DOCKMATE®
RED
WIRELESS REMOTE CONTROL
DOCKING SYSTEM
USER MANUAL
1
Congratulations on your purchase of a Dockmate® RED TWIN or Dockmate® RED SINGLE system.
Please read the following instructions carefully before getting started.
Dockmate is a wireless remote-control system that enables you to manoeuver your ship from any
place aboard. With a Dockmate® RED TWIN or Dockmate® RED SINGLE, you can control the
engine(s), horn, 1 anchor/windlass, a bow- and stern thruster with your fingertips.
IMPORTANT: Read the precautions before first use!
2
1. What’s in the box? ....................................................................................................................................................... 4
2. Precautions ................................................................................................................................................................... 5
3. Installation ..................................................................................................................................................................... 9
4. Using Dockmate TWIN or SINGLE ........................................................................................................................ 12
5. Charging the batteries ............................................................................................................................................ 16
6. Turning the remote on and off ............................................................................................................................. 18
7. Error codes .................................................................................................................................................................. 19
8. LED behavior during operation ............................................................................................................................ 21
9. Maintenance .............................................................................................................................................................. 33
10. Troubleshooting......................................................................................................................................................... 23
11. Technical specifications .......................................................................................................................................... 25
3
Remote .................................................................................................................................................................................. 25
Receiver ................................................................................................................................................................................ 26
FCC Warning ....................................................................................................................................................................... 28
12. Environmental Information ................................................................................................................................... 30
13. Warranty .......................................................................................................................................................................31
14. Dockmate is compliant with the following standards .................................................................................. 33
15. Declaration of Conformity ..................................................................................................................................... 35
4
- This user manual
- Installation manual
- The Dockmate® RED Receiver
- The Dockmate® RED TWIN or Dockmate® RED SINGLE remote
- Dockmate wireless charging pad
- Lanyard
- All necessary wiring cut to length
- Antenna
5
To avoid damage to your Dockmate® RED and hurting yourself or others, you should read the
following safety precautions before using the device. Keep these safety instructions in an area
where all users can read them.
When in doubt, contact PPA-Electronics regarding the use or operation of the unit.
PPA-Electronics is not responsible for injuries or damage caused as a result of improper use or
installation by a non-qualified technician.
2.1. Before taking command with Dockmate make sure that all levers controlling the engines
and thrusters are in neutral position.
2.2. Whether using the Dockmate wireless charging pad or another Qi certified charger, do not
put the Dockmate® RED remote that is switched on onto the wireless charger . Always
switch it off first, before charging. It is highly recommended to use a wireless charger
supplied by Dockmate.
6
2.3. Do not store or place the remote for prolonged periods of time in direct sunlight (i.e. on the
dashboard); temperatures can easily rise to 65°C+ or 150°F+.
The Dockmate devices must be kept at an acceptable temperature.
The operating temperature range for the remote is 0°C to +43°C or +32°F to +110°F
The operation temperature range for the Receiver is -10°C to +60°C or +14°F to +140°F
2.4. Do not disassemble the Dockmate® RED remote or Receiver.
Touching the internal parts may lead to injuries. Repairs may only be performed by
trained technicians.
2.5. Do not use near flammable gases or liquids.
This may cause an explosion or fire.
2.6. Keep out of reach of children.
The devices contain small parts which can be swallowed by children. Beware for
suffocation by plastic packaging.
2.7. The Dockmate may only be used by persons who have the necessary skills to manoeuver a
yacht.
2.8. Be careful with the lanyard.
Keep it away from small children (choking hazard).
7
2.9. Do not use the Dockmate when the remote or Receiver have been immersed in water. The
units may be damaged beyond repair. Test both devices with the boat in a safe
environment before use.
Contact your Dockmate dealer when any abnormality is detected.
2.10. Make sure you can operate the Dockmate like an expert before actually using it in a
crowded harbour.
2.11. In very exceptional circumstances, the communication between the remote and Receiver
can be disturbed by radio frequency remotes in the immediate neighborhood.
2.12. Never use the Dockmate if you are not on the ship. Remember that the use of the
Dockmate from ashore or the jetty is a criminal offense in several countries.
2.13. Batteries should be charged as soon as the stat LED on the remote lights up yellow.
2.14. Please note that when the system is in operation each involuntary push on the buttons of
the remote has an action as a result.
2.15. It’s a good habit to briefly test your Dockmate when you first turn it on, before untying your
ropes, lifting the anchor, or heading into the marina or port. Just like it’s a good habit to test
your boat’s engine and thruster controls (and other systems) before heading out on the
water.
8
2.16. If you detect or experience any abnormal behaviour of your Dockmate system, do not use
it. First verify if all the controls on your fixed station(s) work correctly and then contact your
Dockmate dealer for support.
2.17. The remote, Receiver and any other Dockmate device may only be opened by an
authorised technician. Opening of a Dockmate device by an unauthorised person will void
the warranty.
