DIVA T/A ISDN Modem

User’s Guide

International

Third Edition (July 1999) 206-269-03

DIVA T/A ISDN Modem is a trademark of Eicon Technology Corporation.

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.

CompuServe is a registered trademark of CompuServe Incorporated.

Hayes is a registered trademark of Hayes Microcomputer Products, Inc.

Changes are periodically made to the information herein; these changes will be incorporated

into new editions of the publication. Eicon Technology may make improvements and/or

changes in the products and/or programs described in this publication at any time.

A Product Comment Form is provided at the back of this publication. If the form has been

removed, address your comments to: Eicon Technology Corporation, Attn.: Corporate

Publications, 9800 Cavendish Blvd., Montreal, Quebec, Canada H4M 2V9. Eicon Technology may

use or distribute whatever information you supply in any way it believes appropriate without

incurring any obligations to you.

reproduce this publication or parts thereof in any form without permission in writing from Eicon

Technology Corporation.

DIVA T/A ISDN Modem User’s Guide ◆Page 3

Contents

Introduction .......................................................................................................................................... 5

Installation Requirements ................................................................................................................... 6

Connecting the Cables to the DIVAT/A ............................................................................................... 7

Windows 95/98/NT Installation and Setup .........................................................................................9

Installing the DIVA Software ....................................................................................................................................... 20

Macintosh (System 7 or Later) Installation and Setup ..................................................................... 25

Installing the DIVA Software ....................................................................................................................................... 26

Specifying ISDN Settings via the Configuration Assistant ...............................................................................28

Setup for Other Operating Systems .................................................................................................. 31

The DIVA Terminal Adapters Program for Windows 95/98/NT ....................................................... 32

Introduction ...................................................................................................................................................................... 33

The Profiles Window ...................................................................................................................................................... 35

About Configuration Profiles ......................................................................................................................................36

Configuring a Profile using the Configuration Tool ........................................................................................... 37

Configuring a Profile using the Wizard ...................................................................................................................54

The DIVA Terminal Adapters Program for Macintosh ...................................................................... 55

Introduction ...................................................................................................................................................................... 56

About Configuration Profiles ......................................................................................................................................58

The Profiles Window ...................................................................................................................................................... 59

Configuring a Profile using the Configuration Tool ........................................................................................... 60

Configuring a Profile using the Assistant ...............................................................................................................71

The VT100 Configuration Tool ........................................................................................................... 73

Updating Firmware ............................................................................................................................ 79

Windows 95/98/NT ........................................................................................................................................................ 80

Macintosh (System 7 or Later) .................................................................................................................................... 81

Other Operating Systems ............................................................................................................................................82

Updating the DIVA T/A INF file ................................................................................................................................... 83

Using the DIVA T/A .............................................................................................................................. 84

SecurID Connectivity .....................................................................................................................................................85

Dialing with Multilink PPP ........................................................................................................................................... 86

Establishing a Connection ........................................................................................................................................... 88

Connecting to the World Wide Web ......................................................................................................................103

Analog Device Support .................................................................................................................... 104

Calling Features .............................................................................................................................................................105

DIVA T/A ISDN Modem User’s Guide ◆Page 4

Contents

Multiple Subscriber Numbering ...................................................................................................... 120

Assigning Primary and Secondary Numbers to the Phone Ports ................................................................121

Configuring a Port to Answer Any Number no tConfigure dElsewhere ...................................................123

Specifying what numbers the data port should answer ................................................................................124

Routing voice calls to your computer (Voice to PC) .........................................................................................126

ISDN Line Termination ..................................................................................................................... 129

Troubleshooting the DIVAT/A ......................................................................................................... 131

LED Status Indicators on the DIVA T/A ..................................................................................................................132

Common Problems ......................................................................................................................................................134

Dumping the DIVA T/A Memory ..............................................................................................................................136

Billing Interval Example ................................................................................................................... 137

DIVA T/A ISDN Modem Specifications ............................................................................................. 138

Technical Support ............................................................................................................................. 140

Regulatory Information and Conditions of Use ............................................................................. 141

Limited Warranty .............................................................................................................................. 142

DIVA T/A ISDN Modem User’s Guide ◆Page 5

Introduction

The DIVAT/A is an external ISDN modem available in S/T and U interface versions. It provides

easy and affordable access to the Internet via ISDN.

With the DIVA T/A, Small Office Home Office (SOHO) users and telecommuters can combine

the higher performance of ISDN with the simplicity of a terminal adapter. The DIVA T/A

supports all standard modem AT commands.

You can connect the DIVAT/A to a serial port on your computer that complements your

TCP/IP application, without the need for additional device drivers.

Internet Access

The DIVAT/A allows you to connect to the Internet over an ISDN line at speeds of up to 128

kilobits per second. With virtually no delays, you can access online services or browse the

World Wide Web to download high-resolution graphics, video clips, interactive games, music,

and more.

Work-at-Home Access

The DIVA T/A provides the telecommuter with fast access to network resources back at the

office. You can access applications such as email or download data from a remote database in

a fraction of the time it would take using a conventional analog modem.

Analog Device Ports (certain models only)

Certain DIVA T/A models include two analog device ports (also referred to as Plain Old

Telephone Service, or POTS). You can use these ports to connect regular telephones,

modems or fax machines to your DIVA T/A. Calls to and from these analog devices are carried

over your ISDN line. This saves you the expense of installing a separate analog phone line.

The DIVAT/A supports a variety of calling features such as Call Forward, Call Waiting,

Caller ID, Call Transfer, and Call Redirection. The available calling features, and the way each

feature works, depends on your location. See “Analog Device Support” on page 104 for

details.

Note: The DIVA T/A can work independently from your computer. If the DIVA T/A is turned

on, your analog devices can use your ISDN line regardless of whether or not the DIV AT/A is

connected to your computer.

Ease of Use

You can connect the DIV AT/A to any computer (desktop or notebook) equipped with a serial

port. Under Windows 95/98/NT and Macintosh (System 7 or later), you can easily configure

the DIVA T/A using the included DIVA Terminal Adapters software. For all platforms, the

VT100 Configuration Tool can be used as well as AT commands.

DIVA T/A ISDN Modem User’s Guide ◆Page 6

Installation Requirements

To install the DIVA T/A, you will require the following:

Item Description

DIVA T/A Package •DIVA T/A ISDN Modem

•DIVA T/A software (CD)

•ISDN cable (RJ-45)

•Serial cable (RS-232)

•A/C Adapter

•Phone Adapter (RJ11) (where required)

•Terminating Resistor (if required - see page 129)

•DIVA T/A QuickStart Guide

•DIVA T/A Release Notes

Desktop or Notebook DIVA T/A can be attached to any desktop or notebook computer.

Remote Access

Client Software

Supplied as part of operating platform or by Internet Service Provider (ISP).

ISDN Basic Rate Line Must be installed by your telephone company.

Terminal Emulation

Program

If you are using an operating system other than Windows 95/98/NT or

Macintosh (System 7 or later), you will need a VT100-compatible

terminal-emulation program (such as Telix or HyperTerminal) in order to

configure the DIVA T/A.

Internet Access

(Optional)

To establish an ISDN connection to the Internet, you will require the

following:

•ISP that provides ISDN Basic Rate Interface service

•PPP and TCP/IP communications protocols for accessing your Internet

subscription (e.g. Windows 95/98/NT Dial-Up Networking)

•TCP/IP clients (Web browser, FTP, Telnet)

Operating System •Microsoft® Windows® 95, Windows 98, or Windows NT® (3.51/4.0)

•Windows 3.x, DOS, or OS/2

•Macintosh

COM Port IBM-compatible computers:

•UART 16650 (230.4 kbps) recommended for maximum throughput

•UART 16550

Macintosh computers

•Serial port capable of 230.4 kbps transfer recommended (found on most

PowerMacintosh and AV Macintosh computers).

DIVA T/A ISDN Modem User’s Guide ◆Page 7

Connecting the Cables to the DIVAT/A

Follow the steps below to connect the cables to your DIVAT/A.

1Turn off your computer before you connect the cables.

2Connect the RJ45 end of the ISDN cable to the jack labeled ‘ISDN’ on the rear of the

DIVA T/A. See below to complete the connection.

•Integrated NT1 (U): Connect the other end of the ISDN cable to your ISDN wall jack.

•S/T Interface: Connect the other end of the ISDN cable to an NT1 interface, whether

part of the ISDN service (e.g. corporate phone switch) or external. In Australia, you

may have to change the ISDN line termination. See “ISDN Line Termination” on

page 129 for more information.

3If your DIVA T/A model comes with phone ports, attach the cables from analog devices

(telephone and fax machine, for example) to the jacks labeled PHONE 1 and PHONE 2 on

the rear of the DIVA T/A. It is recommended that you use PHONE 1 for voice and PHONE 2

for data (modem or fax). Phone ports are only available on certain models.

In certain countries (such as France and the United Kingdom) you must attach your

analog devices to phone adapters before connecting them to the DIVA T/A. One adapter

has been included in your DIVA T/A package.

4Connect one end of the serial cable to the port labeled SERIAL on the rear of the

DIVA T/A, and the other end to the appropriate serial port on your computer.

Note: If you are connecting the DIVA T/A to a Macintosh, you will need a

Macintosh-style modem cable (DB25M-to-DIN8M) that supports hardware handshaking.

The included serial cable (DM25M-to-DB9F) is for use with IBM compatible PCs.

5Connect the A/C adapter connector to the power jack on the rear of the DIV AT/A, then

plug the adapter into an AC power outlet.

Note: On certain DIVA T/A models, the order of the serial and analog ports is reversed.

Reset

ISDN Phone 1 Phone 2 Serial

ISDN Jack

FaxPhone

ISDN Cable

Analog

Devices

Serial

Cable A/C

Adapter

Phone

Adapter Desktop Computer

DIVA T/A ISDN Modem User’s Guide ◆Page 8

Connecting the Cables to the DIVAT/A

After Connecting the Cables

After connecting the power and the ISDN cable to the DIVA T/A, wait at least 10 seconds for

the DIVA T/A to initialize and then check the ‘D’ and ‘Link’ LEDs. If they are both glowing

continuously, then your DIVA T/A is operational from a previous configuration. If not, you will

have to provide information on your ISDN setup using the DIVA Terminal Adapters software,

which you will install next. See below.

What’s Next?

The installation procedure you need to follow depends on the operating system you are

using. Go to the page corresponding to your platform and continue.

•Windows 95/98/NT Installation and Setup...............................................9

•Macintosh (System 7 or Later) Installation and Setup..........................25

•Setup for Other Operating Systems............................................................31

DIVA T/A ISDN Modem User’s Guide ◆Page 9

Windows 95/98/NT Installation and Setup

To properly set up the DIVA T/A with a Windows 95/98/NT system, you must connect the

cables, configure the operating system, and install the DIVA Terminal Adapters Software.

Once the Terminal Adapters software is installed, you will use the Configuration Wizard to set

your ISDN parameters.

Step 1: Connect the Cables to your DIVAT/A

Following the steps outlined on page 7.

Step 2: Configure your Operating System

The configuration procedure you must follow depends on the flavour of Windows you are

using. After you have finished connecting the cables and gathering the required information,

go to the page that corresponds to your platform.

•Windows 95 (Original Release and SP1) ....................................................10

•Windows 95 (OSR2)...........................................................................................12

•Windows 98 .........................................................................................................14

•Windows NT 4.0..................................................................................................16

•Windows NT 3.51 ...............................................................................................19

Note: If you are using Windows 3.x, see page 31.

Step 3: Install the DIVA Software

The Setup Wizard installs all necessary files on your system. These include the DIVA T/A

on-line documentation, the DIVA Terminal Adapters Program, and the Uninstall utility.

Following the steps outlined on page 20.

DIVA T/A ISDN Modem User’s Guide ◆Page 10

Windows 95/98/NT Installation and Setup

Windows 95 (Original Release and SP1)

This install procedure is for the original release and Service Pack 1 (SP1) version of

Windows 95. If you are using Windows 95 Service Release 2 (OSR2), go to “Windows 95

(OSR2)” on page 12.

To verify the version installed on your machine, click ‘Start’, ‘Settings’, ‘Control Panel’, ‘System’,

then click the ‘General’ tab. If you have the original or SP1 version of Windows 95 installed,

you will see ‘4.00.950’ or ‘4.00.950 A’, as shown.

DUN 1.2 or Later Required

If you are using Dial-Up Networking (DUN), make sure you are using version 1.2 or later. If you

are running a previous version, you must upgrade to DUN 1.2 or later before installing the

DIVA T/A. For your convenience, DUN 1.3 is included on the DIVA T/A CD-ROM; run SETUP.EXE

from the CD-ROM and click ‘Bonus Software’.

Setup Instructions

Follow these steps to set up the DIVAT/A under Windows 95 (Original Release and SP1).

1Power on your PC with all cables connected (see page 7 for instructions).

2Windows 95 detects the DIVA T/A and the ‘New Hardware Found’ window appears.

3Insert the DIV AT/A CD into your computer's CD drive.

4In the ‘New Hardware Found’ window, select ‘Driver from disk provided by hardware

manufacturer’ and click ‘OK’. The ‘Install From Disk’ window appears.

Altri manuali per DIVA T/A ISDN Modem

Indice

Altri manuali Eicon Technology Modem

Eicon Technology

Eicon Technology Diva T/A Manuale utente

Eicon Technology

Eicon Technology DIVA LAN ISDN Manuale utente

Eicon Technology

Eicon Technology DIVA LAN ISDN Manuale utente

Eicon Technology

Eicon Technology DIVA T/A ISDN Modem Manuale utente

Manuali Modem popolari di altre marche

Davicom

Davicom DM562AP Manuale utente

EpiValley

EpiValley TATA indicom SXC-1080 Manuale utente

Zte

Zte WiMAX Manuale utente

Intelimax

Intelimax MA-2060 Manuale utente

SMC Networks

SMC Networks D3CM1604V Manuale per l'uso e la cura

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuale utente

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuale utente

Samsung

Samsung AceLink SAM-335A Manuale utente

Enfora

Enfora Enabler-G Guida rapida alla configurazione

iRZ

iRZ ATM2-232 Manuale utente

Zhone

Zhone 6310 Manuale utente

Paradyne

Paradyne Hotwire 7976 Manuale utente

US Robotics

US Robotics 3453C Manuale utente

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuale utente

Zte

Zte MF823 Manuale utente

Four-Faith

Four-Faith F1403 Manuale utente

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuale utente

Gemtek

Gemtek WiMAX WIXFBR-103 Manuale utente
