Dover Hillphoenix BAKERY BWS-B-D Manuale utente
05/21
Technical References .........................................2-7
General Information ............................................... 8
Installation ........................................................9-10
Case Connections ................................................11
Lighting & Power Supplies............................. 12-13
Pre-Power Checklist ............................................14
Case Cleaning ......................................................15
Parts Ordering ......................................................16
Appendices
Table of Contents
BWS-B-D/BWS-RB-D
BAKERY
MULTI-DECK MERCHANDISER
I N S TA L L AT I O N & O P E R AT I O N S M A N U A L
To ensure proper functionality and optimum performance, it is STRONGLY recommended that Hillphoenix specialty cases be installed/serviced by qualified tech-
nicians who have experience working with commercial refrigerated display merchandisers and storage cabinets. For a list of Hillphoenix-authorized installation/
service contractors, please visit our website at www.hillphoenix.com.
ii
LIABILITY NOTICE
For Cases with Shelf Lighting Systems
Hillphoenix does NOT design any of its shelf lighting systems or any of its display cases with shelf lighting
systems for direct or indirect exposure to water or other liquids. The use of a misting system or water hose
on a display case with a shelf lighting system, resulting in the direct or indirect exposure of the lighting
system to water, can lead to a number of serious issues (including, without limitation, electrical failures,
fire, electric shock, and mold) in turn resulting in personal injury, death, sickness, and/or serious property
damage (including, without limitation, to the display itself, to the location where the display is situated
[e.g., store] and to any surrounding property). DO NOT use misting systems, water hoses or other devices
that spray liquids in Hillphoenix display cases with lighted shelves.
If a misting system or water hose is installed or used on a display case with a shelf lighting system, then
Hillphoenix shall not be subject to any obligations or liabilities (whether arising out of breach of contract,
warranty, tort [including negligence], strict liability or other theories of law) directly or indirectly resulting
from, arising out of or related to such installation or use, including, without limitation, any personal injury,
death or property damage resulting from an electrical failure, fire, electric shock, or mold.
P079211M, REVO
iii
Important
D A N G E R
▲
Indicates an immediate threat of death or seri-
ous injury if all instructions are not followed
carefully.
At Hillphoenix®, the safety of our customers and employees, as well as the ongo-
ing performance of our products, are top priorities. To that end, we include impor-
tant warning messages in all Hillphoenix installation and operations handbooks,
accompanied by an alert symbol paired with the word "DANGER", "WARNING", or
"CAUTION".
All warning messages will inform you of the potential hazard; how to reduce the
risk of case damage, personal injury or death; and what may happen if the in-
structions are not properly followed.
W A R N I N G
Indicates a potential threat of death or serious
injury if all instructions are not followed care-
fully.
▲
C A U T I O N
Indicates that failure to properly follow instruc-
tions may result in case damage.
▲
iv
Revision History
• new manual format_03/21
• parts list_03/21
• technical references and diagrams_05/21
v
TECHNICAL REFERENCE
ENGINEERED FOR STORES WITH AMBIENT
CONDITIONS NOT TO EXCEED 75° AND 55%
RELATIVE HUMIDITY. DUE TO ENGINEERING
IMPROVEMENTS SPECIFICATIONS MAY CHANGE
WITHOUT NOTICE. ALL MEASUREMENTS ARE
TAKEN PER ASHRAE-72-2005 SPECIFICATIONS.
NUMBERS ARE BASED ON STANDARD CASE SIZES.
CONSULT ENGINEERING.
BWS-B
Self-Service Open Multi-Deck Crusty Bread Merchandiser w/ Bins
48", 60", 72", 96", 120", & 144" (Bakery)
BWS-B
Rev. Date Rev. # Rev. Title
05-07-21 1 NEW STANDARDS
SHIPPING WEIGHT
Case Weight
BWS-B ---
GENERAL NOTES:
• "---" Indicates that the feature is not an option on this case model and/or the data is not yet available at this time.
2
TECHNICAL REFERENCE
ENGINEERED FOR STORES WITH AMBIENT
CONDITIONS NOT TO EXCEED 75° AND 55%
RELATIVE HUMIDITY. DUE TO ENGINEERING
IMPROVEMENTS SPECIFICATIONS MAY CHANGE
WITHOUT NOTICE. ALL MEASUREMENTS ARE
TAKEN PER ASHRAE-72-2005 SPECIFICATIONS.
NUMBERS ARE BASED ON STANDARD CASE SIZES.
CONSULT ENGINEERING.
BWS-B
Self-Service Open Multi-Deck Crusty Bread Merchandiser w/ Bins
48", 60", 72", 96", 120", & 144" (Bakery)
BWS-B
Rev. Date Rev. # Rev. Title
05-07-21 1 NEW STANDARDS
LIGHTING DATA
Case
Length
Lights
Per
Row
Light
Length
Clearvoyant 4 LED Lighting
(Per Light Row)
Standard Power
(Cornice or Shelf)
High Power
(Cornice)
120 Volts 120 Volts
Amps Watts Amps Watts
48" 1 4' 0.05 5.9 0.12 14.9
60" 1 5' 0.06 7.5 0.15 18.5
72" 2 3' 0.08 9.4 0.20 23.8
96" 2 4' 0.10 11.8 0.24 29.8
120" 2 4' 0.10 11.8 0.24 29.8
144" 3 4' 0.15 17.7 0.36 44.7
3
TECHNICAL REFERENCE
FRONT OF CASE
31 15/16" [81.2 cm]
4 13/16" [12.1 cm]
16" [40.7 cm]
29 13/16" [75.7 cm]
144" [365.8 cm] 1" [2.5 cm]
11 13/16" [30.0 cm]
48" [121.9 cm] {4' case}
60" [152.4 cm] {5' case}
72" [182.9 cm] {6' case}
96" [243.8 cm] {8' case}
120" [304.8 cm] {10' case}
144" [365.8 cm] {12' case}
15" X 15" MECHANICAL ACCESS
TOEKICKPOWER SUPPLY
29 5/16" [74.5 cm]
7 13/16" [19.9 cm]14 11/16" [37.3 cm]
6 5/16" [16.0 cm]
29 15/16" [76.1 cm]
31 15/16" [81.2 cm]
INTERIOR HEIGHT
58 1/2" [148.6 cm]
CASE HEIGHT
81" [205.7 cm]
VISUAL DISPLAY
58 7/16" [148.4 cm]
13"
16"
20"
24"
ENGINEERED FOR STORES WITH AMBIENT
CONDITIONS NOT TO EXCEED 75° AND 55%
RELATIVE HUMIDITY. DUE TO ENGINEERING
IMPROVEMENTS SPECIFICATIONS MAY CHANGE
WITHOUT NOTICE. ALL MEASUREMENTS ARE
TAKEN PER ASHRAE-72-2005 SPECIFICATIONS.
NUMBERS ARE BASED ON STANDARD CASE SIZES.
CONSULT ENGINEERING.
BWS-B
Self-Service Open Multi-Deck Crusty Bread Merchandiser w/ Bins
48", 60", 72", 96", 120", & 144" (Bakery)
BWS-B
Rev. Date Rev. # Rev. Title
05-07-21 1 NEW STANDARDS
4
TECHNICAL REFERENCE
ENGINEERED FOR STORES WITH AMBIENT
CONDITIONS NOT TO EXCEED 75° AND 55%
RELATIVE HUMIDITY. DUE TO ENGINEERING
IMPROVEMENTS SPECIFICATIONS MAY CHANGE
WITHOUT NOTICE. ALL MEASUREMENTS ARE
TAKEN PER ASHRAE-72-2005 SPECIFICATIONS.
NUMBERS ARE BASED ON STANDARD CASE SIZES.
CONSULT ENGINEERING.
BWS-RB
Self-Service Open Multi-Deck Crusty Bread Merchandiser w/ Bins
48", 60", 72", 96", 120", & 144" (Bakery)
BWS-RB
Rev. Date Rev. # Rev. Title
04-28-21 1 NEW STANDARDS
GENERAL NOTES:
• "---" Indicates that the feature is not an option on this case model and/or the data is not yet available at this time.
SHIPPING WEIGHT
Case Weight
BWS-RB ---
5
TECHNICAL REFERENCE
ENGINEERED FOR STORES WITH AMBIENT
CONDITIONS NOT TO EXCEED 75° AND 55%
RELATIVE HUMIDITY. DUE TO ENGINEERING
IMPROVEMENTS SPECIFICATIONS MAY CHANGE
WITHOUT NOTICE. ALL MEASUREMENTS ARE
TAKEN PER ASHRAE-72-2005 SPECIFICATIONS.
NUMBERS ARE BASED ON STANDARD CASE SIZES.
CONSULT ENGINEERING.
BWS-RB
Self-Service Open Multi-Deck Crusty Bread Merchandiser w/ Bins
48", 60", 72", 96", 120", & 144" (Bakery)
BWS-RB
Rev. Date Rev. # Rev. Title
04-28-21 1 NEW STANDARDS
LIGHTING DATA
Case
Length
Lights
Per
Row
Light
Length
Clearvoyant 4 LED Lighting
(Per Light Row)
Standard Power
(Cornice or Shelf)
High Power
(Cornice)
120 Volts 120 Volts
Amps Watts Amps Watts
48" 1 4' 0.05 5.9 0.12 14.9
60" 1 5' 0.06 7.5 0.15 18.5
72" 2 3' 0.08 9.4 0.20 23.8
96" 2 4' 0.10 11.8 0.24 29.8
120" 2 4' 0.10 11.8 0.24 29.8
144" 3 4' 0.15 17.7 0.36 44.7
6
