Quick-Start Guide

SpeedStream 5667

USB/Ethernet DSL Modem

Before you begin:

Verify that the following items came with your DSL kit:

Documentation Software CD-ROM

USB/Ethernet

DSL Modem

USB cable RJ-11 DSL cable RJ-45 Straight-through

Ethernet cable

RJ-45 Crossover

(Xover) Ethernet cable

Line ﬁlter(s)

PCI Ethernet adapter Wall-mount line ﬁlter

Power supply

SpeedStream®

Safety andCertiﬁcations

xxxx

SpeedStream®

Safety andCertiﬁcations

xxxx

If you are installing the modem to use your USB port, you will need to provide your CD-ROM drive letter

during software installation. To ﬁnd the drive letter, double-click the My Computer icon on your desktop.

Look for the CD icon and note the letter next to it. This letter is your CD-ROM drive letter.

Two-to-one adapter(s)

Your service provider may include a wall-mount ﬁlter, two-to-one adapter(s), line ﬁlter(s), and an Ethernet

adapter in your DSL kit. If you received any of these items, follow the instructions provided in this guide for

basic installation. If you need further assistance installing these items, please contact your service provider.

SpeedStream®

Install Line Filters

Step

Two-to-One Adapter

Devices such as fax machines, caller ID boxes, or phones that share the same phone number as your DSL

account require a line ﬁlter, which prevents modem noise from disrupting the DSL signal on the phone line.

Filters can be in the form of a stand-alone line ﬁlter or a wall mount ﬁlter. A ﬁlter can also be plugged into

a two-to-one adapter if your DSL modem will share the same phone jack with another device.

If your DSL modem and another device will share the same phone jack, install a two-to-one adapter:

1. Plug adapter into the phone jack.

2. Plug a line ﬁlter into one of the sockets of

 the two-to-one adapter. The other socket will

 be used to connect the DSL cable.

3. Plug the telephone (or other device) cord

 into the line ﬁlter.

For each device that shares the DSL phone number:

1. Unplug the device’s cord from the phone jack.

2. Plug the ﬁlter into the phone jack.

3.  Plug the phone cord (or other device cord)

into the ﬁlter.

Stand-alone Line Filter

Wall Mount Filter

For a wall mount phone, install a wall mount ﬁlter:

1. Remove the phone.

2. Connect the wall mount ﬁlter to the wall plate.

3. Reconnect the phone.

2Choose an Installation Method

Step

Connect the DSL modem

DSLRESETUSBCONSOLE10BASE-T PWRPWR-

RJ-11 DSL cable

Install Ethernet adapter

You will need to install an Ethernet adapter if your computer does not already have one installed.

Refer to your Ethernet adapter manufacturer’s documentation for complete installation instructions.

Congratulations! You have completed the installation of your SpeedStream

® hardware.

There is no modem software installation required when using the Ethernet connection method.

Refer to your Internet Service Provider’s instructions for installing their software and/or connecting to the Internet.

Ethernet Installation Method

2A:

1. With your computer off, connect the Ethernet cable to the Ethernet port on the modem.

2. Connect the other end of the Ethernet cable to the Ethernet port on your computer.

3.  Plug the DSL cable into the DSL port on the modem.

4. Plug the other end of the DSL cable into the phone jack.

4a. If using a two-to-one adapter, plug the cable into the open socket.

5. Plug the power adapter into the power outlet and modem.

6.  Power on the computer. Power on the Modem.

Hub

Optional:

Use Crossover (Xover) cable

when connecting to a hub or

switch without an “Uplink” port

Power Supply

Internet Connection

w/two-to-one adapter

Ethernet Connection

to computer RJ-45

Straight-through

Ethernet cable

DSL RESET USB CONSOLE10BASE-T PWRPWR-

RJ-11 DSL cable

Power Supply

Internet Connection

w/two-to-one adapter

USB Installation Method

Congratulations! You have completed the installation of your SpeedStream®DSL modem

Refer to your Internet Service Provider’s instructions for installing their software and/or connecting to the Internet.

1. Connect the USB Cable to the USB port at the rear of the modem.

2. Connect the other end to the USB port on your computer.

3.  Plug the DSL cable into the DSL port on the modem.

4. Plug the other end of the cable into the phone jack.

4a. If using a two-to-one adapter, plug the cable into the open

 socket, which should already be connected to the phone jack.

5. Plug the power adapter into the power outlet and modem.

2B:

Connect the DSL modem

USB Connection

to computer

1. Insert the SpeedStream®Installation CD into your CD-ROM drive.

2. Click the “Start” button on the Windows taskbar.

3. Select “Run” from the Start menu.

4. Type “e:\ setup.exe” where “e” represents your CD-ROM drive.

Note your drive letter may not be "e."

5. Click the “OK” button.

6. The software installation program will start. Follow the on-screen directions to complete the

 software installation. When prompted to attach the modem, please refer to the instructions below.

Before installing the software, make sure your PC is equipped with the following.

Note that the DSL software is not installable on Macintosh®computers.

 • Windows®98, 98 SE, 2000 Professional, and Me®

 • 32 MB RAM

 • Pentium-compatible 233 MHz processor

 • 10 MB available hard disk space

Software Installation

For more information about Efficient Networks, please visit our website www.efficient.com

are registered and unregistered trademarks of Efficient Networks, Inc. All other brand names and

trademarks are held by their respective companies. Efficient Networks reserves the right to make

changes to product specifications at any time without notice.

Unlit

Solid

Blinking

power

Power Off

Power On

N/A

act

N/A

DSL traffic flow

eth

Ethernet port not

connected; check Ethernet

cable connection if using

Ethernet interface

Ethernet port connected

to LAN

Ethernet traffic flow

adsl

N/A

Ready for data

traffic

Searching for signal

usb

USB port not

connected; check USB

cable connection if

using USB interface

USB port connected

to host

Traffic flow on the

USB interface

Troubleshooting

Step

Step 3

adsl

power

acteth

usb

Corporate Headquarters

4849 Alpha Road

Dallas, Texas 75244

1+972-852-1000 PHONE

1+972-852-1001 FAX

info@efficient.com EMAIL
