Dynaudio Xeo Manuale utente

Owner’s Manual Xeo

English

2Dynaudio

All Apple products are trademarks of Apple Inc.

All Sony products are trademarks of Sony Electronics Inc.

All Sonos products are trademarks of Sonos Inc.

Logitech Squeezebox is a trademark of Logitech Inc.

An update to this manual may be necessary due to product improvements and new functions.

The latest version of this manual can be found on the Dynaudio website at www.dynaudio.com/xeo

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer‘s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A po-

larized plug has two blades with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide blade or the third prong

are provided for your safety. If the provided plug does not t into your outlet,

consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by the manufac-

turer, or sold with the apparatus. When a cart is used use caution when moving

the cart/apparatus combination to avoid injury from tip-over.

13. Unplug th is apparatus during lightning storms or when unused for long periods

of time.

4Dynaudio

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or

has been dropped.

15. WARNING: To reduce the risk of re or electric shock, this apparatus should not

be exposed to rain or moisture and objects lled with liquids, such as vases,

should not be placed on this apparatus.

16. To completely disconnect this eq uipment from the mains, d isconnect the pow-

er supply cord plug from the receptacle.

17. The mains plug of the power supply cord shall remain readily operable.

WARNING

RISK OF ELECTRIC SHOCK! DO NOT OPEN!

To reduce the risk of electric shock, do not remove the back panel and do not expose the

apparatus to rain or moisture. No user serviceable parts inside. Refer servicing to qualied

personnel. Never open the loudspeaker housing.

Safety information 7

Xeo loudspeakers 7

Power supply unit for Xeo Hub, Extender, and Link 7

Scope of delivery 8

Xeo loudspeakers (Xeo 4 or Xeo 6) 8

Xeo Hub 9

Xeo Extender 10

Xeo Link 10

Unpacking 11

Packaging material 11

Disposal 11

The Xeo system 12

Components 12

Combination examples 13

Remote control 14

Control elements 14

Xeo Hub 14

Display elements 15

Inputs 15

Other connections and control elements 16

Connection 16

Xeo loudspeakers 18

Connections and control elements 18

Division into audio zones 19

Cloth cover 20

Setting up 20

Connecting and adjusting 20

Switching on/standby mode 21

Selecting a Hub or input/autoplay function 21

Fixing the volume 21

Interface display 22

Xeo Extender 24

Connections and control elements 24

Connecting and establishing a link 25

Xeo Link 26

Connections and control elements 26

Connecting and establishing a link 27

Malfunctions 28

Technical data 29

Reminding 30

IC NOTICE 31

MPE Reminding 31

Table of Contents

6Dynaudio

Thank you

for choosing Dynaudio Xeo.

Xeo combines the latest wireless technology with impressive sound quality and makes listening to

music truly comfortable and easy.

The next few pages contain important information on connecting the system and its operation to

ensure perfect function and the best-possible sound quality.

We hope you have a great time listening to your favorite music,

Dynaudio

Safety information

Xeo loudspeakers

WARNING

Dangerous electrical voltage

If the loudspeakers are connected to the mains voltage, a dangerous electrical voltage is

present inside the speakers.

►Never open the loudspeaker housing.

►Do not operate defective loudspeakers and disconnect defective loudspeakers from the mains

voltage. Please contact your Dynaudio Xeo distributor if you have any problems. Distributor

addresses can be found in the Internet at www.dynaudio.com.

►Use the supplied power cable to connect the loudspeakers to the mains voltage. Make sure that

the power supply cable is not damaged; exchange it for a new one if it has been damaged.

Power supply unit for Xeo Hub, Extender, and Link

WARNING

Dangerous electrical voltage

When plugged in, a dangerous electrical voltage is present inside the housing of the supplied

Xeo power supply unit for Hub, Extender, and Link.

►Only use the delivered Xeo power supply unit.

►Never open the housing of the power supply unit.

►Make sure that the housing is not damaged. Exchange the power supply unit for a new one if it

has been damaged.

8Dynaudio

Scope of delivery

Xeo loudspeakers (Xeo 4 or Xeo 6)

2 Xeo loudspeakers (Xeo 4 or Xeo 6)

2 Xeo loudspeaker cloth covers

1 Xeo remote control

2 Xeo loudspeaker power cables (country-specic version)

1 Xeo rst time setup manual (quick guide for installation, not shown)





Xeo Hub

1 Xeo Hub

1 Xeo power supply unit with micro USB cable (country-specic version)

1 stereo analog cable (jack 3.5 mm – 3.5 mm)

1 stereo analog cable (RCA – RCA)

1 optical digital cable (Toslink – Toslink)

1 USB cable (USB – mini USB)

1 Xeo rst time setup manual (quick guide for installation, not shown)



 







10 Dynaudio

Xeo Extender

1 Xeo Extender

1 Xeo power supply unit with micro USB cable (country-specic version)

1 Xeo rst time setup manual (quick guide for installation, not shown)

Xeo Link

1 Xeo Link

1 Xeo power supply unit with micro USB cable (country-specic version)

1 stereo analog cable (RCA – RCA)

1 optical digital cable (Toslink – Toslink)

1 Xeo rst time setup manual (quick guide for installation, not shown)





 
