Electrolux E48DF76EPS - 48" Pro-Style Dual-Fuel Range Manuale utente

Installation Instructions

Dual Fuel Ranges

5995447082

E30DF74EPS E36DF76EPS E48DF76EPS

2Safety

IMPORTANT SAFETY INSTRUCTIONS

Safety Precautions

Do not attempt to install or operate your unit until you have read the safety

precautions in this manual. Safety items throughout this manual are labeled with a

Warning or Caution based on the risk type.

Definitions

This is the safety alert symbol. It is used to alert you to potential personal

injury hazards. Obey all safety messages that follow this symbol to avoid possible

injury or death.

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

Indicates installation, operation or maintenance information which is important but

not hazard related.

CACA

CAUTIONUTION

UTIONUTION

UTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result

in minor or moderate injury.

CACA

CAUTIONUTION

UTIONUTION

UTION

CAUTION used without the safety alert symbol indicates a potentially hazardous

situation which, if not avoided, may result in property damage.

WARNINGWARNING

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could

result in death or serious injury.

WARNINGWARNING

WARNING

• Read all instructions before using the appliance.

• Improper installation, adjustment, alteration, service, or maintenance can cause

personal injury or property damage. Refer to these instructions and the

accompanying Use & Care Manual. For assistance or additional information,

consult a qualified installer, service agency, manufacturer (dealer), or the gas

supplier.

• For your safety:

- Do not store or use gasoline or other flammable vapors and liquids in the

vicinity of this or any other appliance.

- Do not obstruct the flow of combustion and ventilation air to the unit.

- Keep appliance area clear and free from combustible material, gasoline and

other flammable vapors and liquids.

- Do not use or attempt to use this appliance in the event of a power failure.

• This unit is designed as a cooking appliance. Never use it for warming or heating

a room.

• This appliance must not be used in combination with surface (countertop)

ventilation systems. The use of an overhead hood or downdraft is recommended

for ventilation.

• This appliance must be installed with the gas pressure regulator supplied with it.

• Disconnect the electrical supply before installing or servicing the appliance.

• This appliance must be grounded. Connect only to a properly grounded

electrical supply. Refer to “Electrical Requirements”.

• Install or locate this appliance only in accordance with these installation

instructions.

• Use this appliance only for its intended use as described in this manual. Do not

use corrosive chemicals or vapors in this appliance. This type of appliance is not

designed for industrial or laboratory use.

• As with any appliance, close supervision is necessary when used by children.

• Do not operate this appliance if it has a damaged electrical cord, plug, conduit or

wires, if it is not working properly, or if it has been damaged or dropped.

• This appliance should be serviced only by qualified service personnel.

• Some products, such as whole eggs, and sealed containers, such as closed glass

jars, may explode and should not be heated on this cooktop.

Safety

SAFETY PRECAUTIONS

4Safety

WARNINGWARNING

WARNING

• Based on safety considerations, the top burner flame should be adjusted so it

does not extend beyond the edge of the cooking utensil.

• If the information in this manual is not followed exactly, a fire or explosion

may result causing property damage, personal injury, or death.

• What to do if you smell gas:

- Do not try to light any appliance.

- Do not touch any electrical switch, do not use any phone in your building.

- Immediately call the gas supplier from a neighbor’s phone.

- Follow the gas supplier’s instructions.

- If you cannot reach your gas supplier, call thefire department.

• Installation of this appliance must be performed by a qualified installer, service

agency or the gas supplier.

FindingInformation

READ AND SAVE THESE INSTRUCTIONS

Read all instructions before installing the Range.

For your safety, please read and observe all safety instructions. This guide will help

you anticipate all installation connections.

QUESTIONS?

For toll-free telephone support in the U.S. and Canada:

1-877- 4ELECTROLUX (1-877-435-3287)

For online support and Internet product information:

www.electroluxusa.com

Post Office Box 212378,Augusta, Georgia 30917, USA

Attach your sales

receipt to this

page for future

reference.

NONO

NOTETE

TETE

Installer: Leave instructions with owner.

Owner: Read your Range Use & Care Manual. It contains important safety information

for operating this appliance. It also has many suggestions for getting the best results

from your Range.

6FindingInformation

TABLE OF CONTENTS

Safety ................................................................... 2

Definitions.......................................................... 2

ImportantSafetyInstructions .............................. 2

SafetyPrecautions............................................. 3

Finding Information ........................................... 5

PleaseReadAndSaveThisGuide ................... 5

Questions? ........................................................ 5

TableOfContents .............................................. 6

Preparing for Installation .................................. 7

VerifyingPackageContents ............................... 7

GasSupplyRequirements ................................. 7

GasandElectricRequirementsTable ................ 7

ElectricalPowerSupplyRequirements .............. 8

GasandElectricalRough-In.............................. 9

Cabinet/CounteropPreparation....................... 10

OveralDimensions .......................................... 12

InstallingtheAnti-TipBracket ........................... 13

GasRegulatorandElectrical

ConduitLocation.............................................. 16

Installation ........................................................ 17

InstallingtheRangeBackguards ..................... 17

RemovingtheDoor(s)..................................... 18

ReinstallingtheDoor(s) ................................... 18

MakingtheElectricalConnection ..................... 19

MakingtheGasConnection............................. 22

InstallingtheRange ......................................... 23

InstallingtheBurnerComponents .................... 23

Operation........................................................... 24

VerifyingtheOperation .................................... 24

PreparingforInstallation

VERIFY PACKAGE CONTENTS

• Use & Care Manual • Burner Rings

• Broiler Pan/Insert • Wok Ring

• Anti-tip Bracket • Simmerplate

• Grate Pack • Stainless Steel Cleaner

• Griddle • Roasting Rack

• LP Conversion Kit • Burner Cap Pack

GAS SUPPLY REQUIREMENTS

Check your local building codes for the proper method of installation. In the

absence of local codes, this appliance should be installed in accordance with the

National Fuel Gas CodeANSI Z223.1. Be certain that the appliance being installed

is correct for the gas service being provided. Refer to the rating label located on the

kick panel and/or the table below for gas supply requirements.

GAS AND ELECTRIC REQUIREMENTS TABLE

Refer to the following table for more information on gas and electric requirements.

Model No. Electrical

circuit

required

Total

connected

load

Gas type Manifold

pressure Minimum gas

supply

pressure

E30DF74EPS 240-4

Wire VAC,

60Hz, 30A

26.4 Amps

(6.3 Kw)

Natural

4” Water Column

5” Water Column

E48DF76EPS

E36DF76EPS 240-4

Wire VAC,

60Hz, 30A

240-4

Wire VAC,

60Hz, 50A

26.4 Amps

(6.3 Kw)

44.2 Amps

(10.4 Kw)

Liquid Propane 10” Water Column 11” Water Column

NONO

NOTETE

TETE

This range is shipped from the factory pre-set for use with natural gas. For LP

conversion see the accompanying LP Conversion Kit. The electrical information in the

table is also located on the serial number label on the range. It can be found by

opening the oven door and looking through the inlet air cooling grill.

8PreparingforInstallation

ELECTRICAL POWER SUPPLY REQUIREMENTS

It is the owner’s responsibility to ensure that the electrical connection of this

appliance is performed by a qualified electrician. The electrical installation,

including minimum supply wire size and grounding, must be in accordance with the

National Electric codeANSI/NFPA70- 1993* (or latest revision) and local codes and

ordinances.

*A copy of this standard may be obtained from:

National Fire ProtectionAssociation

1 Batterymarch Park

Quincy, Massachusetts 02269-9101

The correct voltage, frequency, and amperage must be supplied to the appliance

from a separate, grounded, circuit that is protected by a properly sized circuit

breaker or time delay fuse.

Refer to the Gas and Electrical Requirements Table on page 7.

WARNINGWARNING

WARNING

If the gas or electric service provided does not meet the product specifications, do not

proceed with the installation. Call the selling dealer, the gas supplier, or a licensed

electrician.

NONO

NOTESTES

TESTES

TES

The power supply must be properly polarized. Reverse polarity will result in

continuous sparking of the electrodes, even after flame ignition.

If there is any doubt as to whether the power supply is properly polarized or grounded,

have it checked by a qualified electrician.

PreparingforInstallation

GAS AND ELECTRICAL ROUGH-IN

Locations

A manual shut valve must be installed in the gas piping, external to the appliance,

for the purpose of turning on or shutting off gas to the appliance. Plan the location

of the range and the gas supply to allow access to the valve when the unit is

installed.Access to the remote circuit breaker panel/fuse box, with the range in

place, must also be allowed for in the installation.Any openings in the wall behind

the appliance and in the floor under the appliance must be sealed.

Both the gas supply piping and shut-off valve, and the electrical junction box/

receptacle must be located so they do not interfere with the range when it is

installed. In addition, the junction box must be located so the range can be removed

for service when the conduit supplied with the unit is attached to the junction box.

Do not lengthen the conduit or wiring provided with the range.

All dimensions shown are based on standard American cabinets 36 inches

(914mm) high at the finished countertop by 24 inches (610mm) deep, with a 25

inch (635mm) overall countertop depth. When installing the range into nonstandard

cabinets, minimum clearances shown in the diagrams on page 11 must be

maintained.

Carefully check the location where the range is to be installed. For best

performance, the range should be placed away from drafts that may be caused by

doors, windows and HVAC outlets.

NONO

NOTETE

TETE

The shaded areas shown in the illustrations, denote the location of the gas stub and the

electrical junction box/receptacle. These are suggested locations. For replacement

purposes, the location of the existing utilities may be utilized provided that they do not

interfere with the sides or rear of the range. If installing the gas valve behind the range,

verify that local building codes will permit this.

10 PreparingforInstallation

CABINET AND COUNTERTOP PREPARATION

NONO

NOTESTES

TESTES

TES

• If cabinet storage space is to be provided directly above the range, the risk of

personal injury may be reduced by installing a ventilating hood that projects

horizontally a minimum of 5 inches beyond the face of the cabinets.

• The range may be installed flush to the rear wall. We recommend installing a

non-concombustible material on the rear wall above the range and up to the vent

hood. It is not necessary to install non-combustible materials behind the range

below the countertop height.

• The minimum distance from the sides of the range above the countertop to

combustible side walls must be at least 10 inches.

• The E36DF76EPS and E48DF76EPS ranges are delivered with a 3” backguard from

the factory. 9” and 24” backguards are available as options. The E30DF74EPS

range is delivered with a 6” backguard from the factory. 9” and 12” backguards

are available as options.

• Utilities may be located: In the lower left corner of the adjacent right cabinet.

(Recommended)

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

• Contact your local building department to verify compliance with local code

interpretation.

Altri manuali per E48DF76EPS - 48" Pro-Style Dual-Fuel Range

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Electrolux Allineare

Electrolux

Electrolux EI30GF45QSH Manuale utente

Electrolux

Electrolux Frigidaire Gallery Series Manuale del proprietario

Electrolux

Electrolux ECFD3668AS Manuale utente

Electrolux

Electrolux CEW30EF6GBE Manuale utente

Electrolux

Electrolux EKG941AAOX Guida

Electrolux

Electrolux FPEF3081KF Guida utente

Electrolux

Electrolux Frigidaire Professional Series Manuale del proprietario

Electrolux

Electrolux EKC5044 Manuale utente

Electrolux

Electrolux ICON Professional E48DF76EPS Foglio di istruzioni

Electrolux

Electrolux +7GCGD2C00 Manuale utente

Electrolux

Electrolux EI30GF35JS Manuale di servizio

Electrolux

Electrolux 584126 Manuale utente

Electrolux

Electrolux EW30DF65GWA Manuale utente

Electrolux

Electrolux EW30DF65GS - 30" Dual Fuel Range Guida utente

Electrolux

Electrolux GC1G31A1B Manuale utente

Electrolux

Electrolux E48DF76EPS - 48" Pro-Style Dual-Fuel Range Manuale utente

Electrolux

Electrolux EW30ES6CGS8 Manuale utente

Electrolux

Electrolux Electric Range Coil Surface Elements with or without... Manuale utente

Electrolux

Electrolux ICON E30DF74EPS Manuale utente

Electrolux

Electrolux E36GF76GPS Manuale utente

Electrolux

Electrolux 318201631 Manuale utente

Electrolux

Electrolux Modular Cooking Range Line Manuale utente

Electrolux

Electrolux Wave-Touch CEW30GF6GBA Manuale utente

Electrolux

Electrolux EW30DS75KS Manuale utente

Manuali Allineare popolari di altre marche

Samsung

Samsung FCQ321HTUW Manuale utente

Kenmore

Kenmore 790.45712 Manuale utente

Wolf

Wolf CHR CHSSR Manuale utente

Smeg

Smeg Built-in Microwave Oven Manuale di istruzioni

Zanussi

Zanussi ZCG054G Manuale utente

Whirlpool

Whirlpool 8575985-W Manuale elenco delle parti

Frigidaire

Frigidaire 316000635 Manuale utente

GE JCSS630 Manuale utente

Samsung

Samsung NX58M9960P series Manuale utente

Hotpoint

Hotpoint RB524R Guida all'installazione

Whirlpool

Whirlpool Roper FGP305KW3 Manuale utente

Amana

Amana ART6610 SERIES Manuale utente

Maytag

Maytag MERH770WB Manuale utente

Fulgor Milano

Fulgor Milano SOFIA Manuale utente

Premier

Premier EF-4358GH Manuale utente

Kenmore

Kenmore 790.9010 Series Manuale utente

KitchenAid

KitchenAid KESC300 Manuale utente

Frigidaire

Frigidaire FFEF3012LS Guida utente
