EMS30400OX

................................................ .............................................

EN MICROWAVE OVEN USER MANUAL

CONTENTS

1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

5. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

6. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

7. AUTOMATIC PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8. USING THE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

9. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

10. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

11. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

12. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it

decades of professional experience and innovation. Ingenious and stylish, it has been designed

with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great

results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

2www.electrolux.com

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes in-

juries and damages. Always keep the instructions with

the appliance for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they are supervised by an adult or a per-

son who is responsible for their safety.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep children and pets away from the appliance when

it operates or when it cools down. Accessible parts are

hot.

• If the appliance has a child safety device, we recom-

mend that you activate it.

• Cleaning and user maintenance shall not be made by

children without supervision.

• Keep the appliance and its cord out of reach of chil-

dren less than 8 years.

1.2 General Safety

• This appliance is intended to be used in household and

similar applications such as:

– staff kitchen areas in shops, offices and other work-

ing environments;

– farm houses;

ENGLISH 3

– by clients in hotels, motels and other residential envi-

ronments;

– bed and breakfast type environments.

• Internally the appliance becomes hot when in opera-

tion. Do not touch the heating elements that are in the

appliance. Always use oven gloves to remove or put in

accessories or ovenware.

• Do not use a steam cleaner to clean the appliance.

• Before maintenance cut the power supply.

• If the door or door seals are damaged, the appliance

must not be operated until it has been repaired by a

competent person.

• Only a competent person can carry out any service or

repair operation that involves the removal of a cover

which gives protection against exposure to microwave

energy.

• Do not heat liquids and other foods in sealed contain-

ers. They are liable to explode.

• Only use utensils that are suitable for use in microwave

ovens.

• When heating food in plastic or paper containers, keep

an eye on the appliance due to the possibility of igni-

tion.

• The appliance is intended for heating food and bever-

ages. Drying of food or clothing and heating of warm-

ing pads, slippers, sponges, damp cloth and similar

may lead to risk of injury, ignition or fire.

• If smoke is emitted, switch off or unplug the appliance

and keep the door closed in order to stifle any flames.

• Microwave heating of beverages can result in delayed

eruptive boiling. Care must be taken when handling the

container.

• The contents of feeding bottles and baby food jars shall

be stirred or shaken and the temperature checked be-

fore consumption, in order to avoid burns.

4www.electrolux.com

• Eggs in their shell and whole hard-boiled eggs should

not be heated in the appliance since they may explode,

even after microwave heating has ended.

• The appliance should be cleaned regularly and any

food deposits removed.

• Failure to maintain the appliance in a clean condition

could lead to deterioration of the surface that could ad-

versely affect the life of the appliance and possibly re-

sult in a hazardous situation.

• Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the glass door since they can scratch

the surface, which may result in shattering of the glass.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must in-

stall this appliance.

• Remove all the packaging.

• Do not install or use a damaged appli-

ance.

• Obey the installation instruction sup-

plied with the appliance.

• The appliance can be placed almost

anywhere in the kitchen. Make sure the

oven is placed on a flat, level surface

and that vents as well as the surface

underneath the appliance are not

blocked (for sufficient ventilation).

Electrical connection

WARNING!

Risk of fire and electrical shock.

• All electrical connections should be

made by a qualified electrician.

• The appliance must be earthed.

• Make sure that the electrical information

on the rating plate agrees with the pow-

er supply. If not, contact an electrician.

• If the appliance is connected to the

socket via an extension cord, make

sure the cord is earthed.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Contact the Service or an electrician to

change a damaged mains cable.

• Do not pull the mains cable to discon-

nect the appliance. Always pull the

mains plug.

2.2 Use

WARNING!

Risk of injury, burns or electric

shock or explosion.

• Use this appliance in a household envi-

ronment.

• Do not change the specification of this

appliance.

• Make sure that the ventilation openings

are not blocked.

• Do not let the appliance stay unatten-

ded during operation.

• Do not apply pressure on the open

door.

• Do not use the appliance as a work

surface and do not use the cavity for

storage purposes.

ENGLISH 5

2.3 Care and Cleaning

WARNING!

Risk of injury, fire or damage to

the appliance.

• Before maintenance, deactivate the ap-

pliance and disconnect the mains plug

from the mains socket.

• Clean regularly the appliance to prevent

the deterioration of the surface material.

• Do not allow food spills or cleaner resi-

due to accumulate on door sealing sur-

faces.

• Remaining fat or food in the appliance

can cause fire.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal ob-

jects.

• If you use an oven spray, obey the safe-

ty instructions on the packaging.

2.4 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

3. PRODUCT DESCRIPTION

7 56

1 2 3 4

1Lamp

2Safety interlock system

3Display

4Control panel

5Waveguide cover

6Grill

7Turntable shaft

3.1 Accessories

Turntable set

Glass cooking tray and roller guide.

Always use the turntable set to

prepare food in the appliance.

Grill Rack

For grilling food and combi cooking.

6www.electrolux.com

4. BEFORE FIRST USE

WARNING!

Refer to the Safety chapters.

4.1 Initial Cleaning

• Remove all parts from the appliance.

• Clean the appliance before first use.

Refer to chapter "Care and Clean-

ing".

4.2 Setting the time

When you connect the appliance

to the electrical supply or after a

power cut, the display shows 0:00

and an acoustic signal sounds.

1. Repeatedly press to choose 24

hour or 12 hour clock system.

2. Turn the Setting knob to enter the

amount of hours.

3. Press to confirm.

4. Turn the Setting knob to enter the

amount of minutes.

5. Press to confirm.

ENGLISH 7

5. CONTROL PANEL

Symbol Function Description

Function button To set the microwave / grill / con-

vection function.

Power button To set the power level.

Auto Reheating but-

ton To reheat food automatically.

Defrosting button To defrost food by weight or time.

8www.electrolux.com

Symbol Function Description

—Display Shows the settings and current

time.

Clock button To set the clock.

Stop / Clear button To deactivate the appliance or de-

lete the cooking settings.

Start / +30 sec but-

ton

To start the appliance or increase

the cooking time for 30 seconds at

full power.

The cooking time increases by 30

seconds with each additional press

of the button.

—Setting knob To set the cooking time, weight or

function.

6. DAILY USE

WARNING!

Refer to the Safety chapters.

6.1 Activating and deactivating

the appliance

1. Press the button with the function you

want to activate.

2. Press to choose the power level,

if necessary.

3. Turn the Setting knob to set the de-

sired time.

4. Press to confirm and activate the

appliance.

5. To deactivate the appliance you can:

– wait until the appliance deactivates

automatically when the time comes

to an end.

– open the door. The appliance stops

automatically. Close the door to

continue cooking. Use this option

to inspect the food.

–press .

CAUTION!

Do not let the appliance operate

when there is no food in it.

6.2 General information about

using the appliance

General:

• After you deactivate the appliance, let

the food stand for some minutes.

• Remove the aluminium foil packaging,

metal containers, etc. before you pre-

pare the food.

Cooking:

• If possible, cook food covered with ma-

terial suitable for use in the microwave.

Only cook food without a cover if you

want to keep it crusty

• Do not overcook the dishes by setting

the power and time too high. The food

can dry out, burn or catch fire in some

places.

• Do not use the appliance to cook eggs

or snails in their shells, because they

can explode. With fried eggs, pierce the

yolks first.

• Prick food with "skin" or "peel", such as

potatoes, tomatoes, sausages, with a

fork several times before cooking so

that the food does not explode.

• For chilled or frozen food, set a longer

cooking time.

ENGLISH 9

• Dishes which contain sauce must be

stirred from time to time.

• Vegetables that have a firm structure,

such as carrots, peas or cauliflower,

must be cooked in water.

• Turn larger pieces after half of the cook-

ing time.

• If possible, cut vegetables into similar-

sized pieces.

• Use flat, wide dishes.

• Do not use cookware made of porce-

lain, ceramic or earthenware with small

holes, e. g. on handles or unglazed bot-

toms. Moisture going into the holes can

cause the cookware to crack when it is

heated.

• The glass cooking tray is a work space

for heating food or liquids. It is necessa-

ry for the operation of the microwave.

Defrosting meat, poultry, fish:

• Put the frozen, unwrapped food on a

small upturned plate with a container

below it so that the defrosting liquid

collects in the container.

• Turn the food after half of the defrosting

time. If possible, divide and then re-

move the pieces that started to defrost.

Defrosting butter, portions of gateau,

quark:

• Do not fully defrost the food in the ap-

pliance, but let it defrost at room tem-

perature. This gives a more even result.

Fully remove all metal or aluminium

packaging before defrosting.

Defrosting fruit, vegetables:

• Do not fully defrost fruit and vegetables,

which are to be further prepared while

raw, in the appliance. Let them defrost

at room temperature.

• You can use a higher microwave power

to cook fruit and vegetables without de-

frosting them first.

Ready meals:

• You can prepare ready meals in the ap-

pliance only if their packaging is suitable

for microwave use.

• You must follow the manufacturer's in-

structions printed on the packaging

(e.g. remove the metal cover and pierce

the plastic film).

Suitable cookware and materials

Cookware / Material Microwave Grill-

ing /

Con-

vection

Defrost-

ing

Heat-

ing

Cook-

ing

Ovenproof glass and porcelain (with

no metal components, e. g. Pyrex,

heat-proof glass)

X X X X

Non-ovenproof glass and porcelain

X-- -- --

Glass and glass ceramic made of

ovenproof / frost-proof material (e.

g. Arcoflam), grill shelf

X X X X

Ceramic

, earthenware

X X X --

Heat-resistant plastic up to 200 °C

X X X --

Cardboard, paper X-- -- --

Clingfilm X-- -- --

10 www.electrolux.com

Altri manuali per EMS30400OX

Indice

Altri manuali Electrolux Forno a microonde

Electrolux

Electrolux EMS20107OX Manuale utente

Electrolux

Electrolux EMS17006OX Manuale utente

Electrolux

Electrolux EMS3067X Manuale utente

Electrolux

Electrolux EVY7600AA Manuale utente

Electrolux

Electrolux EVY7800AA Manuale utente

Electrolux

Electrolux EMS26004O Manuale utente

Electrolux

Electrolux EMS17216X Manuale utente

Electrolux

Electrolux COM700CX Manuale utente

Electrolux

Electrolux EMSB30XCF Manuale di istruzioni

Electrolux

Electrolux EMM21000 Manuale utente

Electrolux

Electrolux EMM25D22BM Manuale di istruzioni

Electrolux

Electrolux EME31005X Manuale utente

Electrolux

Electrolux EMS3288X Manuale utente

Electrolux

Electrolux GLMV169DQD Manuale utente

Electrolux

Electrolux FRIGIDAIRE GMBS3068AF Manuale del proprietario

Electrolux

Electrolux EI24MO45IB - 2.0 cu. Ft. Microwave Istruzioni per l'installazione

Electrolux

Electrolux EI30BM6CPS Manuale utente

Electrolux

Electrolux In General Manuale utente

Electrolux

Electrolux EMS21400 Manuale utente

Electrolux

Electrolux EMS17005O Manuale utente

Electrolux

Electrolux CMS4253EM Manuale utente

Electrolux

Electrolux EMZ725MMK Manuale utente

Electrolux

Electrolux FGMO205KFA Manuale utente

Electrolux

Electrolux EME 2661 Guida rapida

Manuali Forno a microonde popolari di altre marche

Daewoo

Daewoo KOG-574R0S Manuale utente

LG MH7040SS Manuale utente

Sharp

Sharp R-895(AL)M Manuale utente

Dometic

Dometic DOTRM13W Manuale utente

Sanyo

Sanyo EM-X680 Manuale utente

Sharp

Sharp R-393M Manuale utente

KitchenAid

KitchenAid KMCX4510 Istruzioni per l'installazione

Smeg

Smeg S45MCX1 Manuale utente

Russell Hobbs

Russell Hobbs RHM2044 Manuale utente

Sunbeam

Sunbeam SMW759 Manuale utente

Gallet

Gallet FMOE230S Manuale utente

Bosch

Bosch CEG732X.1B Manuale utente

Dometic

Dometic Roadmate 230 Manuale utente

Samsung

Samsung SJ0396W Manuale utente

Sanyo

Sanyo EM-P494WS Manuale utente

Sharp

Sharp R-240 Manuale utente

Daewoo

Daewoo KOC-984T2S13 Manuale utente

Impecca

Impecca CM07M2 Manuale utente
