Eizo FLEXSCAN L997 - Manuale utente


SAFETY SYMBOLS
 PRECAUTIONS
1. Introduction
1-1. Features
1-2. Package Contents
1-3. Controls &
Connectors
2. CABLE CONNECTION
2-1. Before Connecting
2-2. Connecting the
Signal Cable
2-3. Connecting Two PCs
to the Monitor
3. ScreenManager
3-1. How to use the
ScreenManager
3-2. ScreenManager
Adjustments and Settings
3-3. FineContrast
3-4. Useful Functions
4. ADJUSTMENT
4-1. Screen Adjustment
4-2. Displaying Low
Resolutions
4-3. Color Adjustment
4-4. Power-save Setup
5. ActiveShot Function
5-1. Operation
5-2. Sub Window Settings
5-3. Settings using the
Control Buttons
6. ActiveRotationII Function
7. MAKING USE OF USB
(Universal Serial Bus)

This manual is checked under the browser settings
shown below. Text size can change for another one
through browser setting.
Microsoft Internet Exproler:
Text size: Medium
Encoding: Western European

8. ATTACHING AN ARM
9. TROUBLESHOOTING
10. CLEANING
11. SPECIFICATIONS
12. GLOSSARY
APPENDIX/ANHANG/ANNEXE
About TCO'03 (Applicable gray)
About TCO'99 (Applicable black)
FCC Declaration of Conformity
Hinweis zur Ergonomie / Recycle
Auskunft / Hinweise zur Auswahl
des richtigen Schwenkarms für
Ihren Monitor

SAFETY SYMBOLS

This manual uses the safety symbols below. They denote critical information. Please read them carefully.

WARNING

Failure to abide by the information in a WARNING may result in serious injury and can be life

threatening.

CAUTION

Failure to abide by the information in a CAUTION may result in moderate injury and/or property

or product damage.

Indicates a prohibited action.

Indicates to ground for safety.

retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without

the prior written permission of EIZO NANAO CORPORATION.

EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information

confidential unless prior arrangements are made pursuant to EIZO NANAO CORPORATION's receipt of

said information. Although every effort has been made to ensure that this manual provides up-to-date

information, please note that EIZO monitor specifications are subject to change without notice.

Apple, Macintosh and Mac OS are registered trademarks of Apple Inc.

VGA is a registered trademark of International Business Machines Corporation.

Windows is a registered trademark of Microsoft Corporation in the United States and other countries.

VESA is a registered trademark or a trademark of Video Electronics Standards Association in the United

States and other countries.

EIZO, EIZO Logo, FlexScan and ScreenManager are registered trademarks of EIZO NANAO

CORPORATION in Japan and other countries.

All other trademarks are the properties of their respective owners.

PRECAUTIONS

IMPORTANT!

●This product has been adjusted specifically for use in the region to which it was originally shipped.

If operated outside the region to which it was originally shipped, the product may not perform as

stated in the specifications.

●To ensure personal safety and proper maintenance, please read this section and the caution

statements on the unit (refer to the figure below).

[Location of the Caution Statements]

If the unit begins to emit smoke, smells like something is burning, or makes strange noises,

disconnect all power connections immediately and contact your dealer for advice.

Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.

Do not open the cabinet or modify the unit.

Opening the cabinet or modifying the unit may result in fire, electric shock, or burn.

Refer all servicing to qualified service personnel.

Do not attempt to service this product yourself as opening or removing covers may result in fire, electric

shock, or equipment damage.

Keep small objects or liquids away from the unit.

Small objects accidentally falling through the ventilation slots into the cabinet or

spillage into the cabinet may result in fire, electric shock, or equipment damage.

If an object or liquid falls/spills into the cabinet, unplug the unit immediately.

Have the unit checked by a qualified service engineer before using it again.

Place the unit at the strong and stable place.

A unit placed on an inadequate surface may fall and result in injury or

equipment damage.

If the unit falls, disconnect the power immediately and ask your dealer for

advice. Do not continue using a damaged unit. Using a damaged unit may

result in fire or electric shock.

Set the unit in an appropriate location.

Not doing so may result in fire, electric shock, or equipment damage.

●Do not place outdoors.

●Do not place in the transportation system (ship, aircraft, trains,

automobiles, etc.)

●Do not place in a dusty or humid environment.

●Do not place in a location where the steam comes directly on the screen.

●Do not place near heat generating devices or a humidifier.

To avoid danger of suffocation, keep the plastic packing bags away from babies

and children.

Use the enclosed power cord and connect to the standard power outlet of your country.

Be sure to remain within the rated voltage of the power cord.Not doing so may result in fire or electric

shock.

To disconnect the power cord, grasp the plug firmly and pull.

Tugging on the cord may damage and result in fire or electric shock.

The equipment must be connected to a grounded main outlet.

Not doing so may cause in fire or electric shock.

Use the correct voltage.

●The unit is designed for use with a specific voltage only. Connection to another voltage than

specified in this User's Manual may cause fire, electric shock, or equipment damage.

●Do not overload your power circuit, as this may result in fire or electric shock.

Handle the power cord with care.

●Do not place the cord underneath the unit or other heavy objects.

●Do not pull on or tie the cord.

If the power cord becomes damaged, stop using it. Use of a damaged cord may result in fire or electric

shock.

Never touch the plug and power cord if it begins to thunder.

Touching them may result in electric shock.

When attaching an arm stand, please refer to the user's manual of the arm stand and install the unit

securely with the enclosed screws.

Not doing so may cause the unit to come unattached, which may result in injury or equipment damage.

When the unit is dropped, please ask your dealer for advice. Do not continue using a damaged unit. Using a

damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same

screws and tighten them securely.

Do not touch a damaged LCD panel directly with bare hands.

The liquid crystal which leaks from the panel is poisonous if it enters the eyes or mouth.

If any part of the skin or body comes in direct contact with the panel, please wash thoroughly. If some

physical symptoms result, please consult your doctor.

Follow local regulation or laws for safe disposal.

The backlight of the LCD panel contains mercury.

Handle with care when carrying the unit.

Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is

dangerous. It may result in injury.

When handling the unit, grip the bottom of the unit firmly with both hands

ensuring the panel faces outward before lifting.

Dropping the unit may result in injury or equipment damage.

Do not block the ventilation slots on the cabinet.

●Do not place any objects on the ventilation slots.

●Do not install the unit in a closed space.

●Do not use the unit laid down or upside down.

Blocking the ventilation slots prevents proper airflow and may result in fire, electric shock, or equipment

damage.

Do not touch the plug with wet hands.

Doing so may result in electrical shock.

Use an easily accessible power outlet.

This will ensure that you can disconnect the power quickly in case of a problem.

Periodically clean the area around the plug.

Dust, water, or oil on the plug may result in fire.

Unplug the unit before cleaning it.

Cleaning the unit while it is plugged into a power outlet may result in electric shock.

If you plan to leave the unit unused for an extended period, disconnect the power cord from the wall

socket after turning off the power switch for the safety and the power conservation.

LCD Panel

In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a

monitor in lower brightness is recommended.

The screen may have defective pixels. These pixels may appear as slightly light or dark area on the screen.

This is due to the characteristics of the panel itself, and not the product.

The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to flicker,

please contact your dealer.

Do not press on the panel or edge of the frame strongly, as this may result in damage to the screen. There

will be prints left on the screen if the pressed image is dark or black. If pressure is repeatedly applied to the

screen, it may deteriorate or damage your LCD panel. Leave the screen white to decrease the prints.

When the screen image is changed after displaying the same image for extended periods of time, an

afterimage may appear. Use the screen saver or timer to avoid displaying the same image for extended

periods of time.

When the monitor is cold and brought into a room or the room temperature goes up quickly, dew

condensation may occur inside and outside the monitor. In that case, do not turn the monitor on and wait

until dew condensation disappears, otherwise it may cause some damages to it.

Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may result in

damage to the panel. Do not attempt to brush with tissues as this may scratch the LCD panel.

1. Introduction

Thank you very much for choosing an EIZO Color Monitor.

1-1. Features

●Dual inputs compliant (DVI-I x 2)

●DVI Digital input (TMDS) compliant

●[Horizontal scanning frequency]

Analog: 24 - 100 kHz

Digital: 31 - 100 kHz

[Vertical scanning frequency]

Analog: 49 - 86 Hz (1600 x 1200: 49 - 76 Hz)

Digital: 59 - 61 Hz (VGA text: 69 - 71 Hz)

[Resolution] 1600 dots x 1200 lines

●Smoothing function incorporated for the adjustment of an enlarged image

●FineContrast modes, to select the most suitable mode for screen display

●ActiveShot (Picture in Picture) function incorporated.

●ActiveRotationII (changing the display orientation of the monitor with the panel rotation) function

incorporated.

●The utility software "ScreenManager Pro for LCD" (for Windows) which can control the monitor

from a PC with a mouse or keyboard is included (refer to the EIZO LCD Utility Disk).

●The height adjustable stand incorporated

●Ultra slim bezel incorporated

1-2. Package Contents

Please contact your local dealer for assistance if any of the listed items are missing or damaged.

●LCD Monitor

●EIZO LCD Utility Disk

●Power Cord

●User's Manual (in the CD-ROM)

●Signal Cable (FD-C39)

●Setup Guide

●Signal Cable (FD-C16)

●ScreenManager Quick Reference

●EIZO USB Cable (MD-C93)

●LIMITED WARRANTY

●Please retain the packing materials for future transference.

●The "ActiveRotationII Utility" (for Windows) is included in the EIZO LCD Utility Disk. Please refer
