Dorma TS 93 Series Manuale utente

SHOE

END BLOCK

TRACK SLIDE

(2) DOOR

METAL

DOOR

WOOD

QTY

Attach track to wall.

Insert slide shoe and end blocks into track. Attach track to wall.

Determine hand of door and prepare door and

(REFERENCE UNIT CARTON LABEL FOR ACCESSORIES AND OPTIONS SUPPLIED)

TS93-5 PKT 90/119

POCKET DOOR TRACK (TRACK ON WALL)

POCKET

wall for fasteners according to template 08280112.

1

2

3

4

LEFT HAND DOOR RIGHT HAND DOOR

Attach mounting plate to door.

QTY

(4) WOOD

DOORS

METAL

DOORS

LEFT HAND DOORRIGHT HAND DOOR

QTY

(4)

WALLWALL

POCKET

POCKET

WALL

1 of 3

INS NO. Rev.

08280111 11/07

PAGE

www.dorma-usa.com 1-800-523-8483

RIGHT HAND DOOR

Attach closer to mounting plate. QTY

(4) LEFT HAND DOOR

INSPK NO. 08280110 Rev.11/07

POCKET

WALL

POCKET

WALL

Attach arm to slide shoe.

screw and tighten securely. Install track cover.

Align hole in arm with slide shoe in track. Insert

M5 HEX KEY

(93T, 93TH)

QTY

(1)

INS NO. PAGE Rev.

08280111 2 of 3 11/07

5

6

7

8Adjust spring tension to ensure proper closing and latching of door.

INCREASE

MAXIMUM NUMBER OF TURNS CLOCKWISE - 6

4

approx. 180° to 70°.

4 - DELAY speed from

POCKET

WALL

approx. 70° to 0°.

QTY

(1)

RIGHT HAND DOOR LEFT HAND DOOR

With door closed, place wrench on bottom pinion of closer. Rotate wrench slightly toward latch end of door.

C HINGES

LHINGES C

L

Attach main arm to top pinion of closer. Tighten securely with screw provided.

WRENCH WRENCH

Adjust sweep, latch and backcheck. 1 - SWEEP speed from

2 - LATCH speed from

3 - BACKCHECK cushion effect.

approx. 7° to 0°.

DECREASE

INCREASE SWEEP

BACKCHECK (INTENSITY)

RANGE

LATCH RANGE

CAUTION: DO NOT REMOVE VALVES.

INCREASE

DECREASE BACKCHECK

CAUTION: DO NOT CLOSE VALVE COMPLETELY. RANGE

123

screw.

Secure with locking

TAB

COVER

cover onto plate.

END COVERS

end caps.

Slide end covers over closer body

REMOVE

Remove tab that aligns with arm hub. Slide

Install cover.

9

INS NO. PAGE Rev.

08280111 3 of 3 11/07
