Introduction

Your New

LabelWriter

Congratulations on purchasing the DYMO

LabelWriter. After a short time, you will realize

how many of your daily tasks will be simpliﬁed

by using the DYMO LabelWriter.

Your LabelWriter will help you label ﬁle folders,

diskettes, video cassettes, mail packages, name

tags, and print Internet postage. With a little

imagination, you will think of hundreds of ways

to use the LabelWriter to make your job easier

and more efﬁcient.

Features

Software

The DYMO Label Software includes many

features that make it ﬂexible and easy to use.You

can set your default return address so that you do

not have to enter your address every time you

print a label.You can import graphics to use with

your labels, and select a default logo ﬁle so you

don’t need to import your logo each time you

create a new label. Of course, you can easily

override these default values at any time.

DYMO is even integrated into Microsoft

Word

so that you can easily print labels directly from

the Word toolbar.

Hardware

Your LabelWriter printer does not use toner, ink

cartridges, or a ribbon to print. The LabelWriter

uses advanced

thermal

printing technology to

print on specially treated labels.

Introduction

Thermal printing is based on the principle of heat

transfer from the thermal print head inside the

LabelWriter printer to the label. A row of

miniature heating elements on the print head is

pressed against the thermal labels. As a speciﬁc

element generates heat, a thermal reaction takes

place at that point on the label and the label

becomes discolored.

Labels

The only supplies you will ever need for this

printer are the labels. We recommend you only

use DYMO brand labels.

How long your labels will last depends on how

the labels are used. Thermal labels are susceptible

to fading in two ways:

Exposure to direct sunlight or ﬂuorescent light

for an extended period of time will cause fading.

Contact with plasticizers (for example labels

placed on plastic ring binders) will cause fading.

In the original packaging, the label shelf life is 18

months. When used for short-term applications

(envelopes, packages, etc.), fading has never

been reported as a problem. When used to label

ﬁles in a ﬁle cabinet, fading is very gradual over

many years. When applied to the edge of a

notebook that is then placed on a shelf in the sun,

fading begins within a few months.

When not in use, keep the labels stored in a cool

dry place and in the black bag in which they were

shipped to prolong label life.

Getting Help

Before making labels you should be aware of the

various help resources available to you. DYMO

Label Software comes with extensive Help.At

times in this manual, you will be directed to the

Help for more detailed discussion or instructions

on various topics.

To access the Help:

Click

LabelWriter Help

on the

Help

menu.

The Help is opened in your Web browser.

Chapter 1

Getting Started

DYMO Label Software is a general-purpose label printing

program that is speciﬁcally designed to help you get the

most out of your LabelWriter printer. The program

includes:

Many ready-to-use templates for common labels.

A built-in Designer you can use to create your own

templates.

A built-in List Manager that lets you save addresses or

other types of lists.

An add-in to print directly from Microsoft Word.

DYMO Label

Window

The following ﬁgure introduces the features available from

the DYMO Label Software main window

The ﬁrst time you open DYMO Label Software, you are

prompted to enter your return address and select a default

logo. See "User Information" on page 23 for instructions

on how to deﬁne your return address and select a default

logo ﬁle.

SaveOpen Print Paste

Open List

Manager

Open

Designer

Template

List

Label

Workspace

Rulers

Chapter 1: Getting Started

Creating

Your Own

Label

This tutorial guides you through the steps necessary to

create, print, and save a customized label. The best way to

start is to learn how to modify one of the label templates

included with the software. In this tutorial, you will

customize a shipping label.

You can only print this shipping label on wide print-head

printers. Although the LabelWriter EL40 and

LabelWriter 300 cannot print this shipping label, we

recommend that you follow along. This tutorial will give

you valuable information on how to access the various

text and design objects and change their attributes.

Choose a

Template

The ﬁrst step is to choose a label template as the basis for

your new label.

Click

DYMO Label Software

from the

Apple

menu to

start the program.

The

DYMO Label

window is displayed containing a

blank label.

In the

Label Templates

box, click the

Shipping with

graphic (30256)

template.

The 30256 label is shipped with the EL60, Turbo, 330,

and 330 Turbo model printers. If you have an EL40 or

300 model printer, select this label anyway, and follow

along with the exercise.

Creating Your Own Label

Notice that all templates are listed with the label type ﬁrst,

then any important objects on the template, and ﬁnally the

part number of the label.

The

Shipping with graphic (30256)

template is

displayed.

Changing the

Graphic

The next step in this tutorial is to customize the graphic.

As you will see, to modify an object’s attributes, you

simply

click the object. A dialog box appears that you can

use to change the object’s attributes.

To change the logo:

Click the telephone graphic that appears on the label.

The

Graphic Settings

dialog box appears.

Click the

File

option under

Select Image Source

The

Insert Image

button changes to read

Select File

3. Click Select File.

The Open dialog box is displayed listing the contents of

the default clipart directory which contains the Business,

Miscellaneous, and Sign folders.

4. Select the Miscellaneous folder and click Open.

Chapter 1: Getting Started

The contents of the Miscellaneous folder are displayed.

5. Select the Comput1.jpg ﬁle.

A preview showing the contents of the Comput1.jpg

graphic ﬁle is displayed.

6. Click the Open button.

The Comput1.jpg graphic is displayed in the Graphic

Settings dialog box.

7. Click OK.

The computer graphic is displayed on the label replacing

the telephone graphic.

Changing the

Return

Address

Next, you’ll change the return address.

To enter the return address:

1. Click the text in the label’s upper-right corner.

The Text Settings dialog box is displayed.

Altri manuali per LabelWriter DUO

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Dymo Etichettatrice

Dymo

Dymo MobileLabeler Manuale utente

Dymo

Dymo LabelManager 500 Touch Screen Label Maker Manuale utente

Dymo

Dymo DYMOLM200 Manuale utente

Dymo

Dymo LabelManager 280 Manuale utente

Dymo

Dymo LabelPOINT 100 Manuale utente

Dymo

Dymo 10199 Manuale utente

Dymo

Dymo LabelManager 420P Manuale utente

Dymo

Dymo LabelManager 450D Manuale utente

Dymo

Dymo Rhino 1000 Manuale utente

Dymo

Dymo Rhino 1011 Metal Tape Embosser Manuale utente

Dymo

Dymo LabelMANAGER 150 Manuale utente

Dymo

Dymo RhinoPRO 3000 Manuale utente

Dymo

Dymo LabelPOINT 100 Manuale utente

Dymo

Dymo PL100 Manuale utente

Dymo

Dymo MobileLabeler Manuale utente

Dymo

Dymo LabelManager 120P Guida all'installazione

Dymo

Dymo LabelPOINT 350 Manuale utente

Dymo

Dymo LabelManager 360D Manuale utente

Dymo

Dymo LabelPoint 250 Manuale utente

Dymo

Dymo Rhino Pro 3000 Manuale utente

Dymo

Dymo LabelWriter 300 Manuale utente

Dymo

Dymo LetraTag Plus LT-100T Manuale utente

Dymo

Dymo LabelWriter 450 Duo Label Printer Manuale utente

Dymo

Dymo Cool Clicks Labelmaker A2195a-US Manuale utente

Manuali Etichettatrice popolari di altre marche

Brother

Brother P-Touch 2420PC Manuale utente

newell

newell Dymo LabelManager 210D Manuale utente

Brother

Brother TD-4000 Manuale utente

U-Line

U-Line BROTHER H-8754 Manuale utente

Tharo Systems

Tharo Systems H-435+ Manuale utente

Brother

Brother E300 Manuale utente

Godex

Godex RT700 SERIES Manuale utente

ID Technology

ID Technology 252 Manuale utente

Labelmate

Labelmate MC-11 Manuale utente

CAB

CAB XD4M/300 Manuale utente

Avery Dennison

Avery Dennison Pathfinder 6057 Manuale di servizio

Brother

Brother P-touch PT-9700PC Manuale utente

TSC

TSC PEX1000 Series Manuale utente

Adkins

Adkins Label Master Manuale utente

Epson

Epson LabelWorks LW-400 Manuale utente

Primera

Primera 510212 Manuale utente

Brady

Brady BradyPrinter S3100 Manuale utente

DuraLabel

DuraLabel LabPRO Manuale utente
