Quick Reference Guide CMT-30 (r2) DOKKi.eu
Legal N tices
This manual and any examples c ntained herein are pr vided "as is". JNC makes n warranty f any kind with regard t this manual,
including, but n t limited t , the implied warranties f merchantability, n n-infringement and fitness f r a particular purp se. JNC shall
n t be liable f r any err rs r f r incidental r c nsequential damages in c nnecti n with the furnishing, perf rmance, r use f this
manual r the examples c ntained herein.
Repr ducti n, adaptati n r translati n f this manual is pr hibited with ut pri r written permissi n f JNC Service B.V.
CAUTION: This Quick Reference Guide may be revised r withdrawn at any time with ut pri r n tice.
This d cument pr vides basic instructi ns f r setting up y ur DOKKi d cking cabinet.
UNPACKING
D NOT use a knife t pen the package r c ntents as this may result in damaging the pr duct(s)!
Open the uter b x n the t p-side (indicated by the 'this way up” sign n the labels). Carefully lift the d cking cabinet fr m it's b x and
rem ve the bubble-f il.
REMOVING TRANSPORT TAPE
Several parts have been secured with range tape, t prevent them
fr m m ving during transp rt.
L cate and rem ve all the range the tape gently and verify that
these parts are in their riginal perati nal p siti n.
If n t, re-fit r re-insert as necessary.
DOKKi.eu is a trademark f JNC Service B.V. ('JNC'). C pyright JNC Service B.V. All rights reserved.
CMT-30_QRG-003 / December 2014
Orange transp rt tape
Quick Reference Guide CMT-30 (r2) DOKKi.eu
BOX CONTENTS
•CMT-30 (r2) d cking cabinet
Pr m ti nal items aren't listed here.
The CMT-30 (r2) will fit Optic n scanner m dels OPN-2001, OPN-2002, OPN-2005 and OPN-2006.
Always check ur website f r the latest list f m dels that fit if y ur m del isn't listed here.
Bef re inserting y ur scanner be sure t rem ve the rubber USB c ver (if any). Save the USB c ver in case it's needed
at a later stage.
The inserti n area is as tight as p ssible t ensure stability f r the OPN scanner. That als means that the OPN w n't fit any m re when
used in c mbinati n with any available OPN sleeve r case (rubber, leather, etc.).
By rem ving the USB c ver fr m the scanner dust and/ r m ist can penetrate the c nnect r and pening(s) behind
the USB c ver m re easily. It is p ssible that the pr ducts' IP rating has been altered t .
Rem ving any riginal part fr m the scanner c uld v id warranty. D ing s is at y ur wn risk!
Other m dels (f r example the OPN-2003 and OPN-2004) w n't fit.
Trying t insert unlisted m dels will result in damage t the d cking cabinet and ther scanner m del!
DOKKi.eu is a trademark f JNC Service B.V. ('JNC'). C pyright JNC Service B.V. All rights reserved.
CMT-30_QRG-003 / December 2014
Quick Reference Guide CMT-30 (r2) DOKKi.eu
POSITIONING
The CMT-30 has rubber feet n the b tt m and can be used as a desk-stand , r it can be wall-m unted with the 'Wall M unt KIT'
which is separately available as an access ry.
Desk-stand
Please make sure the CMT-30 is p siti ned n a firm backgr und which is level.
Wall-m unted
The Wall M unt KIT c nsists f:
•CMT-30 M unt Instructi n
•CMT-30 Drill Template 1:1 scale (A3 f rmat)
•M6 x 35mm universal nyl n plugs, gray (3x)
•M5 x 40mm screws, galvanized (3x)
POWER AND CONNECTION
Input: 100–240V~, 50/60Hz
After unpacking and p siti ning, simply plug the p wer c nnect r (type: Shuk F) in the wall utlet.
The d cking cabinet is n w ready f r use.
CMT-30 USAGE SAMPLES
•CHARGE ONLY
Y u can use the CMT-30 as a 'charge nly d ck'. F r this y u nly need t plug the p wer c rd.
This way all thirty p rts are p wered and can be used t charge y ur scanner.
•COMMUNICATION AND CHARGING (MIXED)
Y u can use all p rts t c mmunicate with the PC as well. F r this c nnect the USB p rt situated at the back t a PC.
Remember: each scanner c nnecti n t the PC will generate it's wn VCP (Virtual C mm P rt), s make sure y ur s ftware is
able t handle this!
DRIVER INSTALLATION – ONLY NECESSARY WHEN USING COMMUNICATION ON THE CMT-30
The CMT-30 itself d es n t need a separate driver. The nly driver that needs t be installed n y ur PC is the appr priate
driver f r y ur scanner OPN-m del that y u wish t use n the CMT-30. If n t already d ne s , please f ll w the instructi ns
f r driver installati n in the c rresp nding manual that bel ngs t y ur scanner m del as pr vided by Optic n.
DOKKi.eu is a trademark f JNC Service B.V. ('JNC'). C pyright JNC Service B.V. All rights reserved.
CMT-30_QRG-003 / December 2014
CMT-30 (r2) rear view
Quick Reference Guide CMT-30 (r2) DOKKi.eu
DOCKING YOUR SCANNER
H ld the scanner between y ur thumb and index finger n the OPN's b dy where USB c nnect r is situated in the side (thus, n t in the
middle but m re t the left side, USB c nnect r p inting d wnward). Simply c nnect y ur scanner t the d cking stati n by gently
placing the OPN ver the d ck t align the c nnect rs. When aligned press the scanner d wn t secure the c nnecti n.
Press firmly but never use excessive f rce when pressing d wn as this might damage the c nnect rs!
Check f r bstructi ns n b th c nnect rs and retry c nnecti n.
ACCESSORIES
•Wall M unt Kit t securely m unt the CMT-30 t a wall.
All ( ther) available access ries can be f und n ur website.
DOKKi.eu is a trademark f JNC Service B.V. ('JNC'). C pyright JNC Service B.V. All rights reserved.
CMT-30_QRG-003 / December 2014
CMT-30: d cking y ur scanner
Quick Reference Guide CMT-30 (r2) DOKKi.eu
TROUBLESHOOTING
If y u are experiencing any pr blem with the CMT-30 the first thing t check is if the scanner perates c rrectly when c nnected directly
t the PC with an USB cable. D s by plugging the USB cable that came with y ur scanner int y ur scanner and make sure the ther
end f the USB cable g es directly int the PC (bypassing any present HUB).
If it d es functi n pr perly c ntinue at the check-list bel w, therwise the pr blem is with y ur scanner itself, the USB cable r the PC
(USB p rt and/ r driver(s)).
Checklist
N p wer *1 -Is the mains p wer perati nal and c nnected pr perly?
-Is the scanner firmly pressed int the d cking stati n?
-D es the scanner perate in ther p rts f the d ck? (*2)
N c mmunicati n *1, *2 -Is the scanner fully charged?
-Are the necessary scanner drivers pr perly installed?
-D the c mmunicati n settings match between scanner and the PC?
-Are there n ther pr grams p lling n the same COM-p rt?
*1
(and if c nnected t a
p wered USB hub)
-Is the p wer-supply f the USB hub plugged in?
-Is ne p rt n the USB hub failing, r are all p rts faulty?
-Is the USB cable securely fitted n b th ends?
*2
If applicable t this DOKKi m del
If y u have any questi ns regarding the use f the DOKKi.eu CMT-30 d cking stati n please c ntact y ur dealer.
BY OPENING THE PACKAGE OF THIS PRODUCT YOU AGREE TO BECOME BOUND
BY THE LIABILITY AND WARRANTY CONDITIONS.
Limited Warranty, Liability and Disclaimers
This Limited Warranty and Disclaimer extends nly t pr ducts purchased directly fr m DOKKi.eu r a DOKKi.eu Auth rized Dealer as
stated n ur website (http://www.d kki.eu/dealers).
Under n circumstance JNC will be liable f r any direct, indirect, incidental, special, c nsequential, punitive, r exemplary
damages, including but n t limited t , damages f r l ss f pr fits, revenue, inc me, g dwill, use, data, r ther intangible l sses that
arise fr m use r inability t use the CMT-30, even if JNC has been inf rmed ab ut the p ssibility f such damages.
The DOKKi.eu CMT-30 is warranted f r a peri d f ne year after purchase, c vering defects in material and w rkmanship. JNC will
repair r, at its pini n, replace pr ducts that pr ve t be defective in material r w rkmanship under pr per use during the warranty
peri d. The warranty d es n t apply t defects resulting fr m (a) impr per r inadequate maintenance measures taken; (b) interfacing
parts r supplies n t supplied r auth rised by JNC; (c) unauth rized m dificati n r misuse; (d) perati n utside the applicable
envir nmental parameter limits specified f r the pr duct; r (e) impr per site preparati n r maintenance f r installati n.
Outside The Netherlands, return the pr duct t y ur dealer. F ll w the instructi ns pr vided by y ur dealer.
DOKKi.eu is a trademark f JNC Service B.V. ('JNC'). C pyright JNC Service B.V. All rights reserved.
CMT-30_QRG-003 / December 2014
