Dräger Alcotest 5000 Manuale utente

9033880 | QRG 4754.540

www.draeger.com

Edition 02 | December 2018

Alcotest 5000

th 1 ปากกรวย | 2 ไฟ LED สีแดง/เขียว |

3 จอแสดงผล | 4 ปุ่มเมนู/ลง

ใช้เข้าสู่เมนูหรือเลื่อนลง | 5 ปุ่มตกลง/เปิด-ปิด

ใช้เริ่มโหมดตรวจวัดแบบพาสซีฟและยืนยัน

การเลือกเมนูด้วย | 6 ปุ่มขึ้น ใช้เลื่อนขึ้น |

7 พอร์ต USB ใช้กับบริการซ่อมบำรุง |

8 ช่องร้อยสายคลอ้งขอมือ

ดาวน์โหลดคำแนะนำการใช้งานได้ที่

www.draeger.com/ifu

vi 1Phễu thổi | 2 đèn LED màu đỏ/màu xanh l

á cây | 3Hiển thị| 4 Nút Trình đơn/ĐI XUỐNG

để vào bảng chọn hoặc điều hướng đi xuống |

5Nút OK/Bật-Tắt, để bắt đầu kiểm tra thụ

động và xác nhận lựa chọn menu |

6 Nút ĐI LÊN để điều hướng đi lên |

7cổng USB đểkết nối thiết bị bảo trì/sửa chữa |

8 Lỗ xâu vòng đeo tay

Tải hướng dẫn sử dụng tại

www.draeger.com/ifu

ms 1 Corong | 2 LED merah/hijau | 3 Paparan |

4 Butang menu/TURUN untuk memasuki menu

atau menavigasi ke bawah | 5 Butang OK/Hidup-Mati,

juga untuk memulakan pengujian pasif dan

mengesahkan pemilihan menu | 6 Butang NAIK untuk

menavigasi ke atas | 7 Port USB untuk servis |

8 Lelubang tali tangan

Muat turun arahan penggunaan di

www.draeger.com/ifu

zhTW 1 漏斗 | 2 紅色/綠色 LED |

3 顯示屏 | 4 功能表/向下按鈕，

用於進入功能表或向下瀏覽 |

5 確定/開關按鈕，也用於啟動被

動測試以及確認功能表選擇 |

6 向上按鈕，用於向上瀏覽 |

7 維修用 USB 埠 | 8 腕帶孔眼

請造訪 www.draeger.com/ifu

下載使用說明書

en 1 Funnel | 2 Red/green LED | 3 Display |

4 Menu/DOWN button for entering the menu

or navigating down | 5 OK/On-Off button,

also to start passive testing and confirming

menu selections | 6 UP button to navigate up |

7 USB port for service | 8 Hole for wrist strap

Download the instructions for use at

www.draeger.com/ifu

Click

1 sec

2 cm1 cm 3 cm

10 min

www.draeger.com/ifu

Download

Alcohol No alcohol

Alkohol Tiada alkohol

Có cồn

Không có cồn

มีแอลกอฮอล์ ไม่มีแอลกอฮอล์

zhtw |

vi |

th |

en |

27.12.2016 10:25 #00075

3...2...1... off!

5 sec

www.draeger.com | 9033880 | QRG 4754.540 Edition 02 | December 2018 | © Dräger Safety AG & Co. KGaA

酒精無酒精
