1/ DODGE CALIBER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

CALIBER

2011 Dodge Caliber

SPECIFICATIONS

Dimensions are in inches (millimeters) at curb weight with standard wheels and tires unless otherwise noted.

GENERAL INFORMATION

Body Style

Five-door compact car

Assembly Plant

Belvidere Assembly Plant, Belvidere, Illinois

EPA Vehicle Class

Compact car

Introduction Date

January 2006, as 2007 model

ENGINE: 2.0-LITER DOHC 16-VALVE I-4 WITH DUAL VVT

Availability

Standard on Caliber Express, Mainstreet, Uptown and Heat

Type and Description

Four cylinders inline, tuned intake manifold with electronic Active Charge Motion

Control valves, dual counter-rotating balance shafts

Displacement

121.9 cu. in. (1998 cu cm)

Bore x Stroke

3.39 x 3.39 (86 x 86)

Valve System

Chain-driven DOHC, 16 valves, electronically controlled dual VVT, direct-acting

shimless mechanical bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die-cast aluminum block with dry iron liners, cast-aluminum

cylinder head, cast-aluminum ladder frame, forged steel crankshaft

Compression Ratio

10.5:1

Power (SAE net, estimated)

158 bhp (118 kW) @ 6,400 rpm (79 bhp/liter)

Torque (SAE net, estimated)

141 lb.-ft. (191 N•m) @ 5,000 rpm

Max. Engine Speed

6,750 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2

Oil Capacity

5.0 qt. (4.7L) SAE 5W/20

Coolant Capacity

7.2 qt. (6.8L)

Emission Controls

Single catalytic converter, dual heated oxygen sensors and engine features

Smog-forming Pollution

0.9 g/mile (0.56 g/km)(a)

Max. Gross Trailer Weight

1,000 lbs. (450 kg) std., 1,500 lbs. (680 kg) with Security Group

Estimated EPA Fuel Economy mpg

(City/Hwy)

23/32 (est.)—FWD with five-speed manual transaxle

23/27—FWD CVT

(a) NMOG + NOx emission limits under ULEV II and Tier 2, Bin 5 emission requirements.

2/ DODGE CALIBER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

CALIBER

ENGINE: 2.4-LITER DOHC 16-VALVE I-4 WITH DUAL VVT

Availability

Standard on Caliber Rush, Optional on Caliber Uptown

Type and Description

Four cylinders inline, tuned intake manifold with electronic Active Charge Motion

Control valves dual counter-rotating balance shafts

Displacement

144 cu. in. (2360 cu cm)

Bore x Stroke

3.46 x 3.82 (88 x 97)

Valve System

Chain-driven DOHC, 16 valves, electronically controlled dual VVT, direct-acting

shimless mechanical bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die-cast aluminum block with dry iron liners, cast-aluminum

cylinder head, cast-aluminum ladder frame, forged steel crankshaft

Compression Ratio

10.5:1

Power (SAE net, estimated)

172 bhp (128 kW) @ 6,000 rpm (72 bhp/liter)

Torque (SAE net, estimated)

165 lb.-ft. (224 N•m) @ 4,400 rpm

Max. Engine Speed

6,500 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2

Oil Capacity

5.0 qt. (4.7L) SAE 5W/20

Coolant Capacity

7.2 qt. (6.8L)

Emission Controls

Single catalytic converter

Dual heated oxygen sensors and engine features

Smog-forming Pollution

0.9 g/mile (0.56 g/km)(a)

Max. Gross Trailer Weight

1,000 lbs. (450 kg)/2,000 lbs. (900 kg) with Security Group

Estimated EPA Fuel Economy mpg

(City/Hwy)

23/29—with five-speed manual transaxle

21/25—with CVT2

(a) NMOG + NOx emission limits under ULEV II and Tier 2, Bin 5 emission requirements.

TRANSAXLE: MANUAL, MAGNA DRIVELINE T355 5-SPEED

Availability

Standard on Caliber Express, Heat and Rush

Description

Five-speed, overdrive, synchronized in all forward ratios, cable-operated, three-

plane shifter

Gear Ratios

1st

3.77

2nd

2.16

3rd

1.41

4th

1.026

5th

0.81 (0.72 for 2.4L)

Reverse

3.417

Final-drive Ratio

4.12

Overall top gear

3.34

3/ DODGE CALIBER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

CALIBER

TRANSAXLE: AUTOMATIC, CVT2

Availability

Standard on Caliber Mainstreet and Uptown; Available on Caliber Heat and Rush

Description

Continuously variable ratio, lockup torque converter, electronic controls

Gear Ratios

Forward

2.349:1 to 0.394:1 continuously variable

Reverse

1.762:1

Final-drive Ratio

6.12:1

Overall Top-gear Ratio

2.41:1

DRIVETRAIN

Front-wheel Drive

Availability

Standard

ELECTRICAL SYSTEM

Alternator

120-amp

Battery

525 CCA, maintenance-free

DIMENSIONS AND CAPACITIES(a)

Wheelbase

103.7 (2635)

Track, Front

59.8 (1520)

Track, Rear

59.8 (1520)

Overall Length

173.8 (4414)

Overall Width

68.8 (1747)

Overall Height

60.4 (1533)

Ground Clearance

7.67 (195)

Frontal Area, sq. ft. (sq m)

24.7 (2.29)

Drag Coefficient

0.375

Aero (CdA)

9.3

Curb Weight, lb. (kg)—Est.

Express 2,940 (1334)

Mainstreet 3,012 (1366)

Uptown 3,012 (1366)

Heat 3,012 (1366)

Rush 3,104 (1408)

Weight Distribution, percent F/R

58/42

Fuel Tank Capacity, gal. (L)

13.6 (51.5)

(a) All dimensions measured at curb weight with standard tires

4/ DODGE CALIBER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

CALIBER

ACCOMMODATIONS

Seating Capacity, F/R

2/3

Front

Head Room without Sunroof

39.8 (1012)

Legroom

41.8 (1062)

Shoulder Room

55.4 (1408)

Hip Room

52.2 (1325)

Seat Travel

Driver—10.2 (260), passenger—10.2 (260)

Recliner Angle Range

Driver—up to 88°, passenger—(76° fold flat/88° non-fold flat)

SAE Front Volume Index, cu. ft. (cu m)

53.3 (1.510)

Rear

Head Room

38.9 (988)

Legroom

35.7 (906)

Knee Clearance

0.7 (18.6)

Shoulder Room

53.4 (1356)

Hip Room

49.6 (1261)

SAE Rear Seat Volume Index,

cu. ft. (cu m)

42.9 (1.2)

SAE Interior Volume, cu. ft. (cu m)

96.2 (2.7)

Cargo Volume Indexes

Rear Seats Up, cu. ft. (cu m)

18.4 (0.5)

Rear Seats Folded, cu. ft. (cu m)

47.4 (1.3)

EPA Interior Volume Index, cu. ft. (cu m)

114.6 (3.2)

Trunk lift-over height

27.7 (703)

BODY

Layout

Transverse front-engine front-wheel drive

Construction

Unitized steel body

SUSPENSION

Front

Independent MacPherson strut, coil spring over gas-charged shock absorbers

and stabilizer bar—standard

Rear

Multi-link independent with coil springs, link-type stabilizer bar,

gas-charged shock absorbers—standard

STEERING

Type

Rack and pinion with hydraulic power assist

Overall Ratio

16.6:1

Turning Diameter (curb-to-curb)

17-in. wheels and tires—35.6 ft. (10.8 m)

18-in. wheels and tires—37.2 ft. (11.3 m)

Steering Turns (lock-to-lock)

15- or 17-in. wheels and tires—2.88

18-in. wheels and tires—2.76

5/ DODGE CALIBER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

CALIBER

TIRES

Availability

Standard on Caliber Express

Size and Type

P205/70R15 All-season

Mfr. and Model

Dunlop SP50

Revs per Mile (km)

801 (497)

Availability

Standard on Caliber Mainstreet and Uptown; Optional on Caliber Express

Size and Type

P215/60R17 BSW All-season Touring

Mfr. and Model

Firestone Affinity S3

Revs per Mile (km)

760 (472)

Availability

Standard on Caliber Heat and Rush

Size and Type

P215/55R18 All-season Performance

Mfr. and Model

Firestone Firehawk GTA 03

Revs per Mile (km)

765 (476)

WHEELS

Availability

Standard on Caliber Express

Type and Material

Stamped steel with five-spoke wheel covers

Size

15 in. x 6.0 in.

Availability

Standard on Caliber Mainstreet and Uptown; Optional on Caliber Express

Type and Material

Painted aluminum

Size

17 in. x 6.5 in.

Availability

Standard on Caliber Heat

Type and Material

Polished Aluminum

Size

18 in. x 7.0 in.

Availability

Optional on Caliber Rush

Type and Material

Chrome-clad aluminum

Size

18 in. x 7.0 in.

6/ DODGE CALIBER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

CALIBER

BRAKES

Availability

Standard on Caliber Express and Mainstreet

Front

Size and Type

11.5 x 1.0 (294 x 26) vented disc with 2.2 (57) single-piston floating caliper

Swept Area

223 sq. in. (1442 sq cm)

Rear

Size and Type

9.0 x 0.85 (229 x 35) drum

Swept Area

78 sq. in. (503 sq cm)

Power-assist Type

10 (254) single-vacuum diaphragm

Four-wheel anti-lock brake system (ABS)

Standard

Availability

Standard on Caliber Uptown, Heat and Rush; Optional on Caliber Mainstreet

(with Driver Convenience Group)

Front

Size and Type

11.5 x 1.0 (294 x 26) vented disc with 2.2 (57) single-piston floating caliper

Swept Area

223 sq. in. (1442 sq cm)

Rear

Size and Type

10.3 x 1.39 (262 x 10) solid disc with 1.4 (35) single-piston floating caliper

Swept Area

138 sq. in. (894 sq cm)

Power-assist Type

10 (254) single-diaphragm vacuum

Four-wheel anti-lock brake system (ABS)

Standard

Electronic stability control (ESC)

Standard on Caliber Uptown, Heat and Rush; Optional on Caliber Mainstreet

(with Driver Convenience Group)

Hill-start Assist (HSA)

Standard with manual transmission and ESC

(a) Note: Per axle
