Electrolux EKG9688X Manuale utente
3
INSTALLATION
The work on installation must be carried out by competent and qualified
installers according to the local regulation in force.
Any modifications to the domestic electrical main which maybe necessary for the
installation of the appliance should be carried out only by a qualified technician.
It is dangerous to modify, the characteristics of this appliance.
Avoid installation of the cooker near flammable material ( e.g. curtains, tea
towels, etc. )
If installing the cooker with a cooker hood ensure there is a minimum of 65cmto
the underside of the hood ...see Figure 1
Where supplied you must use the adjustable feet.
The cooker chassis must not sit directly on the floor, a plinth or support surface.
To fit adjustable feet.-
4
1. Place the cooker on a piece of polystyrene packaging or similar exposing the
base for fitting the feet.
2. Fit the 4 feet by screwing them tightly into the base as shown below.
3. Level the cooker by screwing the feet in or out.
To prevent damaging the adjustable feet, ensure the cooker is always lifted by
two people. DO NOT DRAG the cooker. Lift the feet clear of the floor.
Do not lift the cooker by the door handles
The following instructions are meant for a qualified installer, in order that the operations
of installation, regulation, and service are executed according to the existing regulations.
Whenever changes are made involving the disconnection of the machine it is necessary to
proceed with maximum caution.
WARNING –The anti-tip chain must be installed and fixed securely to a wall
behind the cooker to prevent accidental tipping of the cooker. ( See Page 6)
THE MANUFACTURING COMPANY DECLINES ANY RESPONSIBILITY FOR
POSSIBLE DAMAGES RESULTING FROM AN INSTALLATION WHICH
DOESN'T COMPLY WITH THE RULES IN FORCE.
Correct Incorrect
5
INSTALLATION ENVIRONMENT
WARNING - This unit can be installed and can work only in constantly
ventilated rooms, according to the national rules in force.
In order for the gas cooker to work properly, it is necessary that sufficient air for gas
combustion can flow naturally into the room.
The air flow into the room must come directly through openings of external walls.
These openings must have a free passage of at least 100cm²(one or more openings can be
made).
These openings (or opening) should be realized in such a way not to be obstructed both
from inside and outside and preferably positioned near the floor, opposite the combustion
products discharge. In case these systems can't be realized in the room where the unit is
installed, the necessary air can come from a room nearby, provided that this room is not a
bedroom or a dangerous environment and it is ventilated as requested, from national rule
in force.
Combustion Products Discharge
Gas cooking units must discharge combustion products through hoods directly connected
to flues or outside. In case the hood can't be installed, it is recommended to use an electric
fan applied to the external wall or to the window of the room, with condition that
openings to let air flow in the room are realized.
This electric fan must be powerful enough to ensure in a kitchen an air replacement of 3 to
5 times its volume per hour.
WARNING - If the oven touches the side of other pieces of the kitchen
furniture, ensure they can withstand a temperature of 75℃.
ELECTRICAL CONNECTION
Before you connect the gas cooker, please check that the voltage indicated on the rating
plate to ensure that it corresponds to the mains power supply available. Appliance must be
connected with mains supply outlet. The ground wires are easily recognized by its green
and yellow colour. Make sure that the "line" and "neutral" wires are installed into their
correct terminals. The installation must be carried out by an authorized electrician only.
Before connecting to the electric supply, make sure that:
6
1. The protection fuse and the domestic wiring are suitable to carry the total electric
load of the cooker.
2. The electricity supply network (mains) has an efficient earth connecting
according to the established rules and existing regulations.
3. The cooker wire is long enough to reach the socket from where your cooker is
situated.
THE MANUFACTURER WILL NOT BE RESPONSIBLE FORANY ACCIDENT
CAUSED BY NON OBSERVANCE OFSAFETY INSTRUCTION.
GAS HOSE CONNECTION
First connect one end of the rubber hose to the gas regulator and tighten it with a hose
clamp. The other end should be pushed tightly into the gas hose connector. Tighten it with
a hose clamp, make sure that both ends are tighten otherwise gas might leak and this could
be dangerous. Make sure all the control knobs are in the "off" position before connecting
the gas supply. Connect the gas regulator to the LPG tank and your units ready for use.
Whenever connecting the hose to the cooker please ensure:
1. The hose does not exceed a length of 1 meter.
2. The hose must not be very tight or twisted and must not show any sharp bends or
kinks. If there is a leak don't repair but replace it.
3. The hose must not touch the back of the cooker.
Upon completing the installation, check and make sure that all pipes and hoses
are connected correctly. Always use soapy water to check gas leaking. For safety
reasons we would advise you to inspect and change the rubber hose for the gas
connection yearly.
WARNING - USE THE CORRECT DOMESTIC GAS REGULATOR.
DO NOT USE AN INDUSTRIAL GAS REGULATOR.
DOMESTIC GAS REGULATOR FOR LPG 30mbar.
CHILD SAFETY
This appliance has been designed for use by adults. Take care, therefore that
children do not attempt to play with it.
7
The appliance will become hot during operation and can remain hot for a long
time after being switched off.
Supervise children and pay attention that they do not touch surfaces or remain in
the vicinity of the appliance when in use or when not completely cooled.
WARNING - Ensure the anti-tip chain is installed correctly to avoid the
possibility of the cooker falling over and injuring children.
The chain must be firmly secured to the wall behind the cooker by fitting a wall plug
and hook to the wall at the same height as chain
USING COOKER FOR THE FIRST TIME
We recommend that before you cook in your new cooker you heat the oven to 180℃for
2hrs to run in your new oven. After the oven cools wipe it out with hot water and a mild
detergent. We also recommend cleaning the racks and shelves before use.
When using the cooker for the first time you may notice the following……
There may be a smell. This is quite normal when the cooker is first heated as
residual oil from production of parts will be burnt off quickly.
There may be noises. This is also quite normal as new parts move and settle into
place during the initial heating process.
