EGO LB5300E Manuale utente

REPAIR GUIDELINE

Blower_LB5300E

Version: 1

Issue Date: 2016/02/25

Table of Contents

NO. Contents Page

1 Troubleshooting 3

2 Tool list 4

3 How to disassemble the blower 5-20

4 How to replace the PCBA 21-34

5 How to replace the Motor & Ducted Assembly 35-40

6 How to assemble the blower 41-43

Troubleshooting

Problem

Possible Cause

Fault Position

Test & Solution

Fail to start

PCBA is damaged.

PCBA in Handle

Replace PCBA in the handle.

Motor is damaged.

Motor in Ducted

Assembly

Measure the resistance between any

two of the three cables in the motor

and ducted assembly by using a

multimeter.

If the resistance is infinite, replace

the motor and duct assembly.

Press the boost button/air

velocity adjusting knob when the

blower runs, the air velocity and

the volume doesn’t change.

PCBA is broken

PCBA in Handle

Replace PCBA in the handle.

The air velocity and the volume

are decreased compared with

normal use.

The fan in the duct is

over-worn

Fan in Ducted

assembly

Open the handle housing , take off

the fan baffle and check the fan. If

the fan is over-worn, replace the

motor and duct assembly.

Tool List For Repair

NO. Tool List SPEC Remark

1 Magnetic bits

2 Utility knife To remove the label

3 Heat gun

4 Heat -shrinkable sleeves Φ7 mm

5 Scissors To remove the shrinkable sleeve

6 Multimeter

7 Capacitor discharging fixture

1. Remove the air velocity indication label.

Air Velocity

Indication Label

How to disassemble the blower

Four Screws

2. Remove the 4 screws to disassemble the base assembly.

Description

Part Number

Tapping Screw 5610032004

Base Assembly 2824381001

BaseAssembly

How to disassemble the blower

3. Remove the 8 screws and open the handle housings.

How to disassemble the blower

Fan Baffle Right Housing Motor & Duct Assembly

4. Remove the Fan Baffle.

5. Loosen the 2 screws in the right housing and remove the right housing.

How to disassemble the blower

Description

Part Number

Description

Part Number

Battery Release Button

3127201001

Static Dissipation Assembly

2824406001

Latch

3127202001

Anti-static Bar

3650142001

Battery Ejection Lever

3127206001

Left Handle Housing

3321366001

Speed Adjusting Knob

3127215001

Right Handle Housing

3321365001

Boost Button Level

3128066001

Handle Housing Set

2824414001

Trigger Level

3128069001

Left Housing 3321362001

PCBA

2830105001

Right Housing 3321361001

Spring 1

3660088003

Housing Set 2824413001

Spring 2

3660013003

Motor & Duct Assembly 2824335002

Spring 3

3660129002

Fan Baffle 3128068001

Rubber Gasket 5650519001

The following parts can be replaced after opening the housings.

How to disassemble the blower

Battery Release

Button

Latch

Anti-static Bar

Trigger Level

Boost Button Level

PCBA

Speed Adjustment Knob

Battery Ejection Lever

Static Dissipation

Assembly

Spring 2

Spring 1

Spring 3

Left Handle

Housing

Left Housing

Motor & Duct Assembly

Fan Baffle

Right Housing

Rubber Gasket
