Eduard Brassin Bf109F engine and fuselage guns Manuale utente

648 300 Bf109F engine and fuselage guns

435 21 Obrnice 170

Czech Republic

This product contains metal and resin detail parts for upgrading scale plastic models. When selecting this set make sure

that it is for the kit mentioned in product name as these sets are made specifically for that kit. When upgrading the model

some cutting or corrections may be necessary for parts to fit accurately. WARNING! This set contains small and sharp parts.

Work carefully in a ventilated and well-lit room. Safety glasses are recommended.

Tento výrobek obsahuje leptané a odlévané detaily pro úpravu a vylepšení plastikového modelu. Při výběru sady

kovových detailů zkontrolujte, zda je určena pro model, který chcete upravit. Model, pro který je sada určena, je uveden

u názvu výrobku. Pro přesnou aplikaci kovových a odlévaných dílů může být zapotřebí upravit díly upravovaného modelu.

POZOR! Sada obsahuje malé ostré díly. Pracujte ve větrané a dobře osvětlené místnosti. Doporučujeme použití

ochranných brýlí. Tento výrobek není vhodný pro děti mladší 14 let.

This product is not suitable for children

below 14 years of age.

0-14

LDPE

PAP BEST BRASS RESIN AROUND!

Mr.COLOR

AQUEOUS

GSi Creos (GUNZE)

C 33

C 81

H 12

H 33

FLAT BLACK

RUSSET

C 60

H 70

SEMI GLOSS BLACK

Mr.METAL COLOR

CHROME SILVER

MC211

C 92

RLM02 GRAY

1/48

For Eduard kit - pro stavebnici Eduard For Eduard kit - pro stavebnici Eduard

DARK IRON

MC214

SILVER

C 8

H 8

www.eduard.com

1/48 scale

R30 R31 R32 R33 R34 R41 R42

R43

6pcs.

R44

6pcs.

R45

R52 R53 R54

R136 R137

R48 R49

R46 R50 R51

R138

R55

R139

R140 R141 R142 R143 R144 R145

R146 R150 R151 R152

R147 R148 R149

SYMETRICAL ASSEMBLY

SYMETRICKÁ MONTÁŽ

REMOVE

ODSTRANIT

BEND

OHNOUT

OPTION

VOLBA

GRIND

OBROUSIT

REPLACE

NAHRADIT

DRILL HOLE

VRTAT OTVOR

REVERSE SIDE

OTOČIT

RYTÍ

SCRIBE THE PANEL AND HOLES

648 300 Bf 109F engine and fuselage guns page 2/8 Made in Czech Republic

C 60

H 70

RLM02 GRAY

C 8

H 8

SILVER

PE9+PE10

CORRECT

POSITION

R53

PE20

R49

R30

R52

R149

PE24

C 33

H 12

FLAT BLACK

PE24

PE12

CORRECT

POSITION

R50 R30

PE16

C 60

H 70

RLM02 GRAY

C 33

H 12

FLAT BLACK

C 92

SEMI GLOSS

BLACK

PE10

PE9

R32

R31

C 92

SEMI GLOSS

BLACK

C 92

SEMI GLOSS

BLACK

C 92

SEMI GLOSS

BLACK

R33

PE10

C 92

SEMI GLOSS

BLACK

R34

PE15

C 92

SEMI GLOSS

BLACK

R55

PE21

C 92

SEMI GLOSS

BLACK

C 60

H 70

RLM02 GRAY

C 92

SEMI GLOSS

BLACK

PE21

R152

PE21

R41

PE1

PE21

C 92

SEMI GLOSS

BLACK

C 33

H 12

FLAT BLACK

C 8

H 8

SILVER

C 92

SEMI GLOSS

BLACK

C 33

H 12

FLAT BLACK

R150

R151

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 92

SEMI GLOSS

BLACK

C 92

SEMI GLOSS

BLACK

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 8

H 8

SILVER

C 60

H 70

RLM02 GRAY

C 92

SEMI GLOSS

BLACK

www.eduard.com Made in Czech Republic648 300 Bf 109F engine and fuselage guns page 3/8

910

C 92

SEMI GLOSS

BLACK

R45

R46

C 60

H 70

RLM02 GRAY

C 8

H 8

SILVER

R48

R54

C 8

H 8

SILVER

wire

- 0,3mm

l - 4,5mm

wire

- 0,3mm

l - 4,5mm

R147

R146

R145

R143

R144

C 8

H 8

SILVER

R147

C 60

H 70

RLM02 GRAY

C 92

SEMI GLOSS

BLACK

C 33

H 12

FLAT BLACK

R149

R148

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

C 92

SEMI GLOSS

BLACK

C 60

H 70

RLM02 GRAY

C 92

SEMI GLOSS

BLACK

C 60

H 70

RLM02 GRAY

MC214

DARK IRON

MC214

DARK IRON

13 14

PE19

C 8

H 8

SILVER

PE2

C 33

H 12

FLAT BLACK

C 8

H 8

SILVER

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

PE17

PE3

PE22

www.eduard.com Made in Czech Republic648 300 Bf 109F engine and fuselage guns page 5/8

wire

- 0,3mm

l - 8mm

wire

- 0,3mm

l - 9,5mm

wire

- 0,4mm

l - 8,5mm

wire

- 0,5mm

l - 11,5mm

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

C 33

H 12

FLAT BLACK

wire

- 0,6mm

l - 35,5mm

CORRECT POSITION

wire

- 0,6mm

l - 20,5mm

R51

C 60

H 70

RLM02 GRAY

C 33

H 12

FLAT BLACK

wire

- 0,5mm

l - 7mm wire

- 0,3mm

l - 5mm

C 8

H 8

SILVER

15 16 17

C 8

H 8

SILVER

C 8

H 8

SILVER

wire

- 0,3mm

l - 25mm

C 8

H 8

SILVER

C 33

H 12

FLAT BLACK

1,1mm

0,3 mm

H41

R14

R14 R1

H4 H4

plastic plastic

plastic

R138

C 60

H 70

RLM02 GRAY

R136

C 60

H 70

RLM02 GRAY

648279

R141

LATE

R140

R136

C 60

H 70

RLM02 GRAY

EARLY

A B C

R141

R136

C 60

H 70

RLM02 GRAY

TROP

R142

PE27

PE25

PE26

648 300 Bf 109F engine and fuselage guns page 7/8 Made in Czech Republic

www.eduard.com

CORRECT

POSITION

PE14

R42

R139

PE23

PE6

PE7

PE11

PE13

PE8

PE5

R43

R44

6 pcs.

PE14

R43

PE23

PE18

C 60

H 70

RLM02 GRAY

C 60

H 70

RLM02 GRAY

C 60

H 70

RLM02 GRAY

C 81

H 33

RUSSET

C 60

H 70

RLM02 GRAY

MC211

CHROME SILVER

23 24

1 36 4

R136

R137

wire

- 0,4mm

l - 19,5mm

C 60

H 70

RLM02 GRAY

DECALS

PE4

C 60

H 70

RLM02 GRAY

C 60

H 70

RLM02 GRAY

? ?

R137

A B C

decal 4 - for Bf 109F-2

decal 5 - for Bf 109F-4
