Edelkrone WING Manuale utente

TABLE OF CONTENTS

WHAT’S IN THE BOX & THE BASICS

MOUNTING YOUR WING AND A TRIPOD HEAD

PRECAUTIONS

1.

2.

3.

1. WHAT’S IN THE BOX & THE BASICS

3

2

1

1.

2.

1/4”-20 mounting screw

Safety lock 5.

3. 3/8”-16 mounting port

Friction adjustment

4. Reducer bushing/adapter* x2

4

5

*1/4”-20 to 3/8”-16 mounting screw adapter and 1/4”-20 reducer bushing

for mounting port are provided.

DISCLAIMER

edelkrone cannot be held responsible for damage caused by improper use or modiﬁcation

of the product.

For more information and tips about your Wing, please watch

the user’s manual videos at: http://edel.kr/wng

www.edelkrone.com

2. MOUNTING YOUR WING AND A TRIPOD HEAD

A detailed video explaining the mounting process can be found at:

http://edel.kr/wng

Align your Wing with your

tripod’s 3/8”-16 screw.

Rotate clock-wise holding Wing

by the textured base.

If you’re using a tripod head with

a 3/8”-16 mounting port, you will

need to attach the included

adapter.

Mount the tripod head over

Wing by rotating clock-wise.

1.

2.

3.

4.

2

1

3

4

Do not try to tighten your Wing by holding its body. (Use textured base ring to

tighten)

3. PRECAUTIONS

Lock your Wing while not in use for safety.

A detailed video explaining the precautions and warnings can be found at:

http://edel.kr/wng

Before operating your edelkrone,

please watch the user’s manual video from the link below

http://edel.kr/wng

WING

USER’S MANUAL
