INSTALLATION/OWNER'S MANUAL

AM/FM/CD Receiver with Detachable Face

XDMA5280

TYPICAL FRONT-LOAD DIN MOUNTING METHOD

Removal Keys

Mounting Sleeve

Dashboard or

Mounting Kit

Head Unit

XDMA5280 INSTALLATION

Preparation

Please read entire manual before installation.

Before You Start

•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.

•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom

directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.

Getting Started

•Removetrimringfromunit.

•Remove2transitscrewslocatedontopoftheunit.

•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting

sleeve.

•Installmountingsleeveintoopening,bendingtabstosecure.

•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.

•Certainvehiclesmayrequireaninstallationkitand/or

 wiringharnessadapter(soldseparately).

•Testforcorrectoperationandslideinto

mountingsleevetosecure.

•Snaptrimringintoplace.

XDMA5280 INSTALLATION

Wiring Diagram

Rear Preamp Output

Connect to amplifier RCA input

Antenna Connector

RCA Cable

(sold separately)

AMP

BLUE

BLACK

RED

YELLOW

Remote Turn-On

Connect to amplifier or power

antenna. Insulate wire if not used.

Ground

Connect to vehicle

chassis ground.

Accessory

Connect to ignition

circuit or switched 12 volt source.

Memory

Connect to battery

circuit or constant 12 volt source.

Right Front

Gray/Black (-)

Gray (+)

Left Front

White/Black (-)

White (+)

Right Rear

Violet/Black (-)

Violet (+)

Left Rear

Green/Black (-)

Green (+)

10 AMP

AGC Fuse

FUSE

Whenreplacingthe

fuse,makesurenew

fuseisthecorrecttype

andamperage.Using

anincorrectfusecould

damagetheradio.

TheXDMA5280uses

one10ampATMfuse

locatedbesidethewiring

connector.

XDMA5280 OPERATION

Control Locations - Receiver

Release

Volume

Mute/Power

Tune/TrackDown

Source

Tune/TrackUp

Eject

USBPort

AuxiliaryInput

Preset6/FolderUp

Preset5/FolderDown

Preset4/Play/Pause

Preset3/Intro

Preset2/Random

Preset1/Repeat

Band/Select

Display/Escape

Audio/Menu

1 2 3 4 6 7

16 9

15 14 13 12 11 101718

110

2 11

3 12

4 13

514

615

7 16

817

918

XDMA5280 OPERATION

Control Locations - Remote

Display/ESC

Tune/TrackDown

Band/Select

Mute/Power

VolumeUp

Source

Tune/TrackUp

VolumeDown

Audio/Menu

1 6

2 7

4 9

456

XDMA5280 OPERATION

Press oranyotherbutton(exceptEJECT)toturntheunit

on. Press toturntheunitoff.

Press SOURCE toselectbetweenAM/FM,CDplayer,

auxiliaryinput,USBandoperationofiPod®/iPhone®.Modes

ofoperationareshowninthedisplay.

NOTE:CD,USBandoperationofiPodmodeswillnotappear

unlessaCDisinsertedorUSB/iPoddevicesareconnected.

TheXDMA5280offersa3.5mmportonthefrontpanel.

Usinga3.5mmmale-to-malecable,connectaudiodevice,

MP3player,etc.totheauxilaryinput.PressSOURCE to

selectAUX-INmode.

Adjustvolumeusingvolumeknob(00-46).

Press DISPtoselectbetweenclockanddifferenttypesof

information,suchasradiofrequency,CDtrack/elapsedtime

orMP3/WMAsonginformation.

Press RESETuponinitialinstallationorifabnormal

operationoccurs.Resetbuttonislocatedbehindthefront

panel.

Withtheuniton,pressandholdDISPuntiltheclockbegins

toflash,thenrelease.PressTUNE

toadjustthehours

and TUNE

toadjusttheminutes.PressDISP momen-

tarilytosavetheselectedtime.

Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency

spacingmode(10:00PM).InEuropeanfrequencyspacing

mode,theclockwilldisplay24-hourtime(22:00).

PressandholdAUDIO/MENUformorethan3secondsto

accessthesetupmenu.PressAUDIO/MENUmomentarily

toselectbetweenthemenufunctionsandrotatethevolume

knobleft/righttoadjustoractivatethedesiredfunction.

Power On/Off

Changing Modes

Auxiliary Input

Volume

Display

Reset

Set the Clock

12/24-hour Clock

Setup Menu

General Operation

XDMA5280 OPERATION

General Operation - Setup Menu

Menu Function Options Action

Auto Station

Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe

currentband.(Tuner mode only)

Local/Distance

Tuning

LOCALOFF Activatesdistancetuning(Tuner mode only).

LOCALON Activateslocaltuningforstrongstationreceptiononly(Tuner

mode only).

Tuner

Frequency

Spacing

FREQUSA ProgramstheunittoUSAtunerspacing.

(200kHzforFMand10kHzforAM).(Tuner mode only)

FREQEURO ProgramstheunittoEuropeantunerspacing.

(50kHzforFMand9kHzforAM).(Tuner mode only)

Selectable iPod

Control

IPODFULL ProgramstheheadunittoadvancedcontroloftheiPod/

iPhonedevice.(Operation of iPod mode only)

IPODBASIC

ProgramstheheadunittomanualcontroloftheiPod/iPhone

deviceandallowsmusictobecontrolledfromtheiPod/

iPhonedevice.(Operation of iPod mode only)

Clock

Display

CLOCKOFF Programsunittonotdisplaytheclockwhenthepowerisoff.

CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.

Auxiliary Input AUXON Enablesthefrontpanel3.5mmauxiliaryinput.

AUXOFF Disablesthefrontpanel3.5mmauxiliaryinput.

Beep

Confirmation

BEEPOFF Disablestheconfirmationbeep.

BEEPON Enablestheconfirmationbeep.

Programmable

Turn On Volume PRO-VOL# Programsunittoalwaysturnonataspecificvolume

(defaultisOFF).Anyvolumelevel1-46canbeselected.

Power on

Message

MSGOFF Disablespoweronmessage.(example:GOODMORNING)

MSGON Enablespoweronmessagetobedisplayed.

Scrolling

Option

SCROLL15S Programsunittoscrollinformationonceevery15seconds

(default).

SCROLLONCE Programsunittoscrollonce,thenshowthefirst10

charactersondisplay.

SCROLLON Programsunittoscrollcontinuously.

SCROLLOFF Programsunittoshowthefirst10charactersonthedisplay.

Illumination

Dimmer

DIMMERHI Programsunittothebrightestilluminationlevel.

DIMMERMED Programsunittothemiddleilluminationlevel.

DIMMERLOW Programsunittothedimmestilluminationlevel.

Demonstration

Mode

DEMOOFF Disablesthedemonstrationmode.

DEMOON Enablesthedemonstrationmessage.

XDMA5280 OPERATION

Press AUDIOmomentarilytoselectbetweenBass,Treble,

Balance,Fader,EqualizerandSourceVolumeLevel.

Press AUDIO until BASSappearsthenrotatevolumeknob

left/righttoadjust(-6minimum/+6maximum).

Press AUDIO until TREBLEappearsthenrotatevolumeknob

left/righttoadjust(-6minimum/+6maximum).

Press AUDIO until BALappearsthenrotatevolumeknob

left/righttoadjust(BALL12-BALR12).

BALEVENrepresentsequalbalance

Press AUDIO until FADERappearsthenrotatevolumeknob

left/righttoadjust(FADERF12-FADERR12).

FADEVENrepresentsequalfader

Press AUDIO until EQappearsthenturnthevolume knob

tocyclethroughthefollowingequalizationcurves:FLAT

(default),POP,JAZZ,CLASSIC,BEAT,ROCKandUSER.

AnymanualadjustmenttotheBassorTreblesettingsare

automaticallysavedasUSER.

Thesourcevolumelevelcontrolallowsagainadjustment

foreachaudiosource:AM,FM,CD,AUX,operationofiPod

andUSB.Setthesourcevolumelevelforeachmode,

dependingontherelativevolumeofeachaudiosource.

Tosetthesourcevolumelevel,pressAUDIOuntilSRC

LEVELappears.Afteronesecond,thecurrentmodewill

appearonthedisplay.Turnthevolumeknobtoadjust

theaudiolevelofthecurrentsource(-6minimum/+6

maximum).

Note: Onlythecurrentmodewillbeavailablefor

adjustment.Toadjustanothermodeofoperation,press

SOURCE untilthedesiredmodeisselected,thensetthe

sourcevolumelevelforthatmode.

Audio

Bass

Treble

Balance

Fader

Equalizer

Source Volume Level

General Operation

BASS TREBLE BALANCE FADER EQUALIZER SOURCE LEVEL

XDMA5280 OPERATION

Seek Tuning

Manual Tuning

Band

Storing and Recalling

Station Presets

Press TUNE

or TUNE

formorethanonesecond

toseektothenextstrongstation.

Press TUNE

or TUNE

momentarilytochange

radiofrequencyupordownonestepatatime.Pressand

holdtoadvancequickly.

Press BANDtoselectbetweenFM1,FM2,FM3,AM1and

AM2bands.

Upto18FMstationsand12AMstationscanbestored.To

storeastation,selectthedesiredbandandstation.Press

andholdthedesiredpresetbutton(1-6)formorethan

2seconds.Whenstored,thepresetnumberwillappearin

thedisplay.Thestationcanberecalledanytimebypressing

thecorrespondingpresetbutton.

AM/FM Tuner Operation

XDMA5280 OPERATION

Insert CD

Eject CD

Track Select

Fast Forward and Reverse

Pause

Intro

Repeat

Random

CD-R/CD-RW Compatibility

Withthelabelfacingup,insertastandardsizeCDintothe

CDslot.TheCDwillautomaticallybeginplayback.

Press EJECTtoejecttheCD.Theunitwillchangeto

previousmodeofoperation.Ifthediscisnotremoved

within10seconds,theunitwillreloadthedisc.Theunit

doesnothavetobeturnedontoejectCD.

Press TRACK

toskiptothebeginningofthenext

track.PressTRACK

toreturntothebeginningofthe

currenttrack.PressingTRACK

againskipstothe

beginningoftheprevioustrack.

PressandholdTRACK

or TRACK

tofastforward

orreverseatrack.

Press

totemporarilystopCDplayback.

Press

againtoresumeplayback.

Press INT toentertheIntromenu,thenturnthevolume

knobtoselectoneofthefollowingoptions:

•OFF-CancelstheINT function.

•ALL-Playsthefirst10secondsofeachtrack.

Press RPT toentertheRepeatmenu,thenturnthevolume

knobtoselectoneofthefollowingoptions:

•ALL-PlaysalltracksonCD.

•TRACK-Continuouslyrepeatsselectedtrack.

Press RDM toentertheRandommenu,thenturnthe

volumeknobtoselectoneofthefollowingoptions:

•OFF-CancelstheRDM function.

•ALL-Playsalltracksinrandomorder.

SomeCD-RsandCD-RWsmaybeincompatiblewiththis

unit,dependingonmediatypeandrecordingmethod.In

addition,thefollowingCDsmaybeincompatiblewiththis

unit:

CDsexposedtoextremetemperaturesordirectsunlight

forextendedperiodsoftime,CDsrecordedinwhicha

recordingsessionfailedorare-recordingwasattempted

and,orencryptedorcopy-protectedCDswhichdonot

conformtotheaudioCD-DAredbookrecordingstandard.

CD Player Operation

Altri manuali per XDMA5280

Indice

Altri manuali Dual Ricevitore per auto

Dual

Dual DXDM280BT Istruzioni operative

Dual

Dual DV714BH Istruzioni operative

Dual

Dual XDVDN8290 Istruzioni operative

Dual

Dual XDVDN9131 Istruzioni operative

Dual

Dual XD250 Manuale utente

Dual

Dual SD XDMA6370 Guida alla configurazione

Dual

Dual MXD105 Istruzioni operative

Dual

Dual DVN927BT Istruzioni operative

Dual

Dual XDMA6540 Istruzioni operative

Dual

Dual XD5220 Istruzioni operative

Dual

Dual XDMR7700 Istruzioni operative

Dual

Dual XDVDN8290N Istruzioni operative

Dual

Dual XDVD8183 Istruzioni operative

Dual

Dual MXD426BT Istruzioni operative

Dual

Dual MCD139BT Istruzioni operative

Dual

Dual XD5120 Istruzioni operative

Dual

Dual XDVD210 Istruzioni operative

Dual

Dual XDVD1170 Manuale utente

Dual

Dual XDMR7700 Istruzioni operative

Dual

Dual DSA1007 Istruzioni operative

Dual

Dual XDMA450 Manuale utente

Dual

Dual XD7600 Istruzioni operative

Dual

Dual XD230M Istruzioni operative

Dual

Dual DSA2062 Manuale utente

Manuali Ricevitore per auto popolari di altre marche

Motorola

Motorola VWA63 Manuale utente

Nextar

Nextar D3201 Manuale utente

Alpine

Alpine CDE-163BT Manuale utente

Pioneer

Pioneer DEH-P645R Manuale utente

Axxera

Axxera XDMA7600 Istruzioni operative

XM OnyX Manuale utente

Sound Storm

Sound Storm STM93R Manuale utente

Soundstream

Soundstream VIR-5000 Manuale utente

Avson

Avson MKT Platform Manuale utente

Sony

Sony MEX-1HD - Audio Library System Manuale utente

Pioneer

Pioneer DVH-P500UB Manuale utente

JVC

JVC KD-AHD69 Manuale utente

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuale utente

Sony

Sony CDX-4160 - Cd Receiver Manuale utente

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuale utente

VDO

VDO CD 2253 Manuale utente

Volvo

Volvo 13 84 580 Manuale utente

ZENEC

ZENEC ZE-160DVD Manuale utente
