Power Dump Dolly™
Contents:
Introduction 1
Terminology: 1
Steps: 3
Step 1: Place trash can onto the Power Dump Dolly™3
Step 2: Place the Power Dump Dolly onto the dumpster 3
Step 3: Lift trash into the dumpster 4
Step 4: Return carriage to the floor 4
For more information: 5
MANDATORY SAFETY INFORAMTION……………………………………………………………….6
Introduction:
This set of instructions focuses on the Power Dump Dolly and the procedure
it entails to operate it successfully. It will educate any individual on how to
safely empty a trash can, or the equivalent, into a 4 yard, 6 yard, or 8 yard
dumpster with a edge height of 53” or less, or onto a trailer. Without the
control and safety of a Dump Dolly, serious injury can occur when handling
heavy loads above the knees and shoulders. The Power Dump Dolly was
designed in 2012 by Shay Scott, founder of Dump Dolly LLC, to better the
health of individuals who manually lift heavy cans of waste in a commercial
or non-commercial environment.
Terminology:
●Nose Plate- Metal attached to the bottom of the dolly where can is
placed.
●Elastic Cord- Secures can to the dolly and is found on the nose plate.
●Trash Can Clip (anchor)- Adjustable clip that allows can to be attached
securely to the entire dolly. Prevents can from falling into dumpster.
Not intended to use to pull the trash can and dolly backwards.
●Trash Can Clip Knob- Tightens the trash can clip to secure can. Found
behind trash can clip in back of the dolly.
1
Electric
●Dumpster Hooks- Orange/Black hooks attached to the top of the dolly
to place on rim of the dumpster.
●Dumpster Latch (vary by models)- Used for 8 yard dumpsters to
prevent dolly from falling forward instead of onto the dumpster.
2
Electric
Steps:
Step 1: Place can onto the Power Dump Dolly
1. Move nose plate under the can OR place can onto the nose plate.
2. Place the elastic cord around the base of the can.
3. Loosen the trash can clip knob.
4. Lift the trash can clip up, then down and secure to the rim of the can.
5. Tighten the trash can clip knob.
*Note: Do not over tighten.
3
Electric
Step 2: Place the Power Dump Dolly onto the dumpster
1. While holding the trash can, lean the Dump Dolly backwards onto the
leading edge of the dumpster and allow the dumpster latch, located
near dumpster hooks, to fall in place against the dumpster lip.
Step 3: Lift trash into the dumpster
1. Press the “IN” button on the stationery button near the handle to raise
the carriage. Up motion will automatically stop at the top.
2. Manually lift the attached carriage with container attached, and dump
trash into the dumpster.
Step 4: Return carriage to the floor
1. To return can and carriage to the bottom, press the “OUT” button until
the carriage is back at the bottom then release button. (see safety
note on page 6).
2. Carriage will automatically stop when at the bottom. Release the
button. Caution: always return carriage to the bottom before
removing from dumpster!
3. DO NOT OPERATE POWER DOLLY USLESS IT IS LEANING ON THE
DUMPSTER AS INTENDED. WHEN OPERATING IN THE UPRIGHT
POSITION, INJURY AND DAMAGE TO DUMP DOLLY CAN INCUR.
4
Electric
Maintenance
The battery should be charged nightly with the enclosed maintainer/charger.
Connect the charging wire on the Dump Dolly to the connecting end of the
maintainer/charger. Then just plug in the charger to a 115/120 volt outlet.
Indicator lights on the maintainer/charger will let you when charging or
charged. A fully charged battery will do the job of operating the motor for
many fully loaded lifts. The weight of each load and the frequency of use
will determine if the Dump Dolly should be charged more often than once in
any 24 hour period.
The four plastic carriage wheels are not self lubricating and may need to be
occasionally lubricated with a good quality spray or liquid lubricant.
Lubricate only when necessary.
5
Electric
For more information:
For more detailed instructions, go to www.DumpDolly.com or call
(325)227-8051 CST 9:00 am-4:00pm Monday through Friday
**Note: Drawings do not represent the current Power Dolly design but still
allow for understanding how it functions.
CAUTION !!!!
Operate only when leaning on
dumpster
THE POWER DUMP DOLLY HAS SAFETY SWITCHES
AT THE TOP AND BOTTOM TO STOP THE SLIDING
CARRIAGE WHEN IT REACHES THE LIMITS OF THE
TOP AND BOTTOM. WHILE HOLDING DOWN THE
BUTTON, SHOULD THE WINCH CONTINUE TO RUN
WHEN AT THE BOTTOM CAUSING SLACK IN THE
6
Electric
STRAP, THE WINCH WILL EVENTUALLY BEGIN TO
TIGHTEN AGAIN, IN THE OPPOSITE, BUT WRONG
DIRECTION. SHOULD THIS OCCUR, IMMEDIATELY
STOP PRESSING THE OUT (DOWN) BUTTON AND
PRESS THE IN (UP) BUTTON. THIS WILL
TEMPORARILY ALLOW SLACK IN THE STRAP UNTIL
THE STRAP BECOMES TIGHT AND THE CARRIAGE
STARTS GOING UP. RELEASE THE BUTTON AND
NORMAL USE CAN NOW RESUME.
FOR MORE INFORMATION, CALL325-227-8051
