Electrolux Dito 603289 Manuale utente

Item

Model

ProjectName

Turbo Liquidisers

603291

TBX130

The turbo liquidisers are used to

mix, liquidise, reduce and emulsify

vegetable and fish soups, fruit and

vegetable purées, liquid pastries

and sauces. These preparations

can be carried out directly in the

cooking containers or in suitable

liquid containers. The turbo

liquidisers are designed to

withstand intensive use in large

catering, central kitchens and the

food preparation industries.

Stainless steel is used to withstand

the humid atmosphere of the

various production environments.

FEATURES

V All the models are ideal for liquidising

vegetables and meats, producing liquid

and semi-liquid recipes, thick mixtures

(purées, brandades, sorbets), special

preparations in the production of

cosmetics or pharmaceutical products

and rendering sauces consistent.

V Built entirely in stainless steel.

V All models are mounted onto a

stainless steel trolley with castors.

V All models have a turbine that gives

an accelerated flow of the liquid over

the impeller giving greater throughput

and finer grinding.

V Height adjustable on installing.

V All models can be adapted to all

shapes of recipients: cylindrical,

rectangular, hemispherical.

V Safety device in non-working position

and protective ring for the grinding head.

Specifications

MODEL

TBX130F1V

603289

TBX130FP1V

603291

TBX130F2V

603292

TBX130F2V2

603294

TBX130FP2V

603293

External dimensions - mm

width 689 689 689 689 689

depth 1600 1600 1600 1600 1600

height 1278 1278 1278 1278 1278

Electrical power - kW 1.5 1.5 2.2 2.2 2.2

Net weight - kg. 90 90 90 90 90

Supply voltage 230/400 V, 3,

230/400 V, 3,

400 V, 3, 50 230 V, 3, 50 400 V, 3, 50

Included accessories

CODE DESCRIPTION

TBX130F1V

603289

TBX130FP1V

603291

TBX130F2V

603292

TBX130F2V2

603294

TBX130FP2V

603293

653485 S/S TUBE FOR PUREES FOR TURBO

LIQUIDISER

1 1

653484 S/S TUBE FOR SOUPS FOR TURBO

LIQUIDISER

1 1 1

Optional accessories

CODE DESCRIPTION

TBX130F1V

603289

TBX130FP1V

603291

TBX130F2V

603292

TBX130F2V2

603294

TBX130FP2V

603293

653520 BRAISING PAN KIT EJECTOR F.TURBO

LIQUID. ✓ ✓ ✓ ✓ ✓

653521 BRAISING PAN KIT FOR TURBO

LIQUIDISERS ✓ ✓ ✓ ✓ ✓

653507 FISH SOUP GRID FOR TURBO

LIQUIDISERS ✓ ✓ ✓ ✓ ✓

653502 PUREE KIT FOR TURBO LIQUIDISERS ✓ ✓ ✓ ✓ ✓

653485 S/S TUBE FOR PUREES FOR TURBO

LIQUIDISER ✓ ✓ ✓ ✓ ✓

653484 S/S TUBE FOR SOUPS FOR TURBO

LIQUIDISER ✓ ✓ ✓ ✓ ✓

V Very easy to clean: the mixer tube can

be removed without any tool and can be

dismantled in separate parts: tube, shaft,

bearing and rotor.

V Codes 603289 and 603291 are one

speed and codes 603292, 603293 and

603294 are two speed.

V Touch control panel allows the entire

machine to be cleaned with a jet of water

(IP66 water protection).

Installation drawings

XXX

I - Electrical connection 230/400 V, 3,

230/400 V, 3,

400 V, 3, 50 230 V, 3, 50 400 V, 3, 50

MODEL

TBX130F1V

603289

TBX130FP1V

603291

TBX130F2V

603292

TBX130F2V2

603294

TBX130FP2V

603293

603289, 603293, 603294, 603292, 603291

640

1135/1275

420/560

1606

1910/2050

1544/1684

840

ACBC010

www.dito-electrolux.com

Turbo Liquidisers

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.
