Global 55 CF RCE

Global 55XT CF RCE

Installation manual

DRU-790113-EN-US-0420-3

G20/G25/G25.3 (Natural gas) G31 (Propane)

959.116.02.EN

English

INSTALLATION MANUAL

1. Introduction

2. CE declaration

3. SAFETY

3.1 General

3.2 Regulations

3.3 Precautions/safety instructions during installation

3.4 Second thermocouple safety

3.5 Oxypilot safety

4. Removing the packaging

5. Installation

5.1 Type of gas

5.1.1 Reconstruction to different type of gas

5.2 Connection

5.2.1 Gas connection

5.2.2 Electric connection

5.3 Placing the appliance

5.4 Placing a built-in appliance

5.5 Placing the chimney breast

5.6 Placing the control hatch

5.7 Flue gas discharge system in appliances with open combustion

5.7.1 General

5.7.2 Connection flue gas discharge system

5.8 Flue gas discharge / combustion air supply system in appliances with closed combustion

5.8.1 General

5.8.2 Construction of the concentric system

5.8.3 Placing the concentric system

5.8.4 Connection existing chimney

5.9 Additional instructions

5.10 Placing the appliance

5.10.1 Connecting the appliance

5.10.2 Connecting the flue gas discharge system

5.11 Setting the appliance

5.12 Glass pane

5.12.1 Removing the glass pane

5.12.2 Placing the glass pane

5.13 Placing the wood set

5.14 Placing / replacing the receiver’s batteries

6. Control

6.1 Connecting the receiver

6.1.1 Connecting the receiver

6.1.2 Placing / replacing the receiver's batteries

6.2 Setting the communication code

6.3 Alternative operation

7. Final inspection

7.1 Gastightness

7.2 Gas pressure/line-pressure

7.3 Ignition pilot and main burner

7.3.1 First ignition of the appliance after installation or adjustments

7.3.2 Main burner

7.4 Flame picture

8. Maintenance

8.1 Parts

9. Delivery

10. Malfunctions

Appendix 1 Diagnosis of malfunctions

Appendix 2 Various tables

Appendix 3 Figures

Contents

English

INSTALLATION MANUAL

1.Introduction

DRU, a manufacturer of gas-fired heating appliances, develops and produces products that comply with the

highest quality, performance and safety requirements. This appliance has a CE label, which means that it complies

with the essential requirements of the European gas appliance directive. The appliance is supplied with an

installation manual and a user manual. Installation and maintenance of the appliance should be performed by a

professional certified expert with proven knowledge and demonstrable competence in this field. A professional

expert takes all technical aspects such as heat output and gas connection into account, as well as the flue gas

discharge requirements. The installation manual will give you the information you need to install the appliance in

such a way that it will operate properly and safely. If the installation instruction is not clear, national/local

regulations must be observed.

This manual discusses the installation of the appliance and the regulations that apply to the installation. In

addition, you will find the appliance’s technical data as well as information on maintenance, possible malfunctions

that might occur and what may cause them.

The figures can be found at the back of this booklet, in the appendix.

Please, read and use this installation manual carefully and completely, prior to installing this appliance. If you use

the DRU Powervent system® or the DRU Smartvent system®, you must carefully and fully read and use the

accompanying installation manual as well, prior to its installation.

The following symbols are used in the manual to indicate important information:

Work to be performed

!Tip

Suggestions and recommendations

!Caution

You will need these instructions to prevent problems that might occur during installation and/or use.

!Caution

You need these instructions to prevent fire, personal injury or other serious damages.

After delivery, you should give the manuals to the user.

2.CEdeclaration

DRU declares that company internal measures guarantee that appliances produced by DRU meet the essential

requirements and guidelines of the regulation concerning gas-fired appliances and the accompanying standards.

This declaration loses its validity if changes are made to the appliance without written permission from DRU. The

instructions in the manuals must also be observed at all times.

A copy of the CE test certificate can be downloaded via www.druservice.com.

Product:

Type:

Product identification number:

Conformity assessment agency:

Regulations:

Standards:

Gas-fired heating appliance

Global 55 CF RCE, Global 55XT CF RCE

0063CP3640

Kiwa Netherlands B.V. (0063)

Wilmersdorf 50

Postbus 137

7300 AC, Apeldoorn

(EU) 2016/426, (EU) 2015/1188

EN 613:2000, EN 613:2000/A1:2003, EN 613:2000/PrA2:2002

DRU Verwarming B.V.

Postbus 1021, NL-6920 BA Duiven

Ratio 8, NL-6921 RW Duiven

www.drufire.com

R.P. Zantinge Managing director

Duiven, 09-02-2018

English

INSTALLATION MANUAL

3.SAFETY

3.1General

!Caution

• Please observe the generally applicable regulations and precautions/safety instruction in this manual.

• First check the exact technical version of the appliance to be installed in Appendix 2, Table 2.

3.2Regulations

Please install the appliance in accordance with the applicable national, local and constructional (installation)

regulations.

3.3Precautions/safetyinstructionsduringinstallation

Carefully observe the following precautions/safety regulations:

You should only install and maintain the appliance if you are a certified and competent installer in the field of

gas-fired heating.

Do not make any changes to the appliance.

If you are installing an appliance that must be built in;

• use non combustible and heat-resistant material for the chimney breast, including the top of the chimney

breast, the material inside the chimney breast and the back wall against which the appliance will be placed.

For this you can use both sheet material and stone-like materials;

• take sufficient measures to prevent high temperatures of the wall behind the chimney breast, including the

materials and/or objects that are behind the wall;

• comply with the minimum required internal measurements of the chimney breast;

• vent the chimney breast by means of ventilation holes with a combined passage as stated further down in

the text. When placing an appliance with open combustion (type B 11 AS/BS), no chimney breast ventilation is

required, as there is an existing chimney with a brickwork fireplace that is sufficiently able to absorb the heat;

• use heat-resistant electric connections and make sure that they do not make contact with the appliance;

If you are installing an appliance with open combustion: please use a suitable flue gas discharge system provided

with the CE label, and make sure there is sufficient ventilation of the room where the appliance is installed,

according to legislation.

If you are installing an appliance with a closed combustion: only use the concentric systems supplied by DRU.

If you are installing a free-standing appliance:

• place the appliance away from the back wall by the minimum distance stated further down in the text;

• make sure you observe the minimum distance in relation to the side wall(s) and the space above the

appliance (see Appendix 3, fig. 2).

Do not cover the appliance and/or do not wrap it in an insulation blanket or any other material.

Unless stated otherwise: make sure that combustible objects and/or materials have a distance from the appliance

of at least 500 mm.

Only use the accompanying wood/pebble set and place it exactly as described.

The space surrounding the pilot burner, 2nd thermocouple or ionisation pins must remain free.

Make sure there is no dirt in gas pipes and connections.

Place a gas tap in accordance with applicable regulations.

Prior to putting into operation, check the complete installation for gastightness.

If your appliance is provided with explosion hatches on its top, you must make sure that they cannot be blocked

and check whether they fit well onto the sealing surface, prior to building in the appliance.

Do not ignite the appliance before the gas and discharge connections have been fully installed, first observe the

procedure described in chapter 7.3.

Replace broken or torn glass panes.

The appliance was designed for atmospheric and heating purposes. This means that all visible surfaces, including

the glass pane, can become hotter than 100C°. It is recommended to always place a protective grating in front of

the appliance when there are children, elderly people or handicapped persons in the same room as the appliance.

If it is possible that vulnerable people are regularly present in the room with no supervision, a fixed guard should

be mounted around the appliance.

!Caution

In case of broken or torn glass panes, the application may not be used.

English

INSTALLATION MANUAL

3.4Secondthermocouplesafety (if applicable, see Appendix 2, Table 2)

It is possible, that the appliance to be installed has 2 thermocouples. Thermocouple 1 is always next to the pilot

burner, thermocouple 2 is always elsewhere above the main burner.

If the appliance is provided with a second thermocouple safety on the main burner, you need to know that it will

intervene if no proper transfer has taken place from the pilot burner to the main burner or from the main burner

itself. The gas supply will be interrupted after 22 seconds. In order to solve a poor or non-existent transfer from the

pilot burner to the main burner, please use the malfunction search diagram in Appendix 1.

3.5Oxypilotsafety (if applicable, see Appendix 2, Table 2)

If the appliance is provided with an oxypilot safety, you need to know that it will intervene (the pilot flame and the

gas supply to the main burner will be switched off) if insufficient combustion air (oxygen) is supplied and/or if the

discharge system has insufficient thermal draught.

Once the supply of combustion air is sufficient again, the appliance can be restarted.

The supply of fresh air can be controlled by installing/opening ventilation holes in the room where the appliance

is installed.

4.Removingthepackaging

Note the following items when removing the packaging:

Remove all packaging materials.

Remove all supplied components in, on and/or at the appliance.

Check the appliance and accessories for damages (during transport).

If necessary, contact your supplier.

Never install an appliance that is damaged !

Remove any screws that are used to fix the appliance to a platform or pallet.

!Caution

The glass pane(s) is/are made of a ceramic material. Very small irregularities in the glass pane(s) cannot be

avoided, but are within the required quality standards.

!Caution

Keep plastic bags away from children.

In Appendix 2, Table 1 you can see which parts you should have after removing the packaging.

Contact your supplier if you do not have all the parts after you finished removing the packaging.

Dispose of packaging in accordance with local regulations.

5.Installation

Read this manual carefully to ensure the proper and safe installation of the appliance.

!Caution

Install the appliance in the order described in this chapter.

Please install the appliance in accordance with the applicable national, local and constructional (installation)

regulations.

Observe the regulations/instructions in this manual.

5.1Typeofgas

The data plate indicates for which type of gas, gas pressure and for which country this appliance is intended.

The data plate can be found on the appliance or can be attached to a chain to which it should remain attached.

!Caution

Check whether the appliance is suitable for the type of gas and the gas pressure used at the location.

5.1.1Reconstructiontodifferenttypeofgas

If you want to convert this appliance into a different type of gas, please contact DRU's service department and ask

what is possible. Reconstructions should only be performed by authorized gas installers.

English

INSTALLATION MANUAL

5.2Connection

5.2.1Gasconnection

Place a gas tap in the gas pipe in accordance with the applicable regulations.

!Caution

• Make sure there is no dirt in the gas pipes and connections.

• No soldering may take place at the flexible gas hose(s), as this could cause leaks.

The following requirements apply to the gas connection:

• use a gas pipe with the correct dimensions, so that no pressure loss can occur;

• the gas tap must be approved (in the EU this will be the CE mark);

• you should always be able to reach the gas tap.

5.2.2Electricconnection

In case of a 230 Volt electrical connection, provide proper grounding, if applicable.

Place this electrical connection away from the appliance, as low as possible in the chmney breast.

This has to do with the temperature development in the chimney breast.

If possible, place the receiver after any building work has been completed.

If this is not possible:

!Caution

Protect the receiver against dust and moisture created during the building process!

5.3Placingtheappliance

!Caution

• Unless stated otherwise: always place the appliance with a minimum distance of 500 mm from combustible

objects or materials;

• Place the discharge pipes in such a way that situations with risk of fire can never occur;

• Always place the appliance in front of a wall of non combustible and heat-resistant material;

• Always maintain a minimum distance between appliance and back wall, if indicated in the dimensional

drawing (Appendix 3, fig. 2);

• Take sufficient measures to prevent high temperatures of a possible wall behind the chimney breast,

including the materials and/or objects that are behind the wall;

• Do not cover the appliance and/or do not wrap it in an insulation blanket or any other material;

• Make sure that the appliance to be installed has a stable position. Attach the appliance, if applicable, to the

wall using the wall brackets and/or fasten the extending legs with self-tapping screws.

!Caution

When installing an appliance that has to be built in, take the following into account:

The minimum construction dimensions according to Appendix 3, fig. 1 and 2.

Provide a gas connection at the location. For details (see section 5.2).

Make a passage for the flue gas discharge system or the concentric system with the following diameters; for

details, see section 5.7 or 5.8:

• the pipe diameter +10 mm for a passage through non combustible material;

• the pipe diameter +100 mm for a passage through combustible material.

!Caution

Starting at section 5.9, you will find additional instructions that are specifically needed for the installation of your

appliance.

5.4Placingabuiltinappliance (if applicable)

Not all DRU built in appliances are supplied with a control hatch. If not included in the delivery, this control hatch

is available separately. In case of appliances with closed combustion (type C11/C31) we always recommend using

the Dru control hatch. In case of appliances with open combustion (type B 11 AS/BS), a control hatch is not required.

In this section we assume an application with control hatch.

!Caution

If you do not use a recommended Dru control hatch, please strictly observe the safeguards and necessary

instructions stated in chapters 5.4 to 5.6.

If you are not using the control hatch, please take the following into account as well:

• the accessibility of components that are normally placed in the control hatch;

• the maximum temperature of these components (maximum 55 °C).

The gas control is mounted under the appliance, at the burner mounting plate. It must be taken out and placed in

the control hatch at a later time. For placing the gas control in the control hatch, see section 5.6.

English

INSTALLATION MANUAL

Follow the procedure described below:

Disconnect the pipes from the gas control (flexible gas pipe, aluminium pilot burner pipe and thermocouple 1);

!Caution

The red wire of thermocouple 2, if applicable, must remain connected to the gas control.

Disconnect the gas control from the burner mounting plate by unscrewing the self-tapping screw.

Carefully unwind the red and black wire of thermocouple 2, if applicable.

Carefully lay the gas control together with the wires of thermocouple 2, the ignition cable, the flexible gas hose,

the aluminium pilot burner pipe and the type plate plus chain in the direction of the control hatch.

!Caution

• Prevent dirt in gas pipes and connections;

• Avoid kinks in the pipes.

!Caution

• Make sure the ignition cable cannot come into contact with other wires;

• The data plate should remain attached to the chain.

Set the height of the appliance using the adjustable feet (if applicable).

Make the appliance level at the same time.

!Tip

The construction frame for most 2 or 3 sided appliances can be adjusted. This will allow you to connect the

construction frame to the chimney breast correctly. For 2 or 3 sided appliances that cannot be adjusted, we would

like to refer you to chapter 5.9 'Additional instructions'.

!Caution

do not ignite the appliance before the gas and discharge connections have been fully installed, first observe the

procedure described in chapter 7.3.

5.5Placingthechimneybreast (if applicable)

In order to provide proper heat discharge, there should be sufficient space around the appliance. The chimney

breast should be ventilated sufficiently by means of ventilation holes (incoming and outgoing).

!Caution

• Use non combustible and heat-resistant material for the chimney breast, including the top of the chimney

breast, the material inside the chimney breast and the back wall of the chimney breast.

• Make sure that the appliance is not carrying the weight of the chimney breast when using stone-like

materials.

• The passage of the ventilation holes (outgoing), which are placed as high as possible, is stated in Appendix 2,

Table 2.

!Caution

When placing the chimney breast, you should take the following into account (see Appendix 3, fig. 2):

• the location of the control hatch: this must be placed as low as possible;

• the dimensions of the control hatch; see Placing the control hatch section 5.6;

• the Dru control hatch is not supplied with all appliances. Nevertheless, we recommend only using a Dru

control hatch, if available, exept in the case of B 11 AS/BS appliances. If you decide not to take this option, you

will have to make a 100 cm2 ventilation hole that is placed as low as possible, for the benefit of the incoming

ventilation;

• the location of the ventilation holes (V) (outgoing);

• maintain a minimum 30 cm distance between the top of the ventilation hole (outgoing) and the ceiling of the

house.

• the measurements of the glass pane, so that it can be placed/removed after placing the chimney breast;

• the protection of the gas control and the pipes against cement and plaster.

• If possible, you should place decorative strips, frames, etc., after any required structural work has been

completed. Avoid the use of painter's tape. If this is not possible: please use good quality painter's tape and

remove it immediately after plastering or painting work has been completed.

!Tip

You should preferably apply the ventilation holes (outgoing) on both sides of the chimney breast. You can use

DRU ventilation elements.

• Prior to completely closing the chimney breast, check whether the discharge / concentric system is placed

correctly.

• whether the channels, fixing brackets and possible clip bindings, which cannot be reached after installation,

are fastened by means of self-tapping screws.

English

INSTALLATION MANUAL

If applicable, do not plaster on or over the edges of the construction frame, because:

• the heat of the appliance could cause cracks;

• it will no longer be possible to remove/place the glass pane.

When using stone-like materials and/or a plaster finishing, allow the chimney breast to dry for at least six weeks

prior to using the appliance in order to prevent cracks.

5.6Placingthecontrolhatch (if applicable)

The control hatch (also see paragraphs 5.4 and 5.5) is placed as low as possible in the chimney breast.

!Caution

• The bottom of the control hatch may not be placed higher in the appliance than the burner surface.

• Place control hatch and bracket with gas control and accessories indoors in a dry place only!

A number of components are placed in the control hatch, such as data plate, gas control, receiver belonging to the

remote control and, if applicable, the components belonging to the DRU Powervent system ®.

Place the control hatch as follows; see Appendix 3, fig. 3 for details:

Make an opening in the chimney breast, as described in the manual for the control hatch.

Place the inner frame (1); unscrew bolts (5) for this.

!Tip

• When the chimney breast is made of bricks, the inner frame can be built with bricks at the same time

• When using a different material, you can glue the inner frame or fix it with four flush screws.

Mount the gas control to the brackets of the inner frame (2).

Check whether pipes and connections are free from dirt;

Reconnect the pipes to the gas control.

!Caution

• Avoid kinks in the pipes;

• Tighten the flexible gas pipe and the pilot burner pipe until they are gastight.

• First tighten the thermocouple by hand and;

• Then tighten it a quarter turn using a suitable spanner;

• The pilot burner pipe must be protected against possible corrosive influences as a result of, for example,

humidity, cement that has fallen down, dirt that has fallen down from the chimney, etc. The pilot burner pipe

should remain permanently free from the ground and the walls of the room in which the appliance is built in.

When installing in an existing fireplace, or if it is not possible to keep the pipes free, the pipe should be

protected against corrosion by means of a jacket.

Prevent dirt in gas pipes and connections.

Connect the gas pipe to the gas tap.

Bleed the gas pipe.

Place the receiver in the holder (3); for connecting, see section 6.1.

Place the data plate in its intended clamp (6).

Fix the outer frame with door (4) to the inner frame using 2 socket cap screws (5).

!Tip

You can place the outer frame in such a way, that the door turns to the left or to the right.

5.7Fluegasdischargesysteminapplianceswithopencombustion

For connection to an existing chimney without a discharge pipe or flexible SS discharge - only allowed in Great

Britain - the instructions provided in the separately supplied booklet 'Fitting into a conventional class 1 chimney'

apply. In addition to the installation instructions, this booklet also contains supplementary tests. In this situation

we recommend using a stainless steel flexible discharge pipe over the complete length, with a draught increasing

hood.

5.7.1General

The connection dimensions and the minimum length of the discharge system are indicated in Annex 2, table 2.

The appliance should be connected in accordance with the applicable national, local and constructional

(installation) regulations. You should only install the appliance in a well ventilated room which complies with the

applicable national, local and constructional (installation) regulations, in order to guarantee sufficient air supply.

English

INSTALLATION MANUAL

!Caution

• When the appliance is installed in a house with a mechanical air extraction system and/or an open kitchen

with cooker hood, you will need a permanent ventilation hole in the room where the appliance is installed;

please observe the gas installation regulations and the local regulations for dimensions and other required

provisions.

• No ventilation of the chimney breast is required in case of an existing chimney with a masonry fireplace that

is sufficiently able to absorb the heat. Therefore the ventilation hole in the chimney breast does not apply to

the class 1 chimney in the UK.

5.7.2Connectionoffluegasdischargesystem (if a class 1 chimney is not applicable)

For connection to an existing chimney, a flexible stainless steel discharge pipe is required over the complete

length for the discharge of the flue gases, unless indicated otherwise. A draught increasing hood is recommended

here.

!Caution

• Prevent dirt from an existing chimney from entering the flue gas discharge.

• Prevent false draught by carefully closing the space between the existing chimney and the discharge

material.

• Bends of more than 45 degrees are not allowed in the flue gas discharge system, unless indicated otherwise.

• Maintain a distance of at least 50 mm between the outside of the concentric system and the walls and/or

ceiling. If the system is built in (for instance) a cove, it should be made with non combustible material all

around it;

• Use heat-resistant insulation material when passing through combustible material.

• Use a flue gas discharge system with the correct diameter, and which is provided with the CE mark.

!Caution

Some heat-resistant insulation materials contain volatile components that will spread an unpleasant smell during

a longer period; these are not suitable.

Place the flue gas discharge system as follows:

Connect the pipe pieces or flexible SS discharge.

!Caution

• Make sure that the right insertion length is maintained.

• Secure the connections on locations that are impossible to reach after installation by means of self-tapping

screws.

5.8Fluegasdischarge/combustionairsupplysysteminapplianceswithclosed

combustion

5.8.1General

The appliance's type of discharge system is stated in Appendix 2, Table 2.

The appliance will be connected to a combined flue gas discharge / combustion air supply system, hereafter to be

referred to as the concentric system.

The passage to the outside can be made with both a wall terminal and roof terminal. If necessary, you can also use

an existing chimney (see section 5.8.4).

!Caution

• Only use the concentric system supplied by DRU This system has been tested in combination with the

appliance. DRU cannot guarantee a proper and safe operation of other systems and does not accept any

responsibility or liability for this;

• For connecting to an existing chimney you should only use the chimney kit supplied by DRU.

The concentric system is constructed from (the flue spigot of) the appliance.

If, due to constructional circumstances, the concentric system is placed first, it is possible to connect the appliance

by means of a telescopic pipe piece.

5.8.2Constructionoftheconcentricsystem

Depending on the construction of the concentric system, the appliance will have to be further adjusted with

possibly a restrictor slide or air inlet guide.

See Tables 4 and 6 for determining the correct adjustment and section 'Adjustment of the appliance' for the

method of working.

English

INSTALLATION MANUAL

The concentric system with wall or roof terminal has to comply with the following conditions:

• In appendix 2, table 4 or 5 you can find whether a concentric pipe should be connected and what the

minimum vertical length would have to be.

• Determine the permissibility of the required discharge.

When using a wallterminal, the following applies:

• The total vertical pipe length, when using a wall terminal, may have a maximum length that you can find in

Appendix 2, Table 4.

• The minimum vertical pipe length, when using a wall terminal, can be found in appendix 2, table 4.

• The total horizontal pipe length, when using a wall terminal, may have a maximum length that you can find in

Appendix 2, Table 4 (without wall terminal; see Appendix 3, fig. 4).

!Tip

In the horizontal section, 1 bend of 90° may be included. This bend counts for 2 metres. This means that the

maximum allowed length is reduced by 2 metres. A 45° bend counts for 1 metre.

When using a roofterminal, the following applies:

• The construction of the chosen system, when using a roof terminal, must be permissible according to

Appendix 2, Table 5. (See the method of working described below)

The working method below indicates how the permissibility is determined of a concentric system when using a

roof terminal.

1) Count the number of 45° and 90° bends required

2) Count the total number of whole metres of horizontal pipe length;

3) Count the total number of metres of vertical and/or sloping pipe length (roof terminal excluded).

4) In the first 2 columns of Table 5, look for the number of bends required and the total horizontal pipe length.

5) In the top row of Table 5, look for the required total vertical and/or sloping pipe length.

6) If you end up in a box with a letter, the concentric system chosen by you is permissible.

7) Use Table 6 to determine how the appliance should be adjusted

5.8.3Placingtheconcentricsystem

!Caution

• Maintain a distance of at least 50 mm between the outside of the concentric system and the walls and /or

ceiling. If the system is built in (for instance) a cove, it should be made with non combustible material all

around it;

• Use heat-resistant insulation material when passing through combustible material;

• The rosette of the wall terminal is too small to seal the opening when passing through combustible material.

That is why you should first apply a sufficiently large heat-resistant intermediate sheet to the wall. Then, the

rosette is mounted on the intermediate sheet.

The roof terminal can end in a sloping and a flat roof.

The roof terminal can be supplied with a glue plate for a flat roof or with a universally adaptable tile for a sloping

roof.

!Caution

Some heat-resistant insulation materials contain volatile components that will spread an unpleasant smell during

a longer period; these are not suitable.

Place the concentric system as follows:

Build the system up from (the flue spigot of) the appliance.

Connect the concentric pipe pieces and, if necessary, the bend(s).

On each connection, apply a clip binding with silicon sealing ring.

Use a self-tapping screw to fix the clip binding to the pipe on locations that cannot be reached after installation.

Attach the concentric system with sufficient fastening brackets, so that the weight is not resting on the appliance.

Observe the following;

• Place the first fastening bracket 0.5 metre from the appliance, at the most.

• Place a fastening bracket maximum 0.1 metre from each bend, if the bends are more than 0.25 metre away

from each other. If two bends are closer to one another than 0.25 metre, 1 fastening bracket between these

bends will be sufficient.

• At least every 1 metre, place a fastening bracket at slanted and horizontal sections.

• At least every 2 metres, place a fastening bracket at vertical sections.

Fasten a roof terminal with anchor cables, if it protrudes more than 1,5 metres above the terminal.

Attach the wall terminal from the outside by means of four screws.

10

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Camino da interno popolari di altre marche

Brigantia

Brigantia 35-DVRS31N-2 Manuale del proprietario

Nordpeis

Nordpeis Bergen Manuale utente

Superior

Superior BCT2536TMN Manuale utente

Quadra-Fire

Quadra-Fire 5100I-GD-B Manuale utente

Renaissance

Renaissance RUMFORD 1000 Manuale utente

Lacunza

Lacunza IV-800 Manuale utente

Baxi

Baxi 940 Istruzioni per l’uso

Diamond Fireglass

Diamond Fireglass SS-O22 Manuale utente

HearthStone

HearthStone Windsor Bay 8830 Manuale di programmazione

Napoleon

Napoleon ASCENT B42 Manuale utente

Enviro

Enviro E33GI Manuale utente

Smeg

Smeg L30 FABE Istruzioni di montaggio

KEDDY

KEDDY K700 Manuale utente

Godin

Godin 3451 Manuale utente

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manuale utente

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manuale utente

Desa

Desa CCFPDFT Manuale operativo

Miles Industries

Miles Industries Vogue 1300IRN Manuale
