Duracell MN 1300 Manuale utente

This data is subject to change. Performance information is typical. Contact Duracell for the latest information

Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts

and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.

6/08

MN1300

Size: D (LR20)

Zn/MnO2

Nominal Voltage: 1.5 V

Impedance:

Typical Weight: 139 gm (4.9 oz.)

Typical Volume: 56.4 cm3

(3.4 in.3)

Terminals: Flat

Operating Temperature

Range: -20oC to 54oC

(-4oF to 130oF)

ANSI:

IEC: 13A

LR20

Dimensions shown are IEC/ANSI standards

TYPICAL DISCHARGE CHARACTERISTICS AT 21°C (70 °F)

Alkaline-Manganese Dioxide Battery

Berkshire Corporate Park

Bethel, CT 06801 U.S.A.

Telephone: Toll-free 1-800-544-5454

Internet: www.

duracell

.com

0.8

0.9

1.1

1.2

1.3

1.4

1.5

1.6

0 20 40 60 80 100 120 140 160

Service Hours

Voltage

2.2 OHMS

3.9 OHMS

5.1 OHMS

10 OHMS

1.5 mm

MIN.

( +)

9.5 mm

MAX

( –)

61.5

59.5 mm

34.2

32.3 mm

Operating Voltage

Storage Temperature

Range:

1.6 - 0.75V

-20oC to 35oC

136 m-ohm @ 1kHz

MN1300_US_CT.PDF

Page 1 of 2

TYPICAL CONSTANT CURRENT DISCHARGE

CHARACTERISTICS AT 21°C (70°F)

Discharge Current (Amps)

1.1 Volts

1.0 Volts

0.9 Volts

AT 21°C (70°F)

0.8

0.9

1.1

1.2

1.3

1.4

1.5

0 2 4 6 8 10 12 14 16 18

Service Hours

Voltage

2.00 A

1.5 A

1.0 A

0.75 A

TYPICAL DISCHARGE CHARACTERISTICS

This data is subject to change. Performance information is typical. Contact Duracell for the latest information

Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts

and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.

6/08

0.8

0.9

1.1

1.2

1.3

1.4

1.5

1.6

0 5 10 15 20

Service Hours

Voltage

1.1 V

1.0 V

0.9 V

TYPICAL CONSTANT POWER DISCHARGE

CHARACTERISTICS AT 21°C (70°F)

AT 21°C (70°F)

TYPICAL DISCHARGE CHARACTERISTICS

Berkshire Corporate ParkBerkshire Corporate Park

Bethel, CT 06801 U.S.A.Bethel, CT 06801 U.S.A.

Telephone: Toll-free 1-800-544-5454

Internet: www.duracell.com

1.1 V

1.0 V

0.9 V

AT 21°C AND 0°C

TYPICAL FLASHLIGHT TEST

Discharge Current (Amps)

Discharge Power (Watts)

Amp Hours

MN1300_US_CT.PDF

Page 2 of 2

0.25

0.5

100

0.50.5

Service Hours

MN1300

Size: D (LR20)

Zn/MnO2

Alkaline-Manganese Dioxide Battery

Berkshire Corporate ParkBerkshire Corporate Park

Bethel, CT 06801 U.S.A.Bethel, CT 06801 U.S.A.

Telephone: Toll-free 1-800-544-5454

Internet: www.duracell.com
