Duotronpro S-6100 Manuale utente
www.stomshop.pro
Index
1. Introduction .....................................................................................................3
2. Product Information....................................................................................7
3. Technical Data.................................................................................................8
4. Install ...................................................................................................................9
5. Appearance and Name ........................................................................... 10
6. Front Panel Information......................................................................... 11
7. Changing Name .......................................................................................... 14
8. Temperature Setting ................................................................................ 15
9. Setup ................................................................................................................. 17
10. User Instruction........................................................................................ 20
11. Sintering Bridge Frameworks..................................................... 22
12. Trouble Shooting..................................................................................... 23
13. Warranty....................................................................................................... 28
- 1 -
www.stomshop.pro
1. Introduction
Thank you for purchasing S-6100 Furnace. S-6100 Furnace is subject to stringent quality
control procedures and patiently follow standard procedure. As results of our quality system,
S-6100 Furnace has better performance.
Also, S-6100 Furnace has sturdily and gracefully designed and programmed as user friendly.
This Operators Manual will explain the installation and operation of the oven as well as help
you get the most out of your new S-6100 Furnace. Please read carefully the instructions in
this manual for the best user experience.
⊙Attention
Please ensure that all safety information has been read by the operator before
using the oven.
- The Safety information is divided into two sections: Warning and Caution as
described below:
Warning
Violations of instructions may cause increased risk of serious
injury or death.
Caution
Violations of instructions may cause increased chance of
material waste or injuries.
- 2 -
www.stomshop.pro
Warning
1. Do not disassemble, repair or modify any part of the machine without prior approval
from an authorized technician. It could be out of warrantee and could cause damage,
electric shock or fire.
2. Ensure the oven is properly grounded to prohibit error or electrical hazard.
3. Do not cut or modify the power cord. Do not stretch or bend the power cord that
may cause electrical hazard.
4. Keep flammable materials away from the oven at all time.
5. Keep liquid away from the oven and avoid using the oven in damp environment to
prevent electrical hazard.
6. Ensure that the power plug is firmly plugged into the proper section. Unstable contact
may cause a electric spark and a fire.
7. Always wear heavy thermal insulated gloves when handling units with door open to
avoid burns.
8. Always ensure that the oven is completely stopped before working with the oven and
only operate the door when the machine is not in a cycle.
9. Do not touch or handing the power plug. It may cause an electric shock or a fire.
10. Carefully use tongs without touching wires when takeout Casting Ring from inside of
Furnace.
11. Do not place flammable materials or body inside of Furnace. It may cause a burn or a
fire.
- 3 -
www.stomshop.pro
Caution
1 Keep away from Furnace during operation. While running, furnace generates high
temperature.
2. Please handle the oven carefully to avoid damage. The furnace contain fragile parts.
3. Do not use in places with a lot of vibration.
4. Please read the manual and understand the instructions before using the oven.
5. Do not leave Furnace with a door open.
6. Keep away from flammable spray or materials from Furnace.
7. Do not install Furnace on place with gradient or rocking table
8. Do not pull a plug out with a strong force.
9. Keep temperature lower than 40 Celsius degree and sweep the dust out.
10. If detecting any defect during the operation, stop using and inquire manufacturer.
11. Use dry cloth and unplug power cords when cleaning Furnace. Do not use any
detergent.
12. While operating and right after, do not touch Furnace. Especially, do not touch the
upper part of furnace. It may cause a burn or a fire.
- 4 -
www.stomshop.pro
13. Keep away flammable materials from Furnace. It may cause a fire.
14. If Furnace is not in use, turn off switch to power off.
15. If Furnace is not in use for long term, pull out power plug.
16. Changing insulation:
Contact particulate from insulator with the eyes or skin
may cause irritation. Long term and inhaling a large quantity of the particulate
from insulator may cause respiratory disorders. Try protect skin, eyes and
respiratory organs with wearing safety glasses and mask.
<Compliance matters: wear long sleeves clothes, safety glasses, mask and using
vacuum machine. After work, wash unprotected skin with fresh water.>
17. Cracks in insulator should occur by a high temperature or a rapidly changing
temperature. However, cracks by thermal shock in insulator does not critically
affect Firing result. (In case of cracks on Tray insulator may affect on temperature.
In that case, need to change tray insulator through manufacturer or local
distributor.)
- 5 -
www.stomshop.pro
18. Do not start firing schedule without tray insulator. Starting schedule without
tray insulator may cause fire or damaging in furnace.
19. Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
- 6 -
www.stomshop.pro
Symbol Description
Symbol Description
This product fulfills the requirements of Directive
2014/35/EU on Low Voltage directive
Alternating current
Caution, hot surface
Caution, See Instructions for use
On (Power)
Off (Power)
PROTECTIVE CONDUCTOR TERMINAL
Electrical waste and electronics equipment
- 7 -
www.stomshop.pro
2. Product Information
(1) Characteristics
►Easy to operate and full set of features
►Easy-to use display provides all available information and setting control.
►10 custom temperature settings
►Maximum ramp up rate 25℃/min (15 oC/min over 900 oC)
►Compact size
►Double stock Trays in sintering chamber
(2) Main Functions
►User defined programs
►Progress indicates with LED lights
►Display remaining time.
►User can fine-tune temperature.
- 8 -
www.stomshop.pro
3. Technical Data
Temperature Sensor
Sensor Type
Sensor Range
Thermocouple R-type
0~1760℃
Main Controller
Voltage
Display
DC 12V
LED Display
I/O Controller
Voltage
Output
DC 12V
1 Ch. : DC Fan
General
Voltage
Fuse
Max. Current
Dimensions
Chamber
Max. temp.
Max. ramp rate
AC 230V, 50/60 Hz
30A / AC250V
10A
324 ㎜(W) x 391 ㎜(D) x 527 ㎜(H)
110 ㎜x 110 ㎜x 100 ㎜(h)
1600℃(For holding time longer than 30 min, 1580℃)
25℃/min (15℃/min over 900 oC)
