Earthworks Audio SR20 Manuale utente

For more information, please visit

www.earthworksaudio.com or call 1-603-654-2433.

VOCAL & INSTRUMENT CARDIOID MICROPHONE

SR20

1 Earthworks SR20 (with removable windscreen)

1 Microphone Clip

YOUR PURCHASE INCLUDES

Thank you for purchasing the

Earthworks SR20 Cardioid Microphone!

Before setting up the microphone, pull back all existing settings and EQ. By doing this, you will have a

baseline understanding of how our microphones sound, and will then be able to adjust accordingly.

Begin by removing all included components from the packaging. Make sure to mute any incoming

signal to speakers or headphones to avoid any loud “pops” when connecting.

Connect the microphone to an audio interface supplying 24-48V phantom power using a standard

XLR cable. Because of the microphone’s larger capsule size, please allow one minute for the

microphone to settle. (Plugging in the microphone while phantom power is turned on will not damage

the microphone, and will actually settle the microphone faster.)

To guarantee your microphone provides years of performance, follow these guidelines:

• Avoid touching the front protective screen.

• Never attempt to disassemble the microphone - it cannot be opened.

• Avoid extreme heat and condensing humidity. Allow the microphone to warm up when bringing it

in from the cold.

• Rough handling may damage the microphone even if no markings are visible.

• When not in use, keep the microphone in its bag.

GETTING STARTED

PROPER

MAINTENANCE

In order to remove the windscreen from the SR20, unscrew it from the microphone base. Do not

use excessive force while unscrewing. Doing so may damage the SR20.

IMPORTANT

NOTICE

SPECIFICATIONS SR20

Frequency Response 20Hz - 20kHz

Polar Pattern Cardioid

Sensitivity 20mV/Pa (-34dBV/Pa)

Power Requirements 24-48V Phantom, 10mA

Peak Acoustic Input 139dB SPL

Output XLR-3

Output Impedance 65Ω, balanced between pins 2 & 3

Minimum Output Load 600Ω, balanced between pins 2 & 3

Noise 16dB SPL (A weighted)

Dimensions 212mm x 22mm (8.4 x .860 inches)

238mm x 22mm (with windscreen)

Weight 135g (.3lb)

WARRANTY All Earthworks® products carry a limited warranty (parts and labor). Please register your warranty at:

earthworksaudio.com/register. If you have any problems with your Earthworks products, please contact our

warranty/repair department by email at: returns@earthworksaudio.com.

NOTE: This warranty only applies to Earthworks microphones purchased brand new. For microphones purchased/

received second-hand, please contact us via our website.

37 Wilton Rd. Milford, NH 03055

(603) 654-2433

sales@earthworksaudio.com

earthworksaudio.com

If you encounter issues while using your Earthworks Audio microphone, please make sure that:

• Your microphone is connected to an active power supply.

• Phantom power is being supplied to the microphone.

• Your microphone and XLR cable are well connected.

• The microphone is positioned at an appropriate distance from the sound source.

• External noise in your recording environment is kept to a minimum.

• Your recording space is at room temperature and free of dust.

If your issue persists after checking, please contact us via our website.

TROUBLESHOOTING

WE'RE HERE TO

HELP

For anything else, we're a phone call or email away. Please feel free to contact us by email at sales@

earthworksaudio.com, or by phone at (603)-654-2433.
