posterior

safety roller

for use with CE 1200 BK, PE 1200

and PE TYKE 1200

www.drivemedical.com

lifetime limited

warranty

Your Drive brand product is warranted to be free

of defects in materials and workmanship for the

lifetime of the original consumer purchaser.

This device was built to exacting standards and

carefully inspected prior to shipment. This Lifetime

Limited Warranty is an expression of our confi-

dence in the materials and workmanship of our

products and our assurance to the consumer of

years of dependable service.

In the event of a defect covered by this

warranty, we will, at our option, repair or replace

the device.

This warranty does not cover device failure

due to owner misuse or negligence, or normal

wear and tear. The warranty does not extend to

non-durable components, such as rubber

accessories, casters, and grips, which are subject

to normal wear and need periodic replacement.

If you have a question about your Drive device or

this warranty, please contact an authorized Drive

dealer.

Drive is a trademark of Medical Depot, Inc.

Port Washington N.Y. 11050 USA Made in China

set up instructions

1. Remove Safety Roller from carton.

2. Unfold Safety Roller by lifting ring from left upright and

open frame. Lift handlebar and position over left upright.

Make sure spring button snaps into hole on the

handlebar underside.

height adjustments

Recommended handlebar height is at the wrist with arms fully

extended. With your hand placed on the hand grip, your elbow

should be flexed 20° - 30°.

1. Open both height adjustment knobs.

2. Push in spring button, one side at a time and raise

or lower uprights to desired height.

3. Tighten knobs.

folding instructions

1. Press spring button on left side of handlebar and lift

handlebar.

2. Hold handlebar in right hand and with left hand, swing

left upright outward and squeeze into Z position until

fully folded.

3. Drop handlebar over folded Safety Roller.

4. Secure both the uprights by putting the ring over the left

upright and under the spring button.

accessories

Adjustable forearm platforms, vertical hand grips, variable

resistance tabs on rear wheels, swivel wheel locking brackets,

seat harness, ankle prompts, posterior positioning bar, pelvic

stabilizer,trunk support, extended uprights for additional

height, IV pole and oxygen tank holder.

Call an authorized Drive dealer for detailed information about

our accessories.

ﬁgure 1

Item # PE 1200 Shown

Spring Button

Comfort

Grips

Ring

Height

Adjustment

Knobs

Spring

Button

ﬁgure 2

(folded position)
