ITS9613 and ITS9625
Closer in frame, track in door
(Metal door and frame)
Installation instructions
08279641 – 02-2020
| EN |
2ITS96 Concealed in Door Closers 02-2020
08279641
dormakaba ITS9613 and ITS9625 (Metal door)
Installation Instructions
Table of Contents
Table of contents
1 Technical specifications 3
. Overview
. Tools recommended
. Handing the door
2 Installation instructions 4
. Installing closer in frame
. Install track
. Secure arm to track
3 Adjustments 6
. Adjust deadstop
. Adjust sweep and latch
. Adjust hold open
. Adjust spring force
dormakaba ITS9613 and ITS9625 (Metal door)
Installation Instructions
08279641 02-2020ITS96 Concealed in Door Closers 3
Technical specifications
1 Technical specifications
. Overview
Caution: sex nuts are required for attachment
of components to unreinforced doors and to
wood or plastic faced composite type fire doors,
unless an alternative method is identified in the
individual door manufacturer’s listings.
Maximum door opening degree is 120°.
Know the swing of the door which is being
installed prior to installation.
Verify closer spring size prior to installation.
Make sure door efficiently operates prior to
installing closer.
Drill bits: # Phillips screwdriver
Metal: /” drill bit; /-
tap
/” flat head screwdriver
Wood: /” and /” bit mm ,mm, mm hex keys
/” box wrench /” box wrench
. Tools recommended
Table
. Handing the door
Fig.
Hinge Hinge
Exterior side of door
Interior side of door
Left hand door (LH) Right hand door (RH)
dormakaba ITS9613 and ITS9625 (Metal door)
Installation Instructions
08279641 02-2020ITS96 Concealed in Door Closers
4
Closer
Track
. Installing closer in frame
2 Installation instructions
.. Place arm on closer according to hand of door.
.. Secure arm with pinion screw.
.. Close valve by turning completely clockwise.
.. Rotate arm ° to preload.
Fig.
Pinion
screw
Arm
Right hand
door
Left hand
door
mm hex
key
45°
120°-0°
45°
7°-0°
Valve
Right hand
door
Left hand
door
mm hex
key
. Install track
Fig.
.. Thread screw a few turns into deadstop block.
.. Insert components into track.
.. Fasten track to door.
Deadstop
block
Deadstop
assembly
Slide
shoe
Hold open
(optional)
NOTE: Arrows on hold open and
slide shoe, must point away from
hinge when installing in track.
dormakaba ITS9613 and ITS9625 (Metal door)
Installation Instructions
08279641 02-2020ITS96 Concealed in Door Closers 5
Main arm
. Secure arm to track
Fig.
.. Align hole in arm with slide shoe. .. Attach with screw provided.
6mm hex key on
hold open units only
mm hex
key
Screw
Arm
dormakaba ITS9613 and ITS9625 (Metal door)
Installation Instructions
08279641 02-2020ITS96 Concealed in Door Closers
6
Adjustments - deadstop
Adjustments - closing speeds
3 Adjustments
. Adjust deadstop
. Adjust sweep and latch
Fig.
Fig.
.. Open door to desired opening between ° and
°.
.. Tighten deadstop block.
NOTE: The deadstop helps to prevent damage to the
door and wall when the door is opened normally. The
deadstop is not abuse resistant, and cannot replace a
door stop in many situations. Deadstop is adjustable
between 80° and 120° maximum.
120°-0°
7°-0°
7°-0°
120°-0°
-
+
CAUTION:
DO NOT REMOVE VALVES
Increase
only
Sweep
Sweep
range
(°-°)
mm
hex key
Latch Latch
range
(°-°)
mm
hex key
dormakaba ITS9613 and ITS9625 (Metal door)
Installation Instructions
08279641 02-2020ITS96 Concealed in Door Closers 7
Adjustments - hold open
Adjustments - spring force
. Adjust hold open
Fig.
Fig.
Increase
Decrease
Barrier free openings: Adjust only if more tension is
required to close and latch the door. Depending on
opening conditions, a door adjusted to meet barrier-
free forces may not have sufficient power to reliably
close and latch the door.
• Decrease force: turn counter-clockwise
• Increase force: turn clockwise
• Max turns -
Closer size Max door
weight (lbs)
Door width Full turns
Interior
'"
'
'" NA
' NA
’” NA
’ -
’”
’
. Adjust spring force
OFF
ON
.. Place the hold open mechanism in desired
position and tighten screw.
.. To adjust hold open force:
• To increase = turn CW
• To decrease = turn CCW
.. To enable: push white slide into hold open
mechanism.
.. To disable: pull white slide away from hold open
mechanism.
www.dormakaba.us
dormakaba
DORMA USA, Inc.
T: 800-523-8483
