Edimax BR-6428nS 9dBi Manuale utente

N300 Wireless Broadband Router

BR-6428nS +9dBi

Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors. Product specifications and design are subject to change without notice.

BR-6428nS +9dBi is a high performance yet cost-

effective wireless N device provides an exceptional

and advanced wireless performance.

300Mbps Wireless 802.11n Standard

The BR-6428nS +9dBi is a high-speed Wi-Fi solution

which supports IEEE 802.11b/g/n standards, and the

detachable 9dBi antennas provide significantly

improved coverage. When connected to other

802.11n devices, the BR-6428nS +9dBi can achieve

transmission rates of up to 300Mbps, making it

ideal for streaming HD video and online gaming.

Impressive performance and a competitive price

make the BR-6428nS +9dBi a cost-effective solution

for any home or small business environment.

Green Technology

Designed with the latest green technology, the BR-

6428nS +9dBi dynamically adjusts the power supply

according to the amount of wireless transference,

using up to 66% less power than usual while still

ensuring the highest standard of wireless

performance.

Wireless Internet Service Provider (WISP)

Connection Mode

With WISP support, the BR-6428nS +9dBi is able to

share an Internet connection from a wireless ISP

access point and convert it into a wired or wireless

network for multiple users in your home or office.

Power saving up to 66%

Detachable 9dBi high gain

antenna for better coverage

300Mbps transfer speed

HD IPTV

Other 3dBi Edimax 9dBi

Powerful Penetration through Walls and Floors

No Green Technology

300Mbs Router Edimax Green Technology

BR-6428nS +9dBi Router

Power Consumption (%)

100 Power

Saving

up to 66%

Green Technology for Power Saving up to 66%

WISP BR-6428nS +9dBi

Tablet Smart phone

Notebook / PC

Smart TV / IP TV

Shares WISP Wi-Fi Service for Multiple Users

To provide home and office users who need wider wireless coverage, the Edimax BR-6428nS +9dBi N300

Wireless Router employs two high gain detachable 9dBi antennas to enhance the wireless range and coverage.

100Mbps

LAN Ports 100Mbps

WAN Port

WPS / Reset Button

SV DC Power Port

9 dBi Detachable

Antennas

Easy One-Click Setup with WPS Button

FEATURES & TECHNICAL SPECIFICATIONS

FUNCTIONS HARDWARE INTERFACE MANAGEMENT

Supports AP, AP client, bridge, WDS and

repeater modes

Port Triggering for special applications

DDNS and SIP

Virtual server and DMZ hosting

MAC/IP filter and URL blocking

Static routing

UPnP architecture

VPN pass-through (IPSec/PPTP)

Schedule control

1 x RJ-45 WAN port

4 x RJ-45 Fast Ethernet LAN ports

LED Indicators: power, wireless, WAN,

LNK/ACT for LAN

2 x 9dBi detachable antennas

WPS / Reset button

Intuitive user interface

System status and security log

(web interface)

Firmware upgradeable

WAN SECURITY OUTPUT POWER & RECEIVE

SENSITIVITY

Supports WISP connection mode

Supports RJ-45 cable/xDSL modem

WAN protocol: PPPoE, static IP, dynamic

IP, PPTP, L2TP

NAT/NAPT IP sharing

64/128-bit WEP encryption and WPA-

PSK, WPA2-PSK security

DHCP server/client

QoS for critical operations

SPI anti-DoS firewall

11n: 16±1dBm,

11g: 16±1dBm

11b: 18±1dBm

11n (40MHz): -68dBm,

11n (20MHz): -71dBm,

11g: -74dBm,

11b: -87dBm

MEMORY HUMIDITY & TEMPERATURE CERTIFICATIONS

2MB NOR Flash

16MB SDRAM

10 –90% (Non-condensing)

0 –45oC

CE, FCC

POWER ADAPTER DIMENSIONS

5V DC, 1A 135(W) x 100(D) x 28 (H) mm

Antenna: 385 mm

NETWORK DIAGRAM

www.edimax.com

N300 Wireless Broadband Router

BR-6428nS +9dBi

9dBi

Wi-Fi Protected Setup (WPS) Button

The BR-6428nS +9dBi has a one-click Wi-Fi

Protected Setup (WPS) button to help you set up

and activate a secure wireless network in a snap.

Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors. Product specifications and design are subject to change without notice.
