Eicon’s Diva™Server and
Microsoft Speech Server 2004
R2 and Speech Server 2007
Diva Server for Microsoft Speech Server 2004 R2 and 2007 are tightly integrated, robust and complete product offerings for the
Enterprise. No matter what type of network connection you need - analog up to and including multi-T1/E1/PRI adapters - Diva Server
is the answer for a fully functional Speech Server solution that is easy to install and use. As a single telephony platform Diva Server
seamlessly interfaces with both MSS 2004 R2 via a Telephony Interface Manager (TIM) and MSS 2007 via SIP and RTP. Existing TIM
based deployments can upgrade to MSS 2007 by the means of the Telephony Interface Service (TIS) layer which ships with MSS 2007.
Eicon Networks Diva Server for Microsoft Speech Server advantages:
• Scaling from 2 to 480 channels in a system - allows for mixing and matching different board types
• Optimized for IVR and speech applications – offering rich media processing performance
• Best of breed install and configuration support – plug and play, no need for manual configuration
• Designed for Windows - Diva Server telephony boards are Microsoft WHQL certified
• Certified for Windows Server - Telephony Interface Manager (TIM) is certified for Windows Server 2003
• Seamless PBX integration - Diva Server is tested with all key PBX vendors and supports Q.SIG protocol
• Future proof migration path - Diva Server supports both TIM and native VoIP (SIP) interface towards MSS
product
brochure
Microsoft's vision is that speech will become a
mainstream, pervasive technology that is accessible by
any device, at any time, and from any place. Speech-
enabled applications should therefore be accessible by
standard telephones and cell phones as well as GUI
(Graphical User Interface)-based devices like PDAs, Tablet
PCs, smart phones and desktop PCs. The Microsoft vision
includes enabling the convergence of the Web and voice
systems into one infrastructure. With this convergence,
speech-enabled and visual-only Web applications will
become a unified application, developed using standard
Web programming tools, based on Web standards and
running on your existing Web infrastructure.
Eicon Networks is a member of the Microsoft Speech
Partner Program working with Microsoft to ensure our
products are compatible with the latest features of Speech
Server. Eicon has been partnering with Microsoft for over
15 years providing communication drivers on Microsoft
Operating System CDs. Eicon Networks Diva™ Server is
Microsoft WHQL and logo certified which includes the
latest 64-bit operating systems.
Diva Server and Microsoft Speech
www.eicon.com/divaserver
In order to communicate with telephony hardware and the telephony network, MSS 2004 R2 requires a Telephony Interface Manager
(TIM). The main task of a TIM is to stream media to and from MSS Speech Engine Services (SES) for recognition and speech output. The
TIM also processes call control messaging and call signaling as well as DTMF detection.
Eicon Networks has created specific product bundles that include telephony hardware and the Intervoice TIM. Each Eicon Diva Server for
MSS 2004 R2 product bundle includes a Diva Server V-Series telephony board, the Intervoice TIM software and license for the respective
number of channels, as well as a 180-day evaluation version of MSS 2004 R2.
Diva Server for Microsoft Speech Server 2004 R2 Implementation
Speech Server 2007 will provide full support for Speech Application Language Tags (SALT) and Voice Extensible Markup Language
(VoiceXML), which will enable customers to choose the development standard that will work best in their environment. Leveraging
Microsoft’s investments in Internet protocol (IP) telephony, Speech Server 2007 includes native support for voice over IP (VoIP), providing
companies with a powerful platform that can grow with changing business and technology needs. The platform natively supports Session
Initiation Protocol (SIP) and Real-Time Transport Protocol (RTP) as core communications protocols for out-of-the-box support for IP
telephony and interoperability with leading VoIP gateways.
Diva Server SIPcontrol™ adds IP-to-PSTN Gateway functionality to any Diva Server telephony adapter (PCI-board). Thus Diva Server
telephony boards can interface with MSS 2007 natively via SIP and RTP, offering an ideal platform for traditional time division
multiplexing (TDM) or hybrid IP/TDM environments. By using open and standards-based IP protocols, both single-box as well as
distributed deployments are possible.
Diva Server for Microsoft Speech Server 2007 Implementation – Leveraging the native VoIP support!
Figure 1: Diva Server for Microsoft Speech Server - Common platform for MSS 2004 and 2007
www.eicon.com/divaserver
Figure 2 : Diva Server SIPControl™ enables single-box and distributed deployments of MSS 2007
Media processing performance,
number of concurrent channels CTI, Basic Voice Enhanced Voice, Speech
and Conferencing
Product Name Order Code Switching Play/Record DTMF
Echo
Cancellation
Voice Activity
Detection Barge-In
Conferencing
w/ AGC and EC
Diva Server V-series adapters
are all no-compromise, full-function enhanced speech and conferencing adapters that come with ample DSP resources so that every channel can employ the most processing-
intensive features without limitation.
V-BRI-2 306-219 2 2 2 2 2 2 2
V-4BRI-8 306-218 8 8 8 8 8 8 8
V-PRI/E1-30
V-PRI/T1-24
306-214
306-213
30
24
30
24
30
24
30
24
30
24
30
24
30
24
V-2PRI/E1-60
V-2PRI/T1-48
306-249
306-250
60
48
60
48
60
48
60
48
60
48
60
48
60
48
V-4PRI/E1-120
V-4PRI/T1-96
306-251
306-252
120
96
120
96
120
96
120
96
120
96
120
96
120
96
V-Analog-4P
V-Analog-8P
306-236
306-237
4
8
4
8
4
8
4
8
4
8
4
8
4
8
Physical Telephone Interfaces (from 2 to 480 channels in a system)
• Analog – 4 port or 8 port
• ISDN – Basic Rate (BRI) or 4x Basic rate (4BRI)
• 1, 2, or 4 ports of T1/E1 and ISDN PRI
For more details check our web site at: www.eicon.com/worldwide/products/MediaGateways/diva_server_overview.htm
www.eicon.com/divaserver
Diva Server for Microsoft Speech Server (MSS 2004) bundles, including a Diva Server V-Series telephony board together with the
Intervoice TIM software and license, are available through Eicon Networks solution providers (ESP) and Eicon Networks distributors.
See commercial order codes below.
Diva Server SIPControl™ for MSS 2007 will be in beta release to customers’ trialing Microsoft Speech Server 2007.
Please contact your local Eicon Networks representative or check our web site at:
www.eicon.com/worldwide/products/MediaGateways/Diva_Server_for_MSS.htm
Five year hardware warranty. Separate warranty terms apply to software and custom products.
Availability
Warranty
© 2006 Eicon Networks Corporation. All rights reserved. Please note that the use or implementation of any one of the concepts, applications, or ideas described in this document may infringe one or more patents or other
intellectual property rights owned by third parties. Eicon Networks Corporation encourages all users of its products to procure all necessary intellectual property licenses required to implement any concepts or applications, which
licenses may vary from country to country and does not condone or encourage any intellectual property infringement and disclaims any responsibility related thereto. All names, products, and services mentioned herein are the
trademarks or registered trademarks of their respective organizations and are the sole property of their respective owners. Information subject to change without notice. [GR06/18/130] 221-751-01
Asia Pacific:
Offices: Beijing, Hong Kong,
Kuala Lumpur, Shanghai
Corporate headquarters
Eicon Networks Corporation
9800 Cavendish Blvd 5th Floor
Montreal Quebec Canada
H4M 2V9
Tel: +1 (514) 745-5500
Fax: +1 (514) 745-5588
Regional sales head offices
Americas:
Eicon Networks Inc.
Parkway Centre II
2805 N. Dallas Parkway Suite 200
Plano Texas 75093 USA
Tel: +1 (972) 473-4500
Fax: +1 (972) 473-4510
Offices: Dallas, Montreal
Europe, Middle East, Africa:
Eicon Networks (UK) Ltd.
Kings Chase 107-123 King Street
Maidenhead Berkshire SL6 1DP
United Kingdom
Tel: +44 (0) 1628 641770
Fax: +44 (0) 1628 641780
Offices: Barcelona, Bergamo, Berlin,
Den Haag, Dusseldorf, Leonberg, Ljubljana,
London, Paris, Munich, Stockholm
Product Name Product Code
Diva Server V-Analog-4P for Microsoft Speech Server (MSS 2004) - North America 306-290
Diva Server V-Analog-8P for Microsoft Speech Server (MSS 2004) - North America 306-280
Diva Server V-PRI/T1-24 for Microsoft Speech Server (MSS 2004) - North America 306-281
Diva Server V-2PRI/T1-48 for Microsoft Speech Server (MSS 2004) - North America 306-282
Diva Server V-4PRI/T1-96 for Microsoft Speech Server (MSS 2004) - North America 306-283
Diva Server V-Analog-4P for Microsoft Speech Server (MSS 2004) - International 306-279
Diva Server V-Analog-8P for Microsoft Speech Server (MSS 2004) - International 306-289
Diva Server V-BRI-2 for Microsoft Speech Server (MSS 2004) - International 306-286
Diva Server V-4BRI-8 for Microsoft Speech Server (MSS 2004) - International 306-287
Diva Server V-PRI/E1-30 for Microsoft Speech Server (MSS 2004) - International 306-288
Diva Server V-2PRI/E1-60 for Microsoft Speech Server (MSS 2004) - International 306-285
Diva Server V-4PRI/E1-120 for Microsoft Speech Server (MSS 2004) - International 306-284
