Edimax BT-8500 Manuale utente

BT-8500

User Manual

08-2022 / V1.0

Contents

I. Product Information ..................................... 1

I-1. Package Contents ................................................1

I-2. Hardware Overview.............................................1

I-3. Supported System ...............................................1

II. Windows Plug-and-Play Installation ............. 2

II-1. Insert the USB Adapter........................................2

II-2. Bluetooth Plug-and-Play......................................2

II-3. Pair with the Bluetooth Device............................3

III. Windows Driver Installation.......................... 4

III-1. Insert the USB Adapter........................................4

III-2. Download the Driver ...........................................4

III-3. Pair with the Bluetooth Device............................5

IV. Frequently Asked Question (FAQ) ................. 8

V. More Information ......................................... 9

VI. Safety Instructions .......................................10

VII. Simplified EU Declaration of Conformity ......10

I. Product Information

I-1. Package Contents

I-2. Hardware Overview

I-3. Supported System

-Windows 8.1 / 10 / 11

-Linux

* Additional version information may be announced on the EDIMAX website.

Quick Installation Guide

USB Adapter

USB 2.0 Type A

Connector

II. Windows Plug-and-Play Installation

II-1. Insert the USB Adapter

Insert the USB adapter into your computer and

then switch on your computer.

Never use force to insert the USB

adapter.

Please disable all the existing Bluetooth

devices before inserting the device into

your computer. (Refer to IV. FAQ -> Q1)

II-2. Bluetooth Plug-and-Play

If your Windows OS supports Plug-and-Play, the Bluetooth icon will be

displayed on the bottom-right taskbar. (If Bluetooth icon doesn’t display,

please refer to IV. FAQ -> Q2)

Notice that if the Bluetooth icon does not show up,

continue to click the arrow-up icon.

If your Operating System does not recognize the USB

adapter, you need to install an additional driver on

your computer. Please refer to “Section III”.

Insert Plug-and-Play Pair

II-3. Pair with the Bluetooth Device

1. Click “Add a Bluetooth Device”.

2. Select existing Bluetooth devices from the list or click “Bluetooth & other

devices” to add an new Bluetooth device.

3. Select the Bluetooth device in “Paired” status you want to pair with and

click “Connect”.

4. Once the status is “Connected”, the connection is established.

III. Windows Driver Installation

III-1. Insert the USB Adapter

Insert the USB adapter into your computer and

then switch on your computer.

Never use force to insert the USB

adapter.

Please disable all the existing Bluetooth

devices before inserting the device into

your computer. (Refer to IV. FAQ -> Q1)

III-2. Download the Driver

1. You can find the USB adapter driver from the Edimax website.

https://www.edimax.com/download

If your computer can not access the Internet directly, please use an

Internet-Enabled device to download the driver instead.

2. Enter the model number and click to continue.

Insert Download Pair

3. Click on the model number.

Ensure the model number corresponds with your USB adapter.

4. Scroll down the web page and select the correct OS version. Move the

cursor to the “Download icon” and save the driver on the computer

desktop or a location you prefer.

Ensure you download the correct version.

Copy the driver to the USB flash drive first if you downloaded the driver on

another Internet-Enabled device and insert the USB flash drive to the

computer you will use the USB adapter

5. Move the cursor to the driver you just downloaded and extract the file.

III-3. Pair with the Bluetooth Device

1. To install the Bluetooth, once it’s uncompressed fully, access the folder

“Bluetooth” and click “Setup.exe” to continue.

2. Click ick “Next”to continue and follow the instructions on-screen until

installation is completed.

3. When the installation is completed, you will be asked to select whether you

wish to restart your computer now or later. Select “Yes” and click “Finish”

to continue.

4. Click the Bluetooth icon displayed on the bottom-right taskbar to pop

up the menu. (If Bluetooth icon is not displayed, please refer to IV. FAQ ->

Q2)

Notice that if the Bluetooth icon does not show up, click the arrow-up

icon.

5. Click “Add a Bluetooth Device”.

6. Select the existing Bluetooth devices from the list or click “Bluetooth &

other devices”to add new Bluetooth devices.

7. Select the Bluetooth device in “Paired” status you want to pair with and

click “Connect”.

8. Once the status is ”Connected”, the connection is established.

IV. Frequently Asked Question (FAQ)

Q1.How to disable the existing Bluetooth device?

A. Right-click the Windows Start button , and select the “Device

Manager”. Expand all the Bluetooth devices. Right-click on target device

and disable the bluetooth device one by one.

Q2.Why doesn’t the Bluetooth icon display on the Windows

taskbar?

A1. Click Windows Start button , and click “Setting”, select “Device

and other setting”, and set the stauts as “On”to enable thbluetooth

service.

A2. If the Bluetooth icon still doesn’t appear, you may need to install the

driver and try again. Please go to section III-2, to download and install the

driver and try again.
