Eden E300 NEVER COMPROMISE Manuale utente

Eden E Series Amplifier

E300

NEVER COMPROMISET M

Quick Start Guide

Thank you for choosing Eden.

We hope that this product provides you with not only years of faithful service, but also the inspiration and capability

to take your music and express yourself in your own way.

At Eden we realize that having the right gear can mean the difference between having the condence and ability

to perform or not, so we strive to provide you with the tools that you need, whether at home, in the studio or in a

stadium.

All of our Ampliers, Speaker Cabinets, Speakers, and other items have been carefully designed and built to provide

you with optimum performance and maximum exibility, right down to component level. At Eden we work carefully

to ensure that everything down to the last screw used in a product has been chosen to deliver the best possible

product to you. In addition to using the best materials and processes, Eden is also conscious of the environment and

works hard to do everything it can to minimize its impact on the world we live in while still giving you the premium

equipment you should expect from us.

Please take time to read this quick start guide carefully before using your equipment. As with every piece of musical

equipment how you use it will affect the results you can achieve. By taking 5 minutes to understand these guidelines

you will not only ensure you get the best performance from your Eden product, but it may also prevent you from

accidentally damaging your unit through improper use.

We hope you continue to enjoy your equipment and welcome any comments or suggestions you may have for Eden,

after all, it is the creative inspiration of musicians and their music that drives all of us.

Thank you

The Eden Team

NEVER COMPROMISETM | 2

EDEN | E SERIES HEAD |

ENGLISH - 1

NEVER COMPROMISETM | 3

EDEN | E SERIES HEAD |

ENGLISH - 2

CAUTION!

The equipment you have purchased has been developed to provide you with a tool to achieve great tone and in some

cases deliver levels of volume that may be unsuitable for use in conned spaces or without hearing protection.

Every piece of Eden equipment is designed to perform exceptionally and just as with other high performance

products can in certain situations be capable of operating at levels that may be outside of the requirements or

capability of the user.

Use this equipment safely and considerately, the volume control on higher Wattage ampliers is your responsibility.

Your ears and those of others who are fortunate enough to hear you play are your most important instruments

required to enjoy your music.

If you experience any hearing loss or discomfort when listening to any loud music or activity which involves

excessive noise then for your own sake speak with a medical professional. As a Musician keeping your ears in good

working order is as important as being able to play your instrument, you only get one set of ears!

NEVER COMPROMISETM | 4

EDEN | E SERIES HEAD |

ENGLISH - 3

Congratulations on your purchase of this E Series Product. It has been designed specically to provide great bass

amplication tone in a compact portable package that truly allows you to explore your instruments ability.

Designed to provide an easy to use feature set to maximize playing enjoyment while minimizing the amount of

time you need to take to set up your sound. This short quick start guide provides hints to using your new amplier

product straight out of the box. For a more detailed and comprehensive guide visit the Eden website to view or

download the expanded edition User Handbook.

Manual Content:

1. Eden Introduction.............. 2

2. Caution ............................ 3

3. About /Content ................. 4

4. E300 Quick Start............... 5

5. Product Support................ 6

6. E300 Diagram ................... 7

NEVER COMPROMISETM | 5

EDEN | E SERIES HEAD |

ENGLISH - 4

E300 Front Panel Navigation:

1. Illuminated Eden logo - Illuminates when unit is switched on.

2. Line Out - Connect your amplifier to an external recording

device or to a mixing desk console.

3. Input - Connect your instrument here.

4. Gain - Controls the preamp volume (gain) of your amplifier.

5. Set Level LED - Indicates that the compressor circuit is active.

6. Enhance - Eden tailored EQ modifier adjust this to change your

overall EQ shaping.

7. Bass - Set at 12 o'clock this EQ provides a perfect flat Bass EQ

setting to the left will reduce the lower frequencies while turning to

the right will increase the lower frequencies.

8. Mid - Set at 12 o'clock this EQ provides a perfect flat Mid EQ

setting to the left will reduce the Mid frequencies while turning to

the right will increase the Mid frequencies.

9. Treble - Set at 12 o'clock this EQ provides a perfect flat High

EQ setting to the left will reduce the High frequencies while turning

to the right will increase the High frequencies.

10. Master - Controls the overall volume of your amplifier.

11. Aux In - Connect your CD player or other device here.

12. Phones - Insert standard headphones here for silent practice.

13. MP3 In - Connect your MP3 here using a 3.5mm jack plug.

14. Power Switch - Switch your unit off or on using this switch.

E300 Rear Panel Navigation:

1. AC Inlet - Connect your power cord here.

2. Speaker Output - Connect your speaker cable here.

E300 Quick Start Guide

The E300 produces 300 watts of pure power into 4 ohms (175 watts into 8 ohms) with 3dB of dynamic headroom. The preamp

section, with it's Enhance control, powerful tone control system and gentle auto-compression circuit allows you to achieve a wide array

of sounds.

NEVER COMPROMISETM | 6

Product Support

Your Eden equipment has been designed to provide you with years of faithful service however should you ever

need help with one of our products we have dedicated support teams all over the world. Visit your local Eden

dealer or contact your regional distributor for more details. Alternately visit our website to see if you can find a

solution www.edenamps.com

Simple rules to remember when using your Unit:

DO: Keep your unit clean and free from dust and obstructions to ensure adequate cooling and maximum

performance.

DO: Ensure you use the best quality cables and connections when using your unit for peak performance.

DON’T: Use this unit with any power cable or cord that was not supplied by Eden.

DON’T: Store liquids on or near the unit during use or otherwise or store in an overly humid environment.

DON’T: Modify of attempt to modify your unit, there are no user serviceable components inside. Any modication

or repair by an un authorised technician will void any warrantee oered in your region and can pose a serious risk

of electrocution or death.

DON’T: Use your unit for any purpose other than for which it was intended.

REMEMBER: Follow all the warnings and instructions which are provided in this handbook, always keep this

handbook for future reference.

Eden has tested or had the unit tested and approved for sale in your region. Any markings of approval and or

warning labels on an Eden product are provided to ensure you as a user are aware of the efforts Eden go to

ensure your product is suitable for use in your country. If you have any concerns about anything relating to

your product then please contact Eden immediately.

Please check your individual unit for the relevant markings and symbols which may apply.

EDEN | E SERIES HEAD |

ENGLISH - 5

NEVER COMPROMISETM | 7

NEVER COMPROMISET M

Eden is a part of the Marshall Amplication Group of companies. For more information or to nd your regional

Eden distributor visit our Website www.edenamps.com

Eden forma parte del grupo de empresas “Marshall Amplication “. Para más información o para encontrar un

distribuidor Eden en tu región visita nuestra página web www.edenamps.com

Eden fait partie de la famille de sociétés Marshall Amplication. Pour plus d'informations ou pour trouver votre

distributeur régional Eden, visitez notre site web www.edenamps.com

Eden ist Teil der Firmengruppe Marshall Amplication. Für weitere Informationen oder um einen Eden-Händler in

Ihrer Nähe zu nden, besuchen Sie unsere Website www.edenamps.com

EDENは、マーシャル・アンプ・グループに所属しています。製品についての詳しい情報やお住まいの地域のEDEN販売店について

は、EDENのウェブサイト〈www.EDENamps.com〉をご参照ください。
