Eaton BladeUPS none Manuale utente

Powerware Series

Eaton BladeUPS Bar

Installation Guide

® ®

Special Symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of

electric shock symbol.

CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for

additional information, such as important operating and maintenance

instructions.

This symbol indicates that you should not discard the UPS or the UPS batteries

in the trash. This product contains sealed, lead‐acid batteries and must be

disposed of properly. For more information, contact your local recycling/reuse or

hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic

equipment (WEEE) in the trash. For proper disposal, contact your local

recycling/reuse or hazardous waste center.

Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates.

Pozidriv is a registered trademark of Phillips Screw Company. All other trademarks are properties of their respective

companies.

reproduced in any way without the express written approval of Eaton Corporation.

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality i

Table of Contents

1 Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safety Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Installation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Inspecting the Equipment 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setup 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tools Required 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Checking the Package Contents 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BladeUPS Bar Installation 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BladeUPS Bar Installation (Bottom Entry Wireway) 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BladeUPS Bar Installation (Top Entry Wireway) 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Specifications 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Service and Support 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Warranty 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Limited Warranty 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality 1

Chapter 1 Introduction

Paralleled Eaton BladeUPS®uninterruptible power systems (UPSs) use

the Eaton BladeUPS Bar to provide the required input and output

connections. The BladeUPS Bar installs in an industry standard rack and

is available in two models:

SBladeUPS Bar 4-High: Connects up to four of the BladeUPS modules.

SBladeUPS Bar 6-High: Connects up to six of the BladeUPS modules.

Figure 1 shows the installed BladeUPS Bar in a bottom entry and

top entry wireway configuration. The wireway fits into the bottom or top

6U of standard rack space.

Wireway

BladeUPS Bar BladeUPS Bar

Bottom Entry Wireway Top Entry Wireway

Figure 1. BladeUPS Bar Installed in Rack (BladeUPS Bar 6-High Shown)

INTRODUCTION

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality

Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions that you should follow during installation and

maintenance of the BladeUPS Bar. Please read all instructions before operating the

equipment and save this manual for future reference.

VIGTIGE SIKKERHEDSANVISNINGER

GEM DISSE ANVISNINGER

Denne manual indeholder vigtige instruktioner, som skal følges under installation og

betjening af BladeUPS Bar-enheden. Læs venligst alle instruktioner inden betjening af

udstyret og gem denne manual mhp. fremtidige opslag.

BELANGRIJKE VEILIGHEIDSINSTRUCTIES

BEWAAR DEZE INSTRUCTIES

Deze handleiding bevat belangrijke instructies die u dient te volgen tijdens de installatie en

het gebruik van BladeUPS Bar. Lees alle instructies voordat u de apparatuur in bedrijf neemt

en bewaar deze handleiding als naslagwerk.

TÄRKEITÄ TURVAOHJEITA - SUOMI

SÄILYTÄ NÄMÄ OHJEET

Tämä käyttöohje sisältää tärkeitä ohjeita, joita on noudatettava BladeUPS Bar-yksikön

asennuksen ja käytön yhteydessä. Lue kaikki ohjeet ennen laitteiston käyttöä ja säilytä ohje

myöhempää tarvetta varten.

CONSIGNES DE SÉCURITÉ IMPORTANTES

CONSERVER CES INSTRUCTIONS

Ce manuel contient des instructions importantes que vous êtes invité à suivre lors de toute

procédure d'installation et de fonctionnement de la BladeUPS Bar. Veuillez consulter

entièrement ces instructions avant de faire fonctionner l'équipement et conserver ce manuel

afin de pouvoir vous y reporter ultérieurement.

INTRODUCTION

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality 3

WICHTIGE SICHERHEITSANWEISUNGEN

AUFBEWAREN

Dieses Handbuch enthält wichtige Hinweise, welche Sie bei der Installation und Wartung

des BladeUPS Bar beachten sollten. Bitte lesen Sie alle Anweisungen des Handbuches

bevor sie mit dem Gerät arbeiten. Bewaren Sie das Handbuch zum Nachlesen auf.

IMPORTANTI ISTRUZIONI DI SICUREZZA

CONSERVARE QUESTE ISTRUZIONI

Il presente manuale contiene importanti istruzioni da seguire durante l'installazione e il

funzionamento di BladeUPS Bar. Leggere integralmente le istruzioni prima di utilizzare

l'apparecchiatura e conservare il presente manuale per futuro riferimento.

VIKTIGE SIKKERHETSINSTRUKSJONER

GJEM DISSE INSTRUKSJONENE

Denne håndboken inneholder viktige instruksjoner som du bør overholde ved montering og

bruk av BladeUPS Bar. Les alle instruksjoner før utstyret tas i bruk, og gjem håndboken til

fremtidig referanse.

INSTRUÇÕES DE SEGURANÇA IMPORTANTES

GUARDE ESTAS INSTRUÇÕES

Este manual contém instruções importantes que devem ser seguidas durante a instalação e

operação da BladeUPS Bar. Leia todas as instruções antes de operar o equipamento e

guarde este manual para consultá-lo futuramente.

ÂÀÆÍÛÅ ÓÊÀÇÀÍÈß ÏÎ ÌÅÐÀÌ ÁÅÇÎÏÀÑÍÎÑÒÈ

ÑÎÕÐÀÍÈÒÅ ÝÒÈ ÓÊÀÇÀÍÈß

Â äàííîì ðóêîâîäñòâå ñîäåðæàòñÿ âàæíûå èíñòðóêöèè ïî óñòàíîâêå è

îáñëóæèâàíèþ âíåøíåãî áàòàðåéíîãî ìîäóëÿ èëè óñòðîéñòâà ðàñïðåäåëåíèÿ

ýëåêòðîïèòàíèÿ. Ïåðåä ðàáîòîé ñ îáîðóäîâàíèåì ïðî÷òèòå âñå èíñòðóêöèè.

Ñîõðàíèòå äàííîå ðóêîâîäñòâî äëÿ äàëüíåéøåãî èñïîëüçîâàíèÿ.

INTRODUCTION

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality

INSTRUCCIONES DE SEGURIDAD IMPORTANTES

GUARDE ESTAS INSTRUCCIONES

Este manual contiene instrucciones importantes que debe seguir durante la instalación y el

funcionamiento del BladeUPS Bar. Por favor, lea todas las instrucciones antes de poner en

funcionamiento el equipo y guarde este manual para referencia en el futuro.

VIKTIGA SÄKERHETSFÖRESKRIFTER

SPARA DESSA FÖRESKRIFTER

Den här anvisningen innehåller viktiga instruktioner som du ska följa under installation och

användning av BladeUPS Bar. Läs alla instruktioner innan du använder utrustningen och

spara den här anvisningen för framtida referens.

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality 5

Chapter 2 Installation

This section explains:

SEquipment inspection

SBladeUPS Bar setup and installation

Inspecting the Equipment

If any equipment has been damaged during shipment, keep the shipping

cartons and packing materials for the carrier or place of purchase and file

a claim for shipping damage. If you discover damage after acceptance,

file a claim for concealed damage.

To file a claim for shipping damage or concealed damage: 1) File with

the carrier within 15 days of receipt of the equipment; 2) Send a copy of

the damage claim within 15 days to your service representative.

Setup

The BladeUPS Bar comes with all hardware required for installation in a

standard EIA or JIS rack with square and round mounting holes.

Tools Required

To assemble the components, you may need the following tools:

STorque wrench with the following attachments:

- Hex socket size 10 mm for M6 hex bolt

- Hex socket size 8 mm for M5 hex bolt

STorque driver with a Pozidriv®#2 for Pozidriv M4 screw

SLarge screwdriver or crowbar for lifting the bar in place

SPliers for installing cage nuts

INSTALLATION

Eaton BladeUPS Bar Installation Guide S164201723 Rev 2 www.eaton.com/powerquality

Checking the Package Contents

Verify that the following items are included in the package:

SOne of the following BladeUPS Bars:

BladeUPS Bar 4-High. A four-socket bar with (1) attached terminal block

assembly, (1) attached terminal block assembly bracket, and

(2) attached mounting brackets

BladeUPS Bar 6-High. A six-socket bar with (1) attached terminal block

assembly, (1) attached terminal block assembly bracket, and

(3) attached mounting brackets

SWireway main housing with (2) attached side brackets, (1) attached

terminal block housing, and (1) attached wireway access cover

SFront cover mounting panel

S(2) front covers

SFerrite assembly with 38 cm (15”) tie wrap

SThis user's guide

SPackaged hardware items:

-BladeUPS Bar 4-High. (12) M6 12 hex bolts, plus (1) extra

-BladeUPS Bar 6-High. (14) M6 12 hex bolts, plus (1) extra

- (4) M5 16 hex bolts

- (6) M6 12 pan-head screws, plus (1) extra

- (3) M4 8 pan-head screws

- (6) M6 split lock washers, plus (1) extra

- (4) M5 cage nuts

- (3) M6 hex nuts, plus (1) extra

BladeUPS Bar Installation

Follow the appropriate procedure for the BladeUPS Bar wireway

location:

SFollow the procedure “BladeUPS Bar Installation (Bottom Entry

Wireway)” on page 7 if you are installing the bar with the wireway at

the bottom of the rack.

SFollow the procedure “BladeUPS Bar Installation (Top Entry

Wireway)” on page 17 if you are installing the bar with the wireway at

the top of the rack.
