dji RC Pro Manuale utente
Quick Start Guide
v1.0
DJI RC Pro
Disclaimer
Carefully read this entire document and all safe and lawful practices provided by DJITM before using
this product for the first time. Failure to read and follow instructions and warnings may result in
serious injury to yourself or others, damage to your DJI product, or damage to other objects in the
vicinity. By using this product, you hereby signify that you have read this document carefully and that
you understand and agree to abide by all terms and conditions of this document and all relevant
documents of this product. You agree that you are solely responsible for your own conduct while
using this product and for any consequences thereof. DJI accepts no liability for damage, injury, or
any legal responsibility incurred directly or indirectly from the use of this product.
DJI is a trademark of SZ DJI TECHNOLOGY CO., LTD. (abbreviated as “DJI”) and its affiliated
companies. Names of products, brands, etc., appearing in this document are trademarks or
registered trademarks of their respective owner companies. This product and document are
copyrighted by DJI with all rights reserved. No part of this product or document shall be reproduced
in any form without the prior written consent or authorization of DJI.
This document and all other collateral documents are subject to change at the sole discretion of DJI.
This content is subject to change without prior notice. For up to date product information, visit the
product page for this product at http://www.dji.com.
This document is available in various languages. In the event of divergence among dierent versions,
the English version shall prevail.
Introduction
The DJI RC Pro remote controller features O3+, the latest version of DJI’s signature OCUSYNCTM
image transmission technology, and can transmit a live HD view from the camera of an aircraft [1] at
a distance of up to 15 km[2]. Users can connect to the internet via Wi-Fi and the Android operating
system comes with a variety of functions such as Bluetooth and GNSS.
The built-in 5.5-in high brightness 1000 cd/m2screen boasts a resolution of 1920×1080 pixels
while the remote controller comes with a wide range of aircraft and gimbal controls as well as
customizable buttons and has a maximum operating time of 3 hours[3].
[1] Refer to the Specications for more information on supported aircraft.
[2] The DJI RC Pro can reach its maximum transmission distance (FCC) in a wide open area with no electromagnetic interference using a
DJI MAVICTM 3 at an altitude of approximately 120 meters.
[3] The maximum operating time was tested in a lab environment and is for reference only.
Important
Stay alert when using the remote controller to control an Unmanned Aerial Vehicle (UAV).
Carelessness may result in serious harm to yourself and others. Download and read the user
manuals for the aircraft and remote controller before using for the rst time.
1. Fully charge the remote controller before each ight.
2. The remote controller will sound an alert if it is powered on but has not been used for five
minutes. It will automatically power o after a further 30 seconds. Move the control sticks or
perform any other remote controller action to cancel the alert.
3. Make sure the antennas of the remote controller are unfolded and adjusted to the proper position
for optimal transmission.
4. Contact DJI Support to repair or replace the antennas if they are damaged. Damaged antennas
greatly decrease performance.
5. Link the remote controller and the aircraft every time the aircraft is changed.
6. Make sure to power o the aircraft before the remote controller.
7. Fully charge the remote controller every three months.
8. Charge the remote controller immediately if the power level reaches 0%. Otherwise, the remote
controller may be damaged due to being over discharged for an extended period. Discharge the
remote controller to between 40% and 60% if stored for an extended period.
9. DO NOT cover the air vent or the air intake on the remote controller. Otherwise, the performance
of the remote controller may be aected due to overheating.
10. Contact DJI or a DJI authorized dealer to replace the components of the remote controller if
damaged. DO NOT disassemble the remote controller without the assistance of a DJI authorized
dealer.
1. Antennas
2. Back Button/Function Button
3. Control Sticks
4. RTH Button
5. Flight Pause Button
6. Flight Mode Switch
7. 5D Button
8. Power Button
9. Conrm Button/Customizable C3 Button
10. Touchscreen
11. microSD Card Slot
12. USB-C Port
13. Mini HDMI Port
1
234
5
10
11 12 13
67
89
Overview
20
24 22
23
25
21
14. Gimbal Dial
15. Record Button
16. Status LED
17. Battery Level LEDs
18. Focus/Shutter Button
19. Camera Settings Dial
20. Air Vent
21. Control Sticks Storage Slots [1]
22. Customizable C1 Button
23. Speaker
24. Customizable C2 Button
25. Air Intake
[1] A pair of control sticks are stored in the control sticks storage slot
before delivery. The control sticks have already been mounted to the
remote controller in the illustration in the Overview section.
14 19
18
16 17
15
1. Charging and Checking Battery Level
• It is recommended to use an FCC/CE certied USB charger rated 12 or 15V.
• Recharge the battery at least every three months to prevent over discharging. The battery
depletes when stored for an extended period.
Check battery level: press power button.
Power on/o: press, then press and hold.
Low HighBattery
The built-in battery is placed in hibernation
mode before delivery. It must be charged before
using for the rst time.
It takes approximately two hours to fully charge
the remote controller using a recommended
USB charger rated 12V and one and a half hours
using a recommended USB charger rated 15V.
USB
Charger
USB-C Cable
Power Outlet
100~240 V
2. Preparing the Remote Controller
The optimal transmission range is where the antennas are facing
toward the aircraft and the angle between the antennas and the
back of the remote controller is 180° or 270°.
The illustrations show situations where the operator and aircraft
are far away.
• Make sure the control sticks are rmly
mounted.
• A prompt will be received in DJI Fly if the
transmission signal is weak during ight.
Adjust the antennas to make sure that the
aircraft is in the optimal transmission range.
Attach the control sticks
and twist to secure
Unfold the antennas
Remove the control
sticks from the
storage slots
Check the internet connection if activation fails. Try to activate the remote controller again if
the internet connection is normal. Contact DJI if activation fails several times.
3. Activating the Remote Controller
Internet
The remote controller needs to be activated before using for the rst time. An internet
connection is required for activation.
Power on the remote
controller
Select the language Follow the prompts
to activate
Hello
Next
Welcome
Start
Hello
Next
Welcome
Start
Hello
Next
Welcome
Start
4. Linking
The remote controller is already linked to the aircraft when it is purchased together as part of
a combo. Otherwise, follow the steps below to link the remote controller and the aircraft after
activation.
1. Power on the remote controller and the aircraft.
2. Press the customizable C1 button, customizable C2 button, and the record button
simultaneously. The status LED will blink blue and the remote controller will beep twice to
indicate linking has started.
3. Press the linking button of the aircraft. The status LED of the remote controller will turn solid
green if linking is successful.
Refer to the DJI RC Pro User Manual for more information about linking.
To download the user manual, visit https://www.dji.com/rc-pro
