A Harman International Company

ECHO FX

ANALOG DELAY

WHAT THE FX96 DOES

The FX96 Echo Fx is DOD’s latest addition to its arsenal

of great delay effects. The FX96 is an Analog Delay

pedal that offers tape delay simulation at your feet. No

longer will you have to haul (and handle with care) the

bulky Echo tape machines of the past to the gig .And if

the “worn-out tape” characteristics of the old Echo

machines is the sound your looking for, the FX 96 gives a

Tape Quality control for changing the tonal quality of the

tape emulation.

CONNECTING THE FX96

Connect your guitar to the input of the FX96. Connect

the OUTPUT of the FX96 to your amp (or to the input of

another effects device). To eliminate the need for a 9-volt

battery, attach the DOD PS200R to the AC adapter jack.

The PS200R is a regulated supply that will not allow hum

into the pedal.

FEATURES

LED indicator shows status of effect and battery condition

Active switching for noiseless operation

Easy access battery compartment

Adapter jack for AC operation

Rugged die-cast metal case

Three year limited warranty

Rubber non-skid bottom

CONTROLS

MIX (DRY/TAPE) The MIX (DRY/TAPE) knob controls the

mix level between the Dry and Effect level of the FX 96

Echo Fx. Turning the knob all of the way down, produces

all dry signal. Turning it all of the way up, produces a

100% wet effect.

DELAY TIME: The DELAY TIME knob controls the delay

time of the FX 96 Echo Fx. Turning the knob all of the way

up produces up to approximatley 800 milliseconds of delay

time.

REGEN/REPEAT: The REGEN/REPEAT knob controls

the amount of delay regeneration that is fed into the signal

of the FX 96. By turning the knob all of the way up, this will

produce more delay repeats. By turning down the

REGEN/REPEAT control down, this will produce less

repeats,

TAPE QUALITY: The TAPE QUALITY knob controls the

Low Pass Filter which is use to re-create analog tape

quality variances of the past. The higher the TAPE

QUALITY knob is turned up, the more “grainy” and Muddy

the tape quality becomes.

FOOTSWITCH: Switches the Echo effect in or out of the

signal path.

LED INDICATOR: Lights when the Echo is enabled, and

is not lit when the Echo is bypassed.

JACKS: Input, Output, AC Adapter (use the DOD PS200R

power supply only to eliminate the need for a 9 volt

battery).

OPERATION OF THE FX96

The FX96 can be operated in front of an amplifier or in an

effects loop. Since the order of the effects is very important,

they should be ordered as follows: 1) compression effects

(DOD FX84), 2) Wah/volume and envelope filters (DOD

FX17, FX25), 3) Distortion effects or preamps (DOD

FX102, FX69B), 4) EQ’s (DOD FX40), 5) chorus, flanging,

phasing, vibrato (DOD FX75C), 6) Delay and reverb effects

(DOD DFX98, FX 96).

To set up your own sound with the FX96, set all controls at

12 o’clock. Then adjust the DELAY TIME and

REGEN/REPEAT controls for the desired Delay time and

Delay repeats. Next, adjust the MIX (DRY/TAPE) control

for the desired amount of effect. Finally, dial in the quality

of the Tape delay by adjusting the TAPE QUALITY knob

control.

On the following pages, some examples of different types of

sounds are described, along with graphic representations of

how to set the knobs. Since good (or bad) guitar sounds are

a subjective matter, use these examples as starting points to

create your own sounds that meet your specific tastes, or

lack thereof.

SLAP BACK DELAY

Use this setting when you you require a good old fashioned

slap back delay. This is an ideal setting for country guitar. It

gives a nice and short delay time (approximatley 100

milliseconds), and enough repeat to make that Tele sing.

GRAINY TAPE ECHO

If you are longing for the unique sounds of an analog tape

machine, this setting is for you. Utilizing the tape quality

control, can give you an accurate emulation the old grain

quality sound of echo tape when it becomes good and worn.

The Echo setting will provide you with just enough delay time

to make the delay sound out like and old tape machine.

LONG DELAY

To add depth and dimension to your playing, try this set-up

to to provide big delay that layers your sound with a longer

delay time and more repeats.

IMPORTANT NOTES

• The FX96 battery is in use whenever the INPUT jack is

plugged in. If you are not using the FX96, be sure to unplug

the cable from the INPUT jack. This will prevent

unnecessary battery drain.

• Remove the battery whenever the unit is not going to be

used for an extended period of time. This will prevent

possible damage due to leaking battery fluids.

• If the FX96 fails to switch in or out or the LED indicator

stays lit, the battery needs to be replaced.

• Use of any AC adapter other than the DOD PS200R will

void the warranty of this product.

• Unauthorized repair of the FX96 will void the warranty.

Should your FX96 require service, contact your DOD FX

pedal dealer for return / repair information.

DOD Warranty

1. The warranty registration card must be mailed within ten

days after purchase date to validate this warranty.

2. DOD warrants this product, when used solely within the

U.S., to be free from defects in materials and workmanship

under normal use and service.

3. DOD liability under this warranty is limited to repairing or

replacing defective materials that show evidence of defect,

provided the product is returned through the original dealer,

where all parts and labor will be covered up to a period of

three years. The company shall not be liable for any

consequential damage as a result of the product’s use in

any circuit or assembly.

4. Proof-of-purchase is considered to be the burden of the

consumer.

5. DOD reserves the right to make changes in design or

make additions to or improvements upon this product

without incurring any obligation to install the same on

products previously manufactured.

DECLARATION OF CONFORMITY

Manufacturer’s Name: DOD Electronics Corporation

Manufacturer’sAddress: 8760 S. Sandy Parkway

Sandy, Utah 84070, USA

declares that the product

Product Name: FX96

Product Options: All (requires a Class II power

adapter that conforms to the requirements of EN 60065,

EN 60742, or equivalent).

Safety: EN 60065 (1993)

IEC65 (1985) with Amendments 1,2,3

EMC: EN 55013: (1990)

EN 55020: (1991)

Supplementary Information:

The product herewith complies with the requirements of

the Low Voltage Directive 73/23/EEC and the EMC

Directive 89/336/EEC as amended by directive

93/68/EEC.

DOD Electronics Corporation

President of DOD

8760 S. Sandy Parkway

Sandy, Utah 84070, USA

Effective: August 26, 1997

European Contact: Your Local DOD Sales and

Service Office or

International Sales Office

3 Overlook Drive #4

Amherst, New Hampshire 03031, USA

Tel (603) 672-4244

Fax (603) 672-4246

DOD Electronics Corporation

8760 South Sandy Parkway

Sandy, Utah 84070

Telephone (801) 566-8800

FAX (801) 566-7005

International Distribution

3 Overlook Drive Unit 4

Amherst, New Hampshire 03031

U.S.A.

FAX (603) 672-4246

Printed 2/98

FX96 18-2138-B
