Electro-Voice Cobalt Co9 Manuale utente

COBALT

™

WIRED

MICROPHONES

General Product Description

The Co9 is a favorite among vocalists across all musical genres.

Regardless of the live performance application, sound

technicians and engineers feel confident with this mic.

A slight bass roll-off and accentuated midrange make this

a superb, world-class sound transducer.

Microphone Use and Placement

Please note that miking techniques are a matter of personal

preference. These are merely guidelines to assist in the

placement of the microphone to gain optimal performance.

Usage Optimal Placement

Vocals Zero to six inches from the windscreen,

and on axis with the microphone.

Spoken Word Five to ten inches from the windscreen,

and on axis with microphone

Standard Placement & Use Guidelines

1. Always point the microphone at the desired source of

sound, and away from any unwanted sources.

2.The microphone should be located close to the sound

source to minimize interference from other potential

sound sources.

3. se the 3-to-1 rule when using multiple microphones.

Place each microphone three times farther from other

microphones as from the desired sound source.

4. Minimize over-handling of the microphone to reduce

unwanted mechanical noise.

5.Working close to the microphone will increase the bass

tone and also provide increased gain-before-feedback.

Cobalt™Co9

Premium Vocal Microphone

Cobalt™Co9

Premium Vocal Microphone

Specifications

Element Dynamic

Neodymium magnet structure

Frequency Response 50 Hz to 18 kHz

Polar Pattern Cardioid

Impedance Low-Z balanced (600 Ohms)

Sensitivity

Open Circuit Voltage 3.2 mV/PA (-50 dBV) re 1 Pa*

1 Pa = 94 dB SPL

Microphone Connector 3-pin, XLR-type

Polarity Pin 2 positive, referenced to pin 3

with positive pressure on diaphragm

Finish Durable polyurethane paint

Materials Die cast zinc housing

Dimensions

Length 6.7 in. (170 mm)

Diameter 2.1 in. (53 mm)

Shank .85 in. (22 mm)

Weight

Net 11.8 oz. (335 grams)

Shipping 29.9 oz. (848 grams)

Accessories included Stand adaptor (black)

Gig bag

12000 Portland Avenue South, Burnsville, MN 55337

Phone:952/884-4051, Fax:952/884-0043

www.electrovoice.com

Part Number 38109-896 Rev. B

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other International locations. For customer orders, contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 736-4212

For warranty repair or service information, contact the Service Repair department at:

800/553-5992 or 402/467-5321

For technical assistance, contact Technical Support at:

800/392-3497 or 952/736-4656

Specifications subject to change without notice.
