Electrolux Prostore
650 liter digital waterproof freezers
The Electrolux Prostore range is produced for the customer who needs refrigeration products suitable for
gastronorm containers. The product range is comprised of 650 liter models with full or half door in AISI 304 or
stainless steel. All the internal finishes are in stainless steel. The Prostore models detailed on this sheet are
freezers with remote or built in refrigeration unit.
691186
MATERIALS
• Internal and external in stainless
steel AISI 304 (galvanized back
exterior).
• Runners and supports in
stainless steel easily disassembled
(without any tool) for more
convenient cleaning.
EASY TO INSTALL
• All models require only 1 phase
220/240V supply. They can
therefore be plugged straight into
an existing power socket.
EASY TO USE
• Automatic evaporation of the
defrosting water by hot gas on the
top.
• Designed to operate at ambient
temperatures up to +43°C .
• Hidden evaporator thus
guaranteeing higher storage
capacity and less corrosion
problems.
• Simple control panel: on/off
switch, digital thermometer with
increasing and reduction button,
control lamps and light switch.
• Self closing and reversible
left/right doors (not for glass door).
• Door microswitch to stop the fan
once the door is opened.
• Light as standard in all models.
EASY TO MAINTAIN
• Insulation thickness: 60 mm to
ensure effective insulation with
minimum energy consumption.
• Door handle entirely in pressed
stainless steel (without plastic)
without joints gathering dust and
dirt.
• Joints between side and bottom
inner panels less than 0.5 mm
(according to hygienic rules) in
order to avoid the deposit of dirty
residual that are origin of bacterial
proliferation.
• Inner cell with rounded corners,
bottom pressed in only one piece.
• Easy access to the main
components for an easy
maintenance.
• Full frontal and sides waterproof
design: possible to clean with
hose.
Electrolux Prostore
650 liter digital waterproof freezers
Internet: http://www.electrolux.com/foodservice
HAHC0202011-07-13Subject to change without notice
S/S GRID GN 2/1 FOR PROSTORE 880160 880160 880160
PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457 881457
PLASTIC-COATED GRID GN 2/1 880306 880306 880306
PEDAL OPENING FOR REFRIGERATORS/FREEZERS 880172 880172 880172
PAIR OF RUNNERS FOR PROSTORE REFR. 880558 880558 880558
KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205 880205 880205
GRID FOR WINE BOTTLES PROSTORE 650/1400 880167 880167 880167
ACCESSORIES
PLASTIC-COATED GRID GN 2/1 5 5 5
PEDAL OPENING FOR REFRIGERATORS/FREEZERS 1 1 1
INCLUDED ACCESSORIES
Net weight - kg. 130 120 130
installed-electric 0.69 0.8 0.69
Power - kW
at evaporation temperature - °C -26 -26 -26
Refrigerant power
Refrigeration power - W 780 975 780
Refrigerant quantity - g. 270 270
Refrigerant type R404a R404a R404a
N° defrost in 24 hrs. 4/30' max 4/30' 4/20'
Compressor power - HP 1/2 1/2
N° and type of grids (included) 5, GN 2/1 5, GN 2/1 5, GN 2/1
Door hinges Right Side Right Side 2 Right
N° and type of door 1 1 2x1/2
height 2112 2112 2112
depth/with open doors 665, 1500 665, 1500 665, 1500
width 900 900 900
External dimensions - mm
Control type Digital Digital Digital
Cooling unit Built-In Remote Built-In
Gross capacity (D.I.N. 8952) - l. 700 700 700
panels 304 AISI 304 AISI 304 AISI
External material
Operating mode Ventilated Ventilated Ventilated
Operating temperature - min/max °C -22/-15 -22/-15 -22/-15
TECHNICAL DATA
PS06F1F
691186
PS06F1FR
691187
PS06F2F
691188
EASY ON THE ENVIRONMENT
• CFC and HCFC free
environmentally friendly: R404a
gas in refrigeration circuit. Gas in
foam: Cyclopentane.
• Low noise level - less than 57 dB
(A).
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
• All models comply with the
standards required by the main
international approval bodies and
are H marked.
Electrolux Prostore
650 liter digital waterproof freezers
Internet: http://www.electrolux.com/foodservice
HAHC0202011-07-13Subject to change without notice
EI - Electrical connection 230 V, 1N, 50
LEGEND
PS06F1F
691186
691186
Electrolux Prostore
650 liter digital waterproof freezers
Internet: http://www.electrolux.com/foodservice
HAHC0202011-07-13Subject to change without notice
RI - Remote refrigeration connection ●
EI - Electrical connection 230 V, 1N, 50
ED - Remote electrical connection ●
LEGEND
PS06F1FR
691187
691187
Electrolux Prostore
650 liter digital waterproof freezers
Internet: http://www.electrolux.com/foodservice
HAHC0202011-07-13Subject to change without notice
EI - Electrical connection 230 V, 1N, 50
LEGEND
PS06F2F
691188
691188
