If the code is entered incorrectly 3 times, there will be a 1-minute lock. If the code is then entered incorrectly a further
3 times, there will be a 15- minute lock. There will be a 15-minute lock each time the code is entered incorrectly after
that.
Controls, optical signals and acoustic signals on the code pad
The code pad has 2 sections with controls.
Control Function
Input buttons Enter pin code; select menu item.
Confirmation buttons Confirm pin code input as positive or negative; start menu.
Table 1: Code pad controls
2 status LEDs signal the operating statuses (pin code correct, pin code incorrect, menu item, etc.). An acoustic signal
transmitter signals that the button has been pressed and that access has been enabled.
The back-illumination of the keypad is blue, dimmable and switches on or off according to the lighting conditions.
Admin menu structure of the code pad
There is a range of menu items available in the admin menu for programming purposes. These can be called via the
buttons.
1 Left status LED
2 Right status LED
3 Input buttons
4 Confirmation buttons
Fig. 2: Code pad overview
1
ABC
2
DEF
3
GHI
4
JKL
5
Button Menu item
Store user code
Delete user code
Change admin code
Button Menu item
Reset the system to default settings
Set the code pad (back-illumination,
relay switching time, acoustic and
optical signal when button is pressed,
acoustic signal on opening)
Table 2: Admin menu structure of the code pad
