Electrolux Create 4 Manuale utente

Create 4 Coﬀee Maker

User Manual

How to use

Regular Function

AROMA Function

To maximize the ﬂavour extraction

and get a stronger coﬀee

Decalcifying: Recommended 1x every 3 months With decalcifying agent

15 min

Decalcifying

Cleaning

While boiling, the jug must not be removed for longer than

30 seconds or the ﬁlter will overﬂow.

Thermal Jar Glass Jar

30s

Never immerse the thermo jug in liquid or wash it in dishwasher.*

It can only be washed under running water

Max

x10 Max

x12

”glass jar” just to make sure

consumer can diﬀerentiate

Warning!

Thank you for choosing an Electrolux product. In order to ensure the best

results, always use original Electrolux accessories and spare parts.

They have been designed especially for your product. This product is

designed with the environment in mind. All plastic parts are marked for

recycling purposes.

Visit our website to:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories and Consumables for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate.

Model, PNC, Serial Number.

Warning / Caution-Safety information

General information and tips

Environmental information

COMPONENTS

*depending on model

ON/OFF switch with power indicator light

Water tank

Water level indicator

Hinged lid

Filter holder with anti-drip valve

Glass coﬀee jug*

Warming plate*

Power cord & plug

Aroma button

Measuring spoon

Stainless steel thermo jug*

GETTING STARTED

Place the machine on a ﬂat surface. When starting the machine for the

ﬁrst time, ﬁll the tank with cold water. Start the machine with the ON/OFF

switch. Let a full tank of water pass through the machine once or twice to

clean it, without using paper ﬁlter or coﬀee.

Making coﬀee: open the lid and ﬁll the water tank with fresh cold water up

to the desired level. There is a water-level indicator for 2–10 big cups /

3–15 small cups inside the water tank.

Insert paper ﬁlter into ﬁlter basket and ﬁll it with ground coﬀee. There is

a gauge for recommended number of spoons of coﬀee next to the water

gauge. For medium-strength coﬀee, one measuring spoon (approx. 6-7 g)

per cup is suﬃcient. Close the water tank lid and place the jug (complete

with lid) onto the warming plate.

Start the machine with the ON/OFF switch. The power indicator light will

come on and hot water will ﬂow into the ﬁlter. When water has stopped

ﬂowing, the warming plate keeps the coﬀee hot until the machine is

turned oﬀ with the ON/OFF switch. If the machine is not turned oﬀ manually,

the Safety Auto-Oﬀ function turns it oﬀ after 40 minutes.

If the jug is removed, the ﬁlter valve prevents coﬀee from dripping onto

the warming plate. While boiling, the jug must not be removed for longer

than 30 seconds or the ﬁlter will overﬂow.

The Aroma Selector extends the brewing time to maximize the ﬂavour

extraction and get a stronger coﬀee for a small number of cups (normally

less than 6). Press the Aroma button, and the aroma icon will turn on.

SAFETY ADVICE

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without

supervision.

The appliance may only be connected to a power supply whose voltage

and frequency comply with the speciﬁcations on the rating plate! Never use

or pick up the appliance if – the supply cord is damaged, – the housing is

CLEANING AND CARE

Switch the machine oﬀ and unplug the power cord. Wipe all outer surfaces

with a damp cloth.

Coﬀee jug (F) and jug lid are dishwasher proof. Never use caustic or

abrasive cleaners, and never immerse the machine in liquid!

To clean the ﬁlter holder (E), lift up the handle and remove the ﬁlter holder.

To clean the ﬁlter valve thoroughly, rotate it several times while it is being

rinsed.

Decalcifying is recommended regularly, depending on water hardness.

Fill the tank with water and decalciﬁer according to product instructions,

then follow steps 9 and 10.

Place the coﬀee jug (F) with its lid onto the warming plate (G). Allow the

decalciﬁer to take eﬀect for about 15 minutes, then switch the machine on.

Switch it oﬀ when the solution has ﬁnished ﬂowing through. If necessary

repeat the decalcifying process.

Allow the machine to run at least twice with plain water. Then thoroughly

rinse the coﬀee jug (F), jug lid and ﬁlter holder (E) under running water,

activate the ﬁlter valve repeatedly during the rinse process.

damaged. The appliance must only be connected to an earthed socket.

If necessary an extension cable suitable for 10 A can be used. If the

appliance or the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed person, in order to

avoid hazard.

Always place the appliance on a ﬂat, level surface.

Never leave the appliance unattended while connected to the supply mains.

The appliance must be switched oﬀ and the mains plug withdrawn each time

after use, before cleaning and maintenance.

The appliance and accessories become hot during operation. Use only

designated handles and knobs. Allow to cool down before or storage.

The mains cable must not come into contact with any hot parts of the

appliance.

Do not immerse the appliance in water or any other liquid. Do not exceed

the maximum ﬁlling volume as indicated on the appliances. Do not use or

place the appliance on a hot surface or near source of heat.

This appliance is intended to be used in household and similar applications

such as:

– staﬀ kitchen areas in shops, oﬃces and other working environments;

– farm houses;

– by clients in hotels, motels and other residential type environments;

– bed and breakfast type environments.

The coﬀee maker shall not be placed in a cabinet when in use.

No action is needed to adapt the product to 50 or 60Hz.

The product will adjust itself.

Recycle the materials with the symbol. Put the packaging in applicable

containers to recycle it. Help protect the environment and human health

and to recycle waste of electrical and electronic appliances.

DISPOSAL

This symbol on the product indicates that this product contains

a battery which shall not be disposed with normal household waste.

This symbol on the product or on its packaging indicates that the

product may not be treated as household waste. To recycle your

product, please take it to an oﬃcial collection point or to an

Electrolux service center that can remove and recycle the battery

and electric parts in a safe and professional way. Follow your

country’s rules for the separate collection of electrical products and

rechargeable batteries.

Electrolux reserves the right to change products, information and

speciﬁcations without notice.

Symptoms Possible causes

The power supply is not

connected or the ON/OFF

switch is not turned on.

No water in the water tank.

Too much lime scale is formed

in the water tank.

The anti-drip valve in ﬁlter

holder is obstructed by

residual coﬀee powder.

No paper coﬀee ﬁlter in the

ﬁlter holder.

Connect the power plug into

an earthed wall socket and

turn on the ON/OFF switch.

Fill the water tank with cold

water.

Perform the decalcifying

procedure.

Remove the obstructing

particles and clean the

anti-drip valve.

Always use a new paper

coﬀee ﬁlter in the ﬁlter holder

when brewing coﬀee.

Coﬀee is not

brewing.

Filter holder is

leaking.

Coﬀee powder

found in the

coﬀee jug.

Solution

TROUBLESHOOTING
