFF you are

Plug your mod into the SB port on your computer and launch

Ntoolbox.exe. se 'Firmware pdater” to reflash your mod. Choose the

AFF .bin file you downloaded.

Now you can configure profiles using “ArcticFox Configuration”. Start

with the same TCR configuration to the left. Then click the “setup”

button next to temp control and enable PI-Regulator. The percentage

value is when the PI-Regulator kicks in a zero value means it's –

enabled from start to finish while a number indicates percent of

desired temperature. I leave 0% and set P=950 and I=10. Testing

with an IR thermometer with emissivity set to 0.65 shows my donut

temp tracks within 10F of the displayed temperature. I create one

profile for 10mm donuts and one for 13mm donuts. I also like to

increase the puff cutoff time to 15 seconds on the “Advanced” tab.

Divine Tribe v3 Ceramic Donut Atomizer Quick Start Guide

sage and cleaning notes:

●There is a “break-in” period for a new/clean donut - load

slightly

more during this time (first 5-10 loads)

●There is a “sweet spot” where new loads and reclaim are balanced using cool down hits can extend this time. Finish each session with a full –

unpowered

cool down hit. Holding your mod upside down after a hit will let the reclaim drop down on the bottom of the donut for vaping. Holding

the atomizer at a

slight

angle and rotating in a circle while hitting it will help the hot oil touch the bottom of the donut and vaporize.

●Once past the “sweet spot” the excess reclaim must be removed. I use a tightly rolled up paper towel for this. Roll the paper towel like a

cigarette (flat end) and insert into the atomizer. Hold it upside down and fire it to heat the reclaim. You can assist this process by blowing

through one air intake while covering the other. Rotate the paper towel to clean the walls too. Finally, re-roll the paper towel with a pointed end

and work the center and sides of the donut soaking up most of the reclaim. This will extend the time between break down cleanings.

●Eventually a full break-down cleaning will be required as the donut will have some buildup and taste will be affected. New donut/cups are cheap

and you can save time by just q-tipping the base and replacing the donut and cup, but you can also clean donuts and cups to original condition

and use them for 6 months or longer.

●Matt has an excellent video on cleaning using your mod - https://www.youtube.com/watch?v=P6RuAjzqY_A

●I clean with isopropyl alcohol (ISO) and a torch. First note the cold resistance of your atomizer it should not change with this procedure. –

Remove the outer cover from the base by removing the three screws and wipe down the mouthpiece and base cover. Carefully separate the

donut and cup by removing the two post screws. Straighten the leads with a needle nose pliers and carefully slide the donut out of the cup.

This takes some finesse because reclaim will lock the leads in the holes. Put the cup back in the ISO and

gently

grab the donut leads with a

locking pliers and use a torch to burn the crust off the donut. Move the torch frequently and do not cherry the donut the goal is just to burn –

off any buildup. While the donut cools, torch the cup until clean. When all parts are cool, reassemble the atomizer and check that the cold

resistance has not changed. Treat yourself to a nice dab on a clean donut.

●A little bit of coconut oil makes a great lubricant for the mouthpiece o-rings.

Divine Tribe v3 Ceramic Donut Atomizer Quick Start Guide
