Elba CE302 Istruzioni per il montaggio

NZ AU
Installation instructions
and User guide
Solid hotplate cooktops
CE302 & CE604 models


1
Contents
Safety and warnings
2
Installation instructions
4
Introduction
14
Using your cooktop
16
Care and cleaning
19
Warranty and service
20
Important!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.

2
Important safety instructions
Installation
This appliance is to be installed only by an authorised person.
Ensure the benchtop is square and level and ensure no structural members interfere with space
requirements.
Ensure a suitable disconnection switch is incorporated in the permanent wiring, mounted and
positioned to comply with the Local Wiring Rules and Regulations.
Use easy-to-clean finishes for the wall surfaces surrounding the cooktop to aid removal of any
cooking fume staining resulting from the use of the cooktop.
Consult local building authorities and by-laws if in doubt regarding installation.
Ensure that the power supply cable is not accessible via cupboard doors after installation.
Ensure that there is adequate clearance between the cutout and the rear and/or side walls.
Safety and warnings
WARNING!
Cut Hazard
Beware of sharp edges when handling appliances.
Failure to use caution could result in injury or cuts.
WARNING!
Electrical Shock Hazard
Before carrying out any work on the electrical section of the appliance, it must
be disconnected from the mains electricity supply.
Connection to a good earth wiring system is absolutely essential and
mandatory.
Failure to do so could result in death or electrical shock.

3
Safety and warnings
Important safety instructions
Operation
Household appliances are not intended to be played with by children.
Children, or persons with a disability which limits their ability to use the appliance, should have a
responsible person to instruct them in its use. The instructor should be satisfied that they can use
the appliance without danger to themselves or their surroundings.
Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other
elements that are on. Keep handles out of reach of children.
Do not use a steam cleaner.
Do not use harsh/abrasive cleaning agents to clean your cooktop.
WARNING!
Hot Surface Hazard
Accessible parts of this appliance will become hot during use.
Care should be taken to avoid touching the hotplates.
Keep children away.
Failure to do so could result in burns and scalds.
WARNING!
Electrical Shock Hazard
Switch the cooktop o at the wall before cleaning or maintenance.
Failure to do so may result in death or electrical shock.

4Installation instructions
Important!
Read these instructions carefully before installing or using this product.
Please make this information available to the person responsible for installing the product as it
could reduce your installation costs.
In order to avoid a hazard, this appliance must be installed according to these instructions for
installation.
This cooktop has been designed and constructed in accordance with the following codes and
specifications:
AS/NZS 60335-1 General Requirements for Domestic electrical appliances
AS/NZS 60335-2-6 Particular Requirements for Domestic electrical cooking appliances
AS/NZS CISPR 14.1: 2010 Electromagnetic Compatibility Requirements.

5
Installation instructions
Product dimensions and clearances
The installation shall comply with the dimensions in Figs. 1 and 2, bearing in mind the following
requirements:
A minimum clearance of 40 mm for CE302 models and 30 mm for CE604 models has to be
kept between the bottom of the cooktop and the top of an underbench appliance or a thermal
protection barrier (see Figs. 5-7).
Overhead clearances - In no case shall the clearance between the highest part of the cooktop
and a range hood be less than 600 mm. Any other downward-facing combustible surface less
than 600 mm above the highest part of the cooktop shall be protected for the full width and
depth of the cooking surface area in accordance with local regulations in force. However, in no
case shall this clearance to any surface be less than 450 mm.
Side clearances - Where the distance from the periphery of the nearest hotplate to any vertical
combustible surface is less than 50 mm (CE302 models) or 100 mm (CE604 models), the surface
shall be protected in accordance with with local regulations in force to a height of not less than
150 mm above the cooktop for the full dimension (width or depth) of the cooking surface area.
Note: one side of the cooktop must always be kept clear.
Protection of combustible surfaces - The required protection shall ensure that the surface
temperature of combustible surfaces does not exceed 50 °C above ambient.
To comply with this requirement satisfactorily, fix 5mm-thick ceramic tiles to the surface or
attach fire-resistant material to the surface and cover with sheet metal (minimum thickness 0.4
mm).
Important!
The underside surface of the cooktop can reach a temperature exceeding 95 °C during normal
use.
650 mm
50 mm min.
450 mm
650 mm
60 mm min
100 mm min
500 mm
450 mm
Fig. 2 CE604 models clearances
Fig. 1 CE302 models clearances

6Installation instructions
490
510
270
288
30
0
– 2
0
– 2
50
580
480
500
60
0
–2
560 0
–2
55
Fig. 4 CE604 models product and cutout dimensions
Fig. 3 CE302 models product and cutout dimensions

7
Installation instructions
40 mm
Installing a thermal protection barrier
Important!
If the cooktop is installed over drawers or cupboards and its underside surface thus becomes accessible
after installation, a thermal protection barrier must be fitted at least 40 mm (for CE302 models) or 30 mm
(for CE604 models) beneath the base of the cooktop (see Figs. 5 and 6). This barrier must be made of low
thermal conductivity material installed according to the instructions for installation.
Note:
The requirement above is not applicable if the cooktop is installed directly above an oven.
For access to the cooktop for servicing or installation, ensure that the barrier can be removed from
beneath.
A gap of 20 mm may be allowed at the rear of the barrier (see Fig.7) for electrical connection and
ventilation.
20 mm gap
30 mm
Fig. 5 Minimum clearance for thermal
protection barrier - CE302 models Fig. 6 Minimum clearance for thermal
protection barrier - CE604 models
Thermal protection barrier
(min. 15 mm thick)
This must be fitted for the full length of the cook-
top below the bench, and be removable for
installation and service.
Fig. 7 Side sectional view

8Installation instructions
Fastening the installation brackets
Each cooktop is provided with an installation kit including brackets and screws for fastening the
cooktop to benches from 20 to 40 mm thick.
CE302 models are provided with four Ftype brackets.
CE604 models are provided with two Rtype brackets (for the rear of the cooktop) and two Ftype
brackets (for the front of the cooktop).
1
Create a cutout according to the dimensions in Fig.3 or Fig.4.
2
Stretch gasket “D” (Figs. 10 and 11) over the edge of the cutout, being careful to overlay the
junction edges.
3
Turn the cooktop upside down, place it on a soft surface and fasten the brackets Fand Rto the
appropriate socket holes, without tightening the screws Bfor the moment. Make sure that the
tabs are mounted correctly, as shown. Rotate the tabs so that the cooktop can be put into the
cutout.
4
Put the cooktop into the cutout and position it correctly.
5
Put the brackets Fand Rinto place; tooth Aof the brackets should go into the hole (Figs. 10 and
11).
6
Tighten screws Buntil the cooktop is completely secured to the bench.
7
Using a sharp cutter or trimmer knife, trim the excess sealing material around the edge of the
cooktop. Take care not to damage the workbench.
F
20 mm min.
40 mm max.
B
D
Rtype bracket
A
20 mm min.
40 mm max.
B
D
Ftype bracket
A
Fig. 8 CE302 models
Fig. 10 CE604 models rear side Fig. 11 CE302 models front and rear side
CE604 models front side
F
FF
Fig. 9 CE604 models
FRONT
F
F
R
R
B
