Dixell XR06CX Temperature Control Manual

833-734-8880

service@ironmountainrefrigeration.com

Thank you for your freezer purchase. Your digital temperature controller should arrive pre-set to factory

standards. This manual is provided to assist with any small changes you may wish to make. If you are

experiencing any issues with the function of your cooler, we are available for support at

service@ironmountainrefrigeration.com or by phone at 833-734-8880.

Your freezer is designed to maintain a temperature range with a high and low setting. When the high

temperature is reached, the compressor will start and run until the low temperature is reached. Setting

the high and low too close may cause ice build up and compressor failure.

To see your set temperature, press and release “SET”. To change it, hold “SET” until Fis flashing and use

up or down to adjust. This temperature must be within the selected temperature range in the

parameters. To check or adjust the parameters, follow the steps below.

1. Hold “Set” and “Down”together for 3 seconds until F is flashing. Release. Hold “Set” and

“Down” again for 10 seconds until “L2” is shown.

2. You are now in the parameter menu. The first parameter, “Hy”is shown.

a. Press “Set”to see the current setting.

b. Use Up and Down arrows to change, if needed.

c. Press “Set” to show next parameter.

3. To exit and save changes, press “Set” and “Up” together.

Iron Mountain Refrigeration & Equipment, LLC

Dixell XR06CX Temperature Control Manual

833-734-8880

service@ironmountainrefrigeration.com

Temperature Setting Codes

We recommend a differential of 5-6 degrees, -4/-5 as a low temperature and 1 as a high temperature.

To change this, you will need to change BOTH the differential and the temperature settings.

Parameter Code

Setting

Recommended

Temperature differential

Low Temperature

- 5

High Temperature

Defrost Settings

Defrosting is pre-set to occur at regular 4 to 6-hour intervals for 25 minutes. There is a 2-minute delay

after defrosting to allow the water to drip into the evaporation tray before the compressor and fan will

start again. To manually start a defrost cycle, press the “defrost” button for 3 seconds. This will also

cancel a defrost in progress. To change the defrost settings, follow the steps to enter the parameters as

shown above.

Parameter Code

Setting

Pre-Set

Defrost Interval

4 hours

Maximum Defrost Time

25 min

Drip Delay after Defrost

2 min

Fan Delay after Defrost

10 min

Defrost Display

Def
