Edgetech X-PAGE Manuale utente
EdgeTech Corp.
43 Cape cod lrvine, CA92620 U. S. A
TEL:1-866-218-7470 FAX:949-387-2939
750-E&F-31
USER S MANUAL
3
TABLE OF CONTENTS
INTRODUCTION 4
FEATURES 5
GETTING STARTED 6
Description of control buttons 6
Description of icons 7
Turning your pager on and off 8
Setting date & time 9
Choosing different alert modes 10
MESSAGES 12
Reading messages 12
Duplicate messages 13
Display 13
Erasing a message 14
Erasing all messages 14
Locking a message 15
OPTIONAL FUNCTIONS 18
Activating menu board 18
Setting alarm 20
Setting auto timer 21
Setting reminder alert 22
Entering greeting 23
Ready messages 24
Setting low battery alert 26
Setting script language 27
BATTERY INFORMATION 28
Low battery indication 28
Replacing battery 28
English User’s Manual 3
French User’s Manual 30
Getting Started
FEATURES
5
INTRODUCTION
4
FLEX Protocol
520 Characters Private Message Memory
(20 Slots x 26 Characters)
20 Ready Messages
(User Option On/Off)
AGC (Auto Gain Control) Function Available
Side View 1 Line Display (9 Segment)
Menu Display Available in English & French
Battery Backup When Replacing Battery
Date & Time Display
Receiving Time Stamping
Message Lock
Memory Full Indication
Message Error Indication
Individual Delete & Delete All
1 Daily & 2 Event Alarms
User Selectable 15 Melodies & 5 Tones
Vibration Alert
User Programmable Auto On/Off Timer
Reflective Backlighting Display
User Programmable Unread Message Alert
User Programmable Low Battery Alert
Duplicate Message Indication
User Programmable Headline
1 AAA Battery
FEATURESINTRODUCTION
Welcome to Pager World!
Your new pager provides you with many enhanced features,
such as 20 kinds of ready messages, 3 alarms, and English & French menu script.
Nine segment display makes easy to read messages.
This user’s guide gives instructions on how to use “X-PAGE” pager.
GETTING STARTED
7
GETTING STARTED
6
Tone Alert
Vibration Alert
Melody Alert
Pager Alarm
Locked Message
Full Memory Capacity
Auto On/Off Timer
Low Battery
Duplicate Message
Service Area Indicator
Continued Message
2. DESCRIPTION OF ICONS
Function Button
Enter menu set
Change alert mode Read Button
Read messages
Select menu
Stop alert or alarm
Function Button
Screen
Read Button
1. DESCRIPTION OF CONTROL BUTTONS
GETTING STARTED
9
GETTING STARTED
8
4. SETTING DATE AND TIME
Press . Backlight comes on. Then press
again. “Tone off?” or “Tone on?” is displayed.
Press repeatedly until “SET TIME” is displayed.
Press to select menu. The month indicator begins to
blink.
Press to move to the desired number.
Press to enter correct month. The date indicator
starts blinking.
Repeat above steps to set all fields.
NOTE ) Please adjust the date in Feb. of ordinary year
because the pager will go to Feb.29 regardless of leap year.
TURN OFF
To turn your pager off, press two times. When
“Tone off”
or “
Tone on” is displayed, press and
release to scan menu until “Power off” is
displayed.
Press to turn off.
TURN ON
Press for 2 seconds to turn your pager on.
Greeting message is displayed.
BACKLIGHT
Press to activate lamp.
Backlight remains on for 4 seconds before automatically turned off.
3.TURNING YOUR PAGER ON AND OFF
GETTING STARTED
11
GETTING STARTED
10
Press to display “Melody Set.”
Press to confirm. To scan sound, press .
The screen shows the number for each sound.
From 1 to 15 are melody alerts and from 16 to 20 are
beep alerts. When the screen displays an alert you
want, press to confirm.
The standby screen shows or , depending on
your choice.
You can choose one of 3 types of alert modes : beep, vibration or musical alert.
1. VIBRATION ALERT
Press to change the sound alert to vibration alert.
Backlight comes on.
Press again. “Tone Off” is displayed.
Press to confirm. The standby screen displays .
2. SOUND ALERT
X-page has 15 melodies and 5 tones.
To choose sound alert, press . Backlight comes on.
Press again. “Tone on” or “Tone off” is displayed.
5. CHOOSING DIFFERENT ALERT MODES
MESSAGES
13
MESSAGES
12
2. DUPLICATE MESSAGES
f pager receives a duplicate message, duplicate icon
displays on bottom of the screen.
3. DISPLAY
If the pager has 20 messages, “PAGE FULL” is displayed.
If
X-PAGE
receives more than 20 messages, the oldest
message gets deleted as new message is received.
When the pager has no message, the screen
displays “No Page” upon pressing of .
When an error occurs receiving a message, “E” is
displayed on the screen. “E”means error message.
1. READING MESSAGES
When a message is received, X-page either audibly alerts
(beep or musical alert) or vibrates and displays the message.
To stop vibration or audible alert, press any button.
If X-page has any unread message, the screen
displays “PAGE”. To see the current time, press .
The current time will be displayed 3 seconds later.
Press to display the message. The screen displays
the time the message was received.
Press again to display the message.
If the message is continued to next page, is displayed.
Press again to read the continued message.
01] the slot number
A : message address.
MESSAGES
15
MESSAGES
14
6. LOCKING A MESSAGE
You can protect messages from being erased by “ERASE ALL” function.
SET MESSAGE LOCK FUNCTION
Press . Backlight comes on.
Press and hold for 2 seconds.
The screen changes to “ERASE ALL”.
Press to display “SET LOCK FNC”. Then
press .
Press to turn the message lock “ON”.
Press to confirm.
4. ERASING A MESSAGE
After reading a message, press .
Backlight comes on.
Press again. You are prompted with “ERASE?”
display.
Press to confirm. If you want to exit this mode,
press .
5. ERASING ALL MESSAGES
“ERASE ALL” command erases all messages except the locked messages.
Press . Backlight comes on.
Press and hold for 2 seconds.
The screen automatically changes to “ERASE ALL”
Press to erase all messages.
MESSAGES
17
MESSAGES
16
Press . Backlight comes on.
Press again. “Unlock ?” is displayed.
Press to confirm.
LOCK A MESSAGE
Press repeatedly to display the message to be
locked.
Press . Backlight comes on.
Press again. The screen shows “ERASE?”.
Press . The screen displays “LOCK?”.
Press . The message is now locked. When you
read a locked message, you can see icon bottom
of the screen.
UNLOCK A MESSAGE
Press repeatedly to select the message to be
unlocked.
OPTIONAL FUNCTIONS
19
OPTIONAL FUNCTIONS
18
SECOND MENU BOARD
To activate the second menu board, press . Backlight comes on.
Press and hold for 2 seconds. At first the screen displays “Tone off” or “Tone on”, but
it changes to “ERASE ALL” , which is the first option of the second menu board.
As is pressed, the following menu is displayed one after another.
When the desired menu is displayed, press .
1. ERASE ALL 2. SET LOCK
5. READY MESSAGE
4. ENTER GREETING3. SET REMINDER ALERT
7. SET LANGUAGE6. LOW BATTERY ALERT
1. ACTIVATING MENU BOARDS
X-page has 2 menu boards.
FIRST MENU BOARD
To activate a menu board, press . Backlight comes on.
Press again. “Tone off ” or “Tone on” is displayed.
As is pressed, the following menu shown on the down is displayed one after
another.
When the desired menu is displayed, press .
1. SET ALERT 2. SET MELODY
4. SET TIME 6. SET AUTO TIMER
3. SET ALARM
5. POWER OFF
