2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

All-new 2011 Dodge Charger

SPECIFICATIONS

Dimensions are in inches (millimeters) unless otherwise noted.

GENERAL INFORMATION

Body Style

E-segment Sedan

Assembly Plant

Brampton Assembly Plant, Ontario, Canada

EPA Vehicle Class

Large car

Introduction Date

December 2010 as 2011 model

ENGINE: 3.6-LITER PENTASTAR DOHC 24-VALVE V-6

Availability

Standard—Dodge Charger SE (RWD)

Type and Description

60-degree V-type, liquid-cooled

Displacement

220 cu. in. (3604 cu. cm)

Bore x Stroke

3.78 x 3.27 in. (96.0 x 83.0 mm)

Valve System

Chain-driven DOHC, 24 valves, hydraulic end-pivot roller rockers

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

Aluminum deep-skirt block with aluminum-alloy heads

Compression Ratio

10.2:1

Power (SAE net)

292 bhp (218 kW) @ 6,350 rpm (81.1 bhp/L)

Torque (SAE net)

260 lb.-ft. (353 N•m) @ 4,800 rpm

Max. Engine Speed

6,400 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2; and E-85 (Federal Bin 5, 37 state

compliant)

Oil Capacity

6 qt. (5.7L) with dry filter

Coolant Capacity

14.0 qt. (13.25L)

Emission Controls

Dual three-way catalytic converters, heated oxygen sensors

and internal engine features(a)

Max. Gross Trailer Weight

1,000 lbs. (454 kg)

EPA Fuel Economy mpg (City/Hwy)

18/27

Engine Assembly Plant

Trenton South Engine Plant, Trenton, MI

(a) Meets Federal Tier 2 Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York, Maine, Vermont,

Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington.

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

ENGINE: 5.7-LITER HEMI®V-8 WITH FOUR-CYLINDER MODE FUEL SAVER TECHNOLOGY

Availability

Standard—Dodge Charger R/T (RWD/AWD)

Type and Description

90-degree V-type, liquid-cooled with variable cam timing (VCT)

Displacement

345 cu. in. (5654 cu. cm)

Bore x Stroke

3.92 x 3.58 (99.5 x 90.9)

Valve System

Pushrod-operated overhead valves, 16 valves, eight deactivating and eight

conventional hydraulic lifters, all with roller followers

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

Deep-skirt cast-iron block with cross-bolted main bearing caps, aluminum alloy

heads with hemispherical combustion chambers

Compression Ratio

10.5:1

Power (SAE net)

370 bhp (276 kW) @ 5,250 rpm (64.9 bhp/L)— R/T

Torque (SAE net)

395 lb.-ft. (536 N•m) @ 4,200 rpm—R/T

Max. Engine Speed

5,800 rpm (electronically limited)

Fuel Requirement

Unleaded midgrade, 89 octane (R+M)/2—Recommended

Unleaded regular, 87 octane (R+M)/2—Acceptable

Oil Capacity

7 qt. (6.6L)

Coolant Capacity

14.7 qt. (13.9L)

Emission Controls

Dual close-coupled three-way catalytic converters,

quad heated oxygen sensors and internal engine features(b)

Max. Gross Trailer Weight

1,000 lbs. (454 kg)

EPA Fuel Economy mpg (City/Hwy)

16/25 – RWD

15/23 – AWD

(b) Meets Tier 2 Bin 4 emission requirements in all states.

TRANSMISSION: AUTOMATIC FIVE-SPEED OVERDRIVE WITH AUTO STICK

Availability

Standard on Charger SE (RWD) and Charger R/T (RWD/AWD) models

Description

Adaptive electronic control or Auto Stick driver-interactive manual control and

electronically modulated torque converter clutch

Gear Ratios

1st

3.59

2nd

2.19

3rd

1.41

4th

1.00

5th

0.83

Reverse

3.16

Final Drive Ratio

SE (RWD)—2.65

R/T (RWD)—2.65

R/T (R/T Road & Track package)—3.06

R/T (AWD)—3.06

Overall Top Gear

SE (RWD)—2.20

R/T (RWD)—2.20

R/T (R/T Road & Track package)—2.54

R/T (AWD)—2.54

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

TRANSFER CASE

Availability

Standard on Dodge Charger R/T AWD

Type

Active, fully variable with front-axle disconnect

Center Differential

Planetary

Torque Split, Front/Rear

Fully variable

ELECTRICAL SYSTEM

Alternator

160-amp—standard all

Battery

H7 Case, 730 CCA, maintenance-free

DIMENSIONS AND CAPACITIES(D)

Wheelbase

120.2 (3052)

Track, Front

63.4 (1611)

Track, Rear

63.8 (1620)

Overall Length

199.9 (5077)

Overall Width

75.0 (1905)

Overall Height

58.4 (1482)

Ground Clearance

SE (RWD) — 5.0 (126.5)

R/T (RWD) —5.1 (128.3)

R/T (AWD) — 4.9 (125.1)

Frontal Area, sq. ft. (sq. m)

26.2 (2.43)

Drag Coefficient (Cd)

0.297

Curb Weight, lb. (kg)

SE (RWD)—3,961 (1796.7)

R/T (RWD)—4,253 (1929.2)

R/T (AWD)—4,450 (2018.5)

Weight Distribution, percent F/R

SE (RWD)—52/48

R/T (RWD)—53/47

R/T (AWD)—55/45

Fuel Tank Capacity, gal. (L)

SE (RWD)—19.1 (72.2)

R/T (RWD)—19.1 (72.2)

R/T (AWD)—19.1 (72.2)

(d) All dimensions measured at curb weight with standard tires.

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

ACCOMMODATIONS

Seating Capacity, F/R

2/3

Front

Head room

38.6 (981)

36.9 (938.4) with sunroof

Legroom

41.8 (1061)

Shoulder room

59.5 (1510)

Hip room

56.2 (1428)

Seat travel

Driver—10.6 (270)

Passenger—8.66 (220)

Recliner angle range, deg.

Power —70.7

Manual—70

EPA front row interior volume,

cu. ft. (cu. m)

55.6 (1.573)

Rear Seat

Head room

36.6 (930.6)

36.6 (930.6) with sunroof

Legroom

40.1 (1019)

Knee clearance

3.9 (99)

Shoulder room

57.9 (1472)

Hip room

56.1 (1425)

EPA second row interior volume,

cu. ft. (cu. m)

49.2 (1.393)

Total Interior Volume, cu. ft. (cu. m)

104.7 (2.97)

EPA Luggage Compartment Volume, cu.

ft. (cu. m)

15.4 (0.437)

EPA Interior Volume Index, cu. ft. (cu. m)

120.1 (3.40)

Trunk Liftover Height

30.1 (764.0)

BODY

Layout

Longitudinal front engine, RWD

Construction

Unitized steel body and aluminum hood

SUSPENSION

Front

Independent SLA with high upper “A” arm, coil spring over gas-charged

monotube shock absorbers and stabilizer bar—standard on Charger SE and R/T

Lateral and diagonal lower links with dual ball joint knuckles—standard on

Charger SE and R/T

One piece lower-control arms—standard on Charger R/T AWD only

High-performance shock absorbers and larger sway bar—included with Super

Track Pak

Rear

Five-link independent with coil springs, gas-charged monotube shock absorbers,

stabilizer bar and isolated suspension cradle—standard on Charger SE and R/T

High-performance shock absorbers and larger sway bar—included with Super

Track Pak

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

STEERING

Type

Rack and pinion with hydraulic power assist

Overall Ratio

SE (RWD)—14.4:1

R/T (RWD)—14.4:1

R/T (AWD)—16.5:1

Turning Diameter (curb-to-curb)

SE (RWD)—37.7 ft. (11.5 m)

R/T (RWD)—37.7 ft. (11.5 m)

R/T (RWD with Super Track Pak)—37.7 ft. (11.5 m)

R/T (AWD)—38.7 ft. (11.8 m)

Steering Turns (lock-to-lock)

SE (RWD)—2.6

R/T (RWD)—2.6

R/T (RWD with Super Track Pak)—2.6

R/T (AWD)—3.1

Performance Steering Gear

Standard with Super Track Pak

TIRES

Availability

Standard on Charger SE (RWD)

Size and type

P215/65R17 BSW all-season touring

Mfr. and model

Michelin Energy Saver

Revs per mile (km)

748 (465)

Availability

Standard on Charger R/T (RWD) and optional on Charger SE

Size and type

P235/55R18 BSW all-season performance

Mfr. and model

Michelin MXM4

Revs per mile (km)

734 (457)

Availability

Standard on Charger R/T (AWD)

Size and type

P235/55R19 BSW all-season performance

Mfr. and model

Michelin MXM4

Revs per mile (km)

710 (446)

Availability

Optional on Charger SE (RWD) and Charger R/T (RWD)

Size and type

P245/45R20 BSW all-season performance

Mfr. and model

Firestone Firehawk GTV

Revs per mile (km)

725 (451)

Availability

Included with Super Track Pak on Charger R/T Road & Track (RWD)

Size and type

P245/45R20 BSW three-season high-performance

Mfr. and model

Goodyear Eagle F1

Revs per mile (km)

725 (451)

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

WHEELS

Availability

Standard on Charger SE (RWD)

Type and material

Five-spoke design, cast aluminum, fully painted

Size

17 x 7.0

Availability

Optional on Charger SE

Type and material

Six-spoke design, cast aluminum, painted and polished

Size

18 x 7.5

Availability

Standard on Charger R/T (RWD), Optional on Charger SE

Type and material

Five-spoke design, cast aluminum, chrome clad

Size

18 x 7.5

Availability

Standard on Charger R/T AWD

Type and material

Five-spoke design, cast aluminum, painted and polished

Size

19 x 7.5

Availability

Optional on Charger SE (RWD) and Charger R/T (RWD)

Type and material

Five-spoke design, cast aluminum, chrome clad

Size

20 x 8.0

BRAKES

Touring Brake Package

Standard on Charger SE (RWD)

Front

Rotor size and type

12.6 x 1.1 (320 x 28) vented

Caliper size and type

2.36 (60) single-piston sliding with aluminum housing

Swept area

259 sq. in. (1671 sq. cm)

Rear

Rotor size and type

12.6 x 0.4 (320 x 10) solid

Caliper size and type

1.65 (42) single-piston sliding with aluminum housing

Swept area

264 sq. in. (1703 sq. cm)

Performance Brake Package

Standard on Charger R/T (RWD)

Front

Rotor size and type

13.6 x 1.26 (345 x 28) vented

Caliper size and type

1.65 (42) dual-piston sliding with aluminum housing

Swept area

249 sq. in. (1606 sq. cm)

Rear

Rotor size and type

12.6 x 0.87 (320 x 22) vented

Caliper size and type

1.65 (42) single-piston sliding with aluminum housing

Swept area

264 sq. in. (1703 sq. cm)

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

AWD Touring Brake Package

Standard on Charger R/T (AWD)

Front

Rotor size and type

13.6 x 1.0 (345 x 28) vented

Caliper size and type

1.65 (42) dual-piston sliding with aluminum housing

Swept area

249 sq. in. (1606 sq. cm)

Rear

Rotor size and type

12.6 x 0.87 (320 x 22) vented

Caliper size and type

1.65 (42) single-piston sliding with aluminum housing

Swept area

264 sq. in. (1703 sq. cm)

SUSPENSION

Touring-tuned Suspension

Standard on Charger SE (RWD)

Front

Stabilizer bar

27 mm, solid

Shock type/rate

Monotube with 172 lb./in.

Rear

Stabilizer bar

16 mm, solid

Shock type/rate

Monotube with 430 lb./in.

AWD Touring-tuned Suspension

Standard on Charger R/T (AWD)

Front

Stabilizer bar

32 mm, solid

Shock type/rate

Monotube with 340 lb./in.

Rear

Stabilizer bar

16 mm, solid

Shock type/rate

Monotube with 600 lb./in.

Performance-tuned Suspension

Standard on Charger R/T (RWD), available on Charger SE (RWD) with 20-inch

wheels

Front

Stabilizer bar

27 mm, solid

Shock type/rate

Monotube with 340 lb./in.

Rear

Stabilizer bar

16 mm, solid

Shock type/rate

Monotube with 670 lb./in.

Super Track Pak Suspension

Optional on Charger R/T (RWD) Road & Track

Front

Stabilizer bar

30 mm, solid

Shock type/rate

Monotube with 340 lb./in.

2011 Product Information

http://media.chrysler.com

SPECIFICATIONS

CHARGER

Rear

Stabilizer bar

20 mm, solid

Shock type/rate

Monotube with 670 lb./in.

•••

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Dodge Automobile

Dodge

Dodge 2008 LX49 Magnum Manuale utente

Dodge

Dodge 2013 Dart Manuale utente

Dodge

Dodge Charger Police 2020 Guida alla configurazione

Dodge

Dodge journey 2013 Manuale utente

Dodge

Dodge 2012 Challenger Manuale utente

Dodge

Dodge 2014 dodge challenger Manuale del proprietario

Dodge

Dodge Ram Truck 2010 Manuale utente

Dodge

Dodge 2014 urango Manuale utente

Dodge

Dodge avenger 2013 Manuale utente

Dodge

Dodge 2006 Sprinter Manuale utente

Dodge

Dodge Durango 012 Manuale utente

Dodge

Dodge Journey 2018 Manuale utente

Dodge

Dodge RAM ProMaster 2014 Manuale utente

Dodge

Dodge CALIBER 2011 Manuale utente

Dodge

Dodge Polara 1967 Manuale utente

Dodge

Dodge 2007 Charger Manuale utente

Dodge

Dodge 2010 Ram Truck Chassis Manuale utente

Dodge

Dodge Challenger SRT8 2011 Manuale utente

Dodge

Dodge ram truck 3500 1996 Manuale utente

Dodge

Dodge Coronet 1967 Manuale utente

Dodge

Dodge Grand Caravan 2019 Manuale utente

Dodge

Dodge 2006 Grandcaravan Manuale utente

Dodge

Dodge CHARGER 08 Manuale utente

Dodge

Dodge 2014 dodge challenger Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
