Dyson Purifier big+quiet formaldehyde Manuale utente

User guide

SV12 JN.00000 PN.000000-00-00

00.00.00 VERSION NO.01

Contents

Getting started

Assembling your machine

Positioning your machine

Connecting to the MyDyson™app

Connecting to your smart home

Power on/off

Continuous monitoring

Information menu

Auto purify

Set airflow speed and direction

Night mode and Sleep timer

Changing your HEPA filter

Reset your HEPA filter life

Changing your carbon filter

Reset your carbon filter life

Looking after your machine

Dyson purifier big+quiet

formaldehyde logo.

The Dyson purifier big+quiet

formaldehyde.

Power button on an LCD

screen, mesh filter cover

and integrated sensor

system on the side.

Getting started

Selective catalytic

oxidisation filter

Real-time LCD screen

LCD screen reports

indoor air quality in

real time.

Hidden wheels

Easy to manoeuvre across

a room – designed for

hard surfaces.

360º HEPA filter

Carbon filter

MyDyson™app

The MyDyson™app is essential

to get the most from your air

purifier. You can track current

and historical data, control your

machine from wherever you are,

set schedules and track filter life.

Remote control

Magnetically stores on

the front of the machine

for easy access.

Intelligent sensors

An integrated sensor

system detects pollutants

across a whole room.

Image of the 360°

HEPA filter in the

Dyson purifier big+quiet

formaldehyde.

The pleated carbon

filter is wrapped

around the central

body of the purifier.

Sensors are on the side

of the machine.

A real-time

LCD display

screen

reports

indoor air

quality.

Image of selective catalytic

oxidisation filter, that will

never need replacing.

Curved remote fits onto

front of machine.

Below the machine are hidden

wheels, for easy manoeuvrability

on hard surfaces.

Standby on/off

Remote control

Assembling your machine

Use both hands to lift your machine out of the box, by its base.

Your machine comes with a HEPA filter, carbon filter and

permanent catalytic filter. These are already installed in

your machine.

Lift the conic amplifier out of the box and place it on the top of

your machine.

Rotate the conic amplifier until it clicks securely into place.

Plug in and press the power button on the screen or

remote control.

Place the remote control on the front of your

machine with the buttons facing down.

The image demonstrates

the location of the standby

button and remote control.

Image demonstrates

how to assemble the

Dyson purifier big+quiet

formaldehyde’s conic

amplifier. Position and

twist. A click indicates a

secure lock.

Positioning your machine

Your machine is fitted with wheels to make it easier to move.

Position your machine on a level floor.

For the most effective purification, position your machine on the

edge of the room at least 1 metre from the wall, with the conic

amplifier pointing to the furthest point, along the wall.

You can also position your machine facing diagonally across

the room.

The purifier positioned on the edge of a room. A blue arrow shows the

conic amplifier direction, pointing to furthest point, along the wall.

The purifier positioned on the edge of a room. A blue arrow shows

the conic amplifier direction, pointing diagonally across the room.

Connecting to the MyDyson™app

Connecting to your smart home

Take full control with the MyDyson™app and access step-by-step setup and

support, control how and when your Dyson air purifier operates, monitor air

quality with visual updates and automatically keep up to date with the latest

software updates.

Download the MyDyson™app from the App Store or Google Play.

Open the app and follow the on-screen instructions to create a new account.

Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries.

App Store is a service mark of Apple Inc., registered in the U.S. and other countries.

Google Play and the Google Play logo are trademarks of Google Inc.

Available on

Android™ stores

The Android robot is reproduced or modified from work created and shared by Google and used

according to terms described in the Creative Commons 3.0 Attribution License.

Using Amazon Alexa

Ask Alexa to enable the Dyson skill – to help control your air purifier.

Set a routine that automates how your machine works with other

devices in your home.

Using Google Assistant

Control all of your connected purifiers with Google or set a routine to

automate how your machine works with other devices in your home.

Just say “Hey Google” to get started.

Using Siri

Connect your Dyson machine to Siri Shortcuts to control it by voice on

your Apple device.

Power on/off

Press the Stand-by on/off button on your Dyson air purifier or remote

control to start/stop your machine. It will continue to monitor the air quality.

Continuous monitoring is turned off by default. You’ll need to

activate it to see your historic AQ data.

With continuous monitoring active, your Dyson air purifier will

gather air quality and temperature information, displaying it

on the LCD screen and in the MyDyson™app.

Continuous monitoring on/off

You’ll be prompted to activate Continuous monitoring on the

MyDyson™app. To turn it on or off using the remote control,

press and hold the Auto mode button for five seconds. The LCD

screen will indicate the Continuous monitoring status.

Wi-Fi connectivity

Wi-Fi is turned on by default. To turn the Wi-Fi on or off, press and

hold the Stand-by on/off button on your machine for five seconds.

Continuous monitoring

The remote

control with the

Stand-by button

on the top left.

Information menu

Press this button to scroll through information monitored by your

Dyson air purifier.

Information about air quality, temperature, humidity and filter

levels is shown on the LCD screen.

When a particular type of pollutant causes air quality to decrease,

a symbol for the pollutant will show on the LCD screen.

Volatile organic compounds

VOCs are potentially harmful odours found in

cleaning products, paints and furnishings.

Wi-Fi

The current status of connection to the

Wi-Fi network.

Filters

Remaining filter life on LCD screen indicates

when filters need replacing.

Indoor temperature

Monitor the ambient temperature of the room.

Particulate matter (PM2.5)

Microscopic particles up to 2.5 microns in size,

suspended in the air we breathe. These include

smoke, bacteria and allergens.

Indoor humidity

The amount of water vapour in the air,

shown as a percentage.

Nitrogen dioxide and other oxidising gases

Potentially harmful gases released into the

air by combustion from cooking and vehicle

exhaust emissions.

Particulate matter (PM10)

Larger microscopic particles up to 10 microns

in size, suspended in the air we breathe.

These include dust, mould and pollen.

Indoor air quality

Air quality graph shows the last

12 seconds of data.

Formaldehyde (HCHO)

A common indoor pollutant released for many

years from furnishings, floorings and glue.

Carbon dioxide (CO2)

CO2can build up indoors without adequate

ventilation, which can impact cognitive function.

The remote

control with the

information button

highlighted on the

right hand side.

In Night mode, your Dyson air purifier will continue to clean the air

quietly, in a lower airflow speed with its LCD screen dimmed.

Press the Night mode and Sleep timer button to scroll through the

timer options.

Night mode and Sleep timer

Set your air purifier to Auto mode and the on-board sensors will

intelligently adjust the settings of the machine according to the air quality.

Air quality: your machine will pause when the target air quality has been

reached, switching on again when the air quality levels drop.

Airflow speed: the airflow speed will increase to its maximum until the

target air quality has been reached.

Increase or decrease the airflow speed and change air direction

from 0°to 50°using the remote or MyDyson™app.

Select Breeze mode by repeatedly pressing down on the airflow

direction button until it activates or by using the MyDyson™app.

Auto purify

Set airflow speed and direction 50°

25°

0°

The remote control

with the Auto mode

button highlighted on

the left hand side.

The remote control

with the airflow speed

toggle button on the

left hand side and the

airflow direction button

on the right hand side.

The remote control with

the Night mode button

on the bottom right and

Sleep timer button on

the bottom left.

Changing your HEPA filter

The MyDyson™app and the LCD screen will alert you when your filter life is

running low. Replacement filters are available to buy on www.dyson.com

Remove the conic amplifier

Slide the Release button on the back of the conic amplifier to unlock.

Lift the conic amplifier off your machine.

Lift the outer cover off the base of your machine.

Remove the filter

The HEPA filter is located in the outer cover. Press the filter release buttons

located on the inner rim and lift the outer cover off the filter.

Dispose of the filter.

Install a new filter

Remove your replacement filter from any packaging. Place the filter

on the base of your machine.

Place the outer cover over the filter and press down until it clicks

securely into position.

Place the conic amplifier on your machine and rotate until it clicks

securely in position.

Plug in, switch on and reset your filter life.

Reset your HEPA filter life

It’s important to reset the filter life after replacing your filter.

Press and hold the Night mode button on the remote control.

The LCD screen on your machine will count down from five,

until a tick appears on the screen.

The filter life has been reset and your machine is ready to use.

sec

Pressing the night mode

button on the bottom right

of the remote control for 5

seconds.

Sideways green arrow

indicates Release switch

to open the purifier, for

access to change the

HEPA filter. Upward

green arrows indicate

direction to lift the conic

amplifier and outer

cover off.

Zoomed in green

indicators highlight

the release buttons to

remove outer cover

off the filter. Green,

upward arrow shows

direction to lift the

cover.

The reassembly is

demonstrated by first

placing the filter on to

the base, followed by

the outer cover over the

filter. Finally, referring

to green arrow

direction, position and

twist the conic amplifier.

A click indicates a

secure lock.

sec

Changing your carbon filter

The MyDyson™app and the LCD screen will alert you when your filter life is

running low. Replacements are available to buy on www.dyson.com

Remove the conic amplifier

Slide the Release button on the back of the conic amplifier to unlock.

Lift the conic amplifier off your machine.

Lift the outer cover off the base of your machine.

Reset your carbon filter life

It’s important to reset your filter life after you have replaced your filter.

Press and hold the down airflow direction button on the remote control.

The LCD screen on your machine will count down from five, until a tick

appears on the screen.

The filter life has been reset and your machine is ready to use.

Remove the filter

The carbon filter is wrapped around the central body of your machine.

Pull each of the four clips towards you to release the filter.

Dispose of the filter.

Install a new filter

Remove your replacement filter from any packaging.

Wrap the filter around the base of your machine, fit the clips in

position and push each one to secure the filter.

Place the outer cover and HEPA filter back in position on the base of

your machine.

Place the conic amplifier on your machine and rotate until it clicks

securely in position.

Plug in and switch on, and reset your filter life.

The user should

pull each of the four

clips towards them

to release the filter

from the body of the

purifier. Green arrows

indicate the direction

to remove the filter

from the purifier.

Wrap carbon filter

around central body of

machine, as indicated

by green arrows. Use

the clips to secure into

position.

Sideways green arrow

indicates release switch to

open the purifier, for access

to change the carbon filter.

Upward green arrows indicate

direction to lift the conic

amplifier, HEPA filter and

outer cover off.

Holding down the

airflow direction button

on the right hand side

of the remote control

for 5 seconds.

Position and twist the

conic amplifier on to the

machine. A click

indicates a secure lock.

Place the outer cover

and HEPA filter back in

position on the base of

your machine.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Dyson Purificatore d'aria

Dyson

Dyson PH01 Istruzioni operative

Dyson

Dyson Pure Cool TP00 Manuale utente

Dyson

Dyson Pure Hot+Cool HP00 Manuale utente

Dyson

Dyson Pure Cool DP04 Manuale utente

Dyson

Dyson Pure Cool Link Manuale utente

Dyson

Dyson Pure Cool Manuale utente

Dyson

Dyson purifier cool Manuale utente

Dyson

Dyson Pure Cool DP04 Manuale utente

Dyson

Dyson purehot+cool link Manuale utente

Dyson

Dyson Pure Hot + Cool HP01 Manuale utente

Dyson

Dyson Pure Cool Manuale utente

Dyson

Dyson Pure Hot+Cool HP05 Manuale utente

Dyson

Dyson pure hot+cool HP06 Manuale utente

Dyson

Dyson Pure Hot+Cool HP04 Manuale utente

Dyson

Dyson Pure Hot + Cool Link HP02 Manuale utente

Dyson

Dyson purifier hot+cool gen1 Manuale utente

Dyson

Dyson Pure Cool Manuale utente

Dyson

Dyson TP02 Manuale utente

Dyson

Dyson Pure Hot+Cool HP04 Manuale utente

Dyson

Dyson pure hot+cool Manuale utente

Dyson

Dyson pure hot + cool link Manuale utente

Dyson

Dyson Pure Cool me BP01 Manuale utente

Dyson

Dyson Pure Cool TP04 Manuale utente

Dyson

Dyson Purifier Hot+ Cool Manuale utente

Manuali Purificatore d'aria popolari di altre marche

IKEA

IKEA UPPÅTVIND Manuale utente

Nash

Nash AP-1 PureSmart Manuale utente

LG PH-U450 Series Manuale utente

DeLonghi

DeLonghi DDSX 220WFA Manuale utente

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuale utente

Sharp

Sharp FU-40SE Manuale utente

Philips

Philips AC2721 Manuale utente

Hitachi

Hitachi EP-A3000 Manuale utente

TruSens

TruSens Z-2000 Manuale utente

Motorola

Motorola MBP87SN Manuale utente

Beko

Beko ATP 7100I Manuale utente

Carrier

Carrier INFINITY 1620 Manuale utente

AtmosAir

AtmosAir P2002 Manuale utente

Winix

Winix NK300 Manuale utente

Friedrich

Friedrich C-90A Istruzioni per l'uso e l'installazione

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuale utente

Base aire

Base aire 555 Pro Manuale utente

Champion

Champion CP25 Manuale utente

Dyson purifier big+quiet formaldehyde Manuale utente

Manuali Purificatore d'aria popolari di altre marche
