Dynaluxx Luna LA325 Manuale utente
Important: Please read the instruction manual carefully prior to installation and keep it for future reference.
No.
1
2
Qty.
3
3
Usage
Fitting base
Rawl plug
Pic.
Accessories
Mounting: Wall or Ceiling
Light features:
Ra: >80
Life Time: 5 years
Light Source: LED SMD2835
Input: 220V-240V 50/60Hz
Ordering Code
LA325 18 STM
Power
(W)
18
Function
Description
On/off function LED
Product
Fitting Series
Luna LA325
LA325 18 SOF
18
Sensor-Dim function
LED
Luna LA325
LA325 18 SDM
18
Corridor function
(Tri-level dimming
function) LED Fixture
Luna LA325
Color Temperature Code
30K
40K
50K
CCT(K)
3000
4000
5000
Lumen
1450
1510
1590
Color temperature
Warm White
Natural White
Cool White
Code
OPERATING MANUAL
Luna LA325 - Sensor
Intelligent Lighting Solutions
C0/C180: C90/C270:
325mm
85mm
Installation
12
Twist the diffuser anticlockwise and
vertically remove it.
a. Cut off the power. Thread the input
cable through the rubber plug to the
fixture. Connect the L, N, Earth wire
based on the wiring diagram.
b. Knock the rawl plugs into the pre-
drilled holes on ceiling/wall. Wear
plastic washers on self-tapping
screws and tighten them to fix the
fixture on ceiling/wall.
Install the diffuser.
3
Caution
1. The product must be installed by professional technicians and the power supply must be cut off before installation.
2. The installation wiring must be at least 0.75mm2and wired in accordance with the latest IEE electrical regulations
or the national requirements.
3. Do not touch the electronic circuit and its components.
4. Contact an authorised technical service centre for any repairs required and use only original spare parts.
5. Do not touch LEDs while installing or maintaining.
6. The LED light source can not be replaced.
RoHS
SAA
IP20
1. Cut off the main power first
2. Don’t touch LEDs while maintaining or cleaning
3. Don't use chemicals to clean the fixture.
Environmental protection: waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority or retailer for recycling advice.
Maintenance
Detection Pattern
ceiling mounting pattern (m)
6m
12m
wall mounting pattern (m)
9m
4m
Sensor On/off(dimming) Setting Options
Sensitivity can be adjusted by selecting the combination
on the DIP switches for different applications.
I – 5s
II – 90s
III – 3min
IV – 10min
I – 0s
II – 10s
III – 10min
IV – +
Hold-time refers to the time period that the light remains
100% on if no more movement is detected.
This is the time period that the light remains at a low level
before it is completely turned off.
I – 100%
II – 50%
100%
50%
1
6 7
0s
10s
10min
+
I – Disable
II – 50Lux
III – 10Lux
IV – 2Lux
Daylight sensor
Different daylight threshold can be preset on DIP switches.
Light will always turn on upon movement if daylight sensor
is disabled.
Stand-by dimming level
Light can be dimmed to different levels after hold-time.
I – 10%
II – 30%
10%
30%
8
Disable
50Lux
10Lux
2Lux
4 5
5s
90s
3min
10min
2 3
Sensitivity
Stand-by period
Hold-time
2~50Lux
Stand-by period
0s~+
8
Hold-time
5s~30min
ceiling mounting pattern (m)
6m
12m
Wiring:
