1. General Introduction

1.1 Brief Introduction

E72-2G4M20S1E is a multi-protocol 2.4GHz SMD wireless system-on-chip

module independently developed by TI based on CC2652P produced by TI. The

transmit power is 20dBm. It integrates an ARM microcontroller and

high-performance wireless transceiver. It uses industrial-grade 48MHz

high-precision low-temperature. Floating crystal oscillator.

The module leads all the IO ports of the single-chip microcomputer. The chip

comes with a powerful 48 MHz Arm ® Cortex ® -M4F processor, an internal

integrated power amplifier, powerful peripherals and up to 26 GPIOs, which can be developed in multiple directions.

CC2652P is a wireless microcontroller with great potential to become the future smart furniture, Internet of Things

transformation, and industrial automation.。

Because this module is a pure hardware SoC module, users need to program it before use.

1.2 Features

Built-in high-performance low-power Arm ® Cortex ® -M4F processor, clock speed up to 48MHz;

Rich resources,352KB FLASH，80KB RAM;

Support 1.9 ~ 3.8V power supply, power supply greater than 3.3V can ensure the best performance;

Transmitting power 20dBm;

Under ideal conditions, the communication distance can reach 700m;

The module contains 48M high-speed crystal/32.768k low-speed crystal;

Industry standard design, support long-term use at -40～+85℃;

2 pin cJTAG and JTAG debugging

Support wireless upgrade (OTA)

Wireless protocol:Thread, Zigbee ® , Bluetooth ® 5 Low Energy,

IEEE 802.15.4g, IPv6-enabled smart objects

(6LoWPAN), Wi-SUN ® , proprietary systems,

SimpleLink™ TI 15.4-Stack (2.4 GHz),

Dynamic Multiprotocol Manager (DMM) driver.

Receive sensitivity:–100 dBm for 802.15.4 (2.4 GHz),–105 dBm for Bluetooth 125-kbps (LE Coded PHY)

1.3 Application

Building automation

-Building security system-Motion detector, electronic intelligent door lock, door and window sensor, garage

door system, gateway

-HVAC-thermostat, wireless environment, sensors, HVAC system controller, gateway

-Fire safety system-Smoke and temperature detector, fire alarm control panel (FACP)

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

-Video surveillance- IP network camera

-Elevator and escalator-Elevator main, control panel of elevator and escalator;

Grid infrastructure

-Smart electric meters-Water meters, gas meters, electric meters and heat cost apportioners

-Grid communication-Wireless communication. Remote sensor application

-Other Alternative Energy-Energy Collection

Industrial Transportation-Asset Tracking

Factory automation and control

Medicine

Electronic Point of Sale (EPOS)-Electronic Shelf

Label (ESL)

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

2. Specification and Parameter

2.1 limit parameter

Main parameter

Performance

Remark

Min

Max

Power supply （V）

3.8

Voltage over 3.8V will cause permanent damage to module

Blocking power（dBm）

Chances of burn is slim when modules are used in short

distance

Operating temperature（℃）

-40

+85

Industrial grade

2.2 Operating parameter

Main parameter

Performance

Remark

Min

Type

Max

Operating voltage（V）

1.9

3.3

3.8

≥3.3 V ensures output power

Communication level （V）

3.3

For 5V TTL, it may be at risk of burning down

Operating temperature （℃）

-40

+85

Industrial grade

Operating frequency（MHz）

2400

2480

Power

Consum-ptio

TX current（mA）

106

Instantaneous power consumption @20dBm

RX current（mA）

7.3

Max TX power（dBm）

19.5

Receiving sensitivity（dBm）

-105

Bluetooth 125-kbps (LE Coded PHY)

Main parameter

Description

Remark

Reference distance

700m

Test condition：clear and open area, antenna gain:

5dBi，antenna height: 2 m，air data rate: 150 kbps

Crystal frequency

48MHz/32.768k

High speed 48MHz/low speed 32.768k

Protocol

Bluetooth 5 Low Energy

Zigbee

Thread

Package

SMD

Interface

1.27mm

Stamp hole

CC2652P1FRGZ

FLASH

352KB

RAM

80KB

Core

Arm ® Cortex ® -M4F

Size

28.7*17.5mm

Antenna

PCB on-board antenna

50 ohm impedance

Weight

1.9±0.1g

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

3. Size and Pin Definition

Pin No.

Item

Direction

Description

GND

Ground, connecting to power source referential ground

DIO_7

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_8

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_9

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_10

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_11

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

details)

DIO_12

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_13

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_14

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_15

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

GND

Ground, connecting to power source referential ground

GND

Ground, connecting to power source referential ground

JTAG_TMSC

Input/Output

JTAG_TMSC

JTAG_TCKC

Input/Output

JTAG_TCKC

DIO_16

Input/Output

Configurable general-purpose IO port, JTAG_TDO (see CC2652P1FRGZ

manual for details)

DIO_17

Input/Output

Configurable general-purpose IO port, JTAG_TDI (see CC2652P1FRGZ

manual for details)

DIO_18

Input

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_19

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

GND

Input/Output

Ground, connecting to power source referential ground

VCC

Module power supply is positive reference voltage, voltage range 1.9 ~

3.8V

DIO_20

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_21

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

GND

Input/Output

Ground, connecting to power source referential ground

RESET_N

Input

Reset pin, low level effective.

DIO_22

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_23

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_24

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_25

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_26

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_27

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_28

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

details)

DIO_29

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

DIO_30

Input/Output

Configurable general-purpose IO port (see CC2652P1FRGZ manual for

details)

GND

Input/Output

Ground, connecting to power source referential ground

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

4. Development and use

No.

Key words

Remark

Burning

program

The module is an SOC module, with its own GPIO port, and the program download uses the

XDS100 special downloader.

Test board

Our company does not provide a supporting board now.

5. Basic operation

5.1 Hardware design

It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible and

the module needs to be reliably grounded.

Please pay attention to the correct connection of the positive and negative poles of the power supply, reverse

connection may cause permanent damage to the module.

Please check the power supply to ensure that between the recommended supply voltage, if exceeding the maximum,

the module will be permanently damaged;

Please check the stability of the power supply. Voltage can not fluctuate greatly and frequently;

When designing the power supply circuit for the module, it is often recommended to reserve more than 30% of the

margin, so the whole machine is beneficial for long-term stable operation;

The module should be as far away as possible from the power supply, transformers, high-frequency wiring and other

parts with large electromagnetic interference;

Bottom Layer High-frequency digital routing, high-frequency analog routing, and power routing must be avoided

under the module. If it is necessary to pass through the module, assume that the module is soldered to the Top Layer,

and the copper is spread on the Top Layer of the module contact part(well grounded), it must be close to the digital

part of the module and routed in the Bottom Layer;

Assuming the module is soldered or placed over the Top Layer, it is wrong to randomly route over the Bottom Layer

or other layers, which will affect the module's spurs and receiving sensitivity to varying degrees;

It is assumed that there are devices with large electromagnetic interference around the module that will greatly

affect the performance. It is recommended to keep them away from the module according to the strength of the

interference. If necessary, appropriate isolation and shielding can be done;

Assume that there are traces with large electromagnetic interference (high-frequency digital, high-frequency analog,

power traces) around the module that will greatly affect the performance of the module. It is recommended to stay

away from the module according to the strength of the interference.If necessary, appropriate isolation and shielding

can be done;

Try to stay away from some physical layers such as TTL protocol at 2.4GHz , for example: USB3.0;

The mounting structure of antenna has a great influence on the performance of the module. It is necessary to ensure

that the antenna is exposed, preferably vertically upward. When the module is mounted inside the case, use a good

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual

antenna extension cable to extend the antenna to the outside;

The antenna must not be installed inside the metal case, which will cause the transmission distance to be greatly

weakened.

5.2 Software writing

The core of this module is CC2652P, and users can operate according to the CC2652P chip manual.

Note: The chip used in the module is in DC/DC mode

The module comes with our radio frequency switch, please operate strictly according to the truth table.

Truth Table:

DIO_6

DIO_5

Transmit(TX)

Receive(RX)

Low

High

OFF

High

Low

OFF

Burning program: The module is an SOC module and comes with a GPIO port. The program download uses the

XDS100 special downloader.

Program download interface definition:

E72 Pin

XDS100

Interface

JATG_TMSC

TMS

JTAG_TCKC

TCK

RESET_N

SRSTN

GND

DGND

VCC

TVD

Indice

Altri manuali Ebyte Modulo wireless

Ebyte

Ebyte E70-868T14S Manuale utente

Ebyte

Ebyte E07-900M10S Manuale utente

Ebyte

Ebyte E280-2G4T12S Manuale utente

Ebyte

Ebyte E72-2G4M05S1G Manuale utente

Ebyte

Ebyte E30-433T20S Manuale utente

Ebyte

Ebyte E01C-ML01SP2 Manuale utente

Ebyte

Ebyte E49-900M20S Manuale utente

Ebyte

Ebyte E220-900M22S Manuale utente

Ebyte

Ebyte E220-900MM22S Manuale utente

Ebyte

Ebyte E220P-400T22S Manuale utente

Ebyte

Ebyte E49-400M20S4 Manuale utente

Ebyte

Ebyte E104-BT20 Manuale utente

Ebyte

Ebyte E22-400T30S1C Manuale utente

Ebyte

Ebyte E32-433T20S1 Manuale utente

Ebyte

Ebyte E106-868G27P2 Manuale utente

Ebyte

Ebyte E72-2G4M02S2B Manuale utente

Ebyte

Ebyte E104-BT54S Manuale utente

Ebyte

Ebyte MA01-AXCX4020 Manuale utente

Ebyte

Ebyte E32-433T20DT Manuale utente

Ebyte

Ebyte E22-230TXXS Manuale utente

Ebyte

Ebyte E10 Series Manuale utente

Ebyte

Ebyte E840-TTL-GPRS03 Manuale utente

Ebyte

Ebyte E10-433MD-SMA Manuale utente

Ebyte

Ebyte E22-400T30S Manuale utente

Manuali Modulo wireless popolari di altre marche

Laird

Laird RM024 Manuale utente

Laird

Laird BT830-SA Guida rapida alla configurazione

Fibocom

Fibocom FM101-NA-20 Istruzioni per l'installazione

Waldmann

Waldmann EnOcean TALK MODUL G2 Manuale utente

Smartech

Smartech LBT-1.DO4 Manuale utente

Cooper Wiring Devices

Cooper Wiring Devices ESPIRE RF RFAPM Manuale utente

Yuga

Yuga CLM920 Manuale utente

Waldmann

Waldmann TALK Bluetooth Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions UC864-G Manuale di installazione

Quectel

Quectel SC690A Series Supplemento

Panasonic

Panasonic INDUSTRY PAN9028 Guida rapida alla configurazione

LongSung Technology

LongSung Technology U9507E Manuale utente

Wistron NeWeb

Wistron NeWeb DNUR-S2 Manuale utente

RF-Star

RF-Star SimpleLink RF-BM-2652P1 CC2652P Manuale utente

CHIEF

CHIEF AVMW Manuale utente

Huawei

Huawei EM701 Manuale utente

SIYI

SIYI FTM30 Manuale utente

RF-Star

RF-Star RF-BM-4055B1L Manuale di istruzioni
