Modular Cooking Range Line

900XP 2-Burner Gas Boiling

Top

ITEM #

MODEL #

NAME #

SIS #

AIA #

Short For Specification

Item No.

APPROVAL:

Electrolux Professional

www.electrolux.com/professional

professional@electrolux.com

Modular Cooking Range Line

900XP 2-Burner Gas Boiling Top

Modular Cooking Range Line

900XP 2-Burner Gas Boiling Top

391000 (E9GCGD2C00)900XP 2 GAS BOILING TOP

6kW - NATURAL/LPG GAS

To be installed on open base installations, bridging supports or cantilever

systems. High efficiency flower flame burners with continuous power

regulation and optimized combustion. Flame failure device as standard on

burners to protect against accidental extinguishing. Exterior panels of unit

in stainless steel with Scotch rite finish. Pan supports in heavy duty cast

iron. Extra strength work top in heavy duty 2 mm stainless steel. Right-

angled side edges to allow flush-fitting junction between units.

Main Features

•Unit to be mounted on open base cupboards,

bridging supports or cantilever systems.

•The two 6 kW high efficiency flower flame burners

are available in two different sizes to suit high

performing cooking requirements of the most

demanding customers:

-60 mm burners with continuous power regulation

from 1,5 to 6 kW.

-100 mm burners with continuous power regulation

from 2.2 kW to 10 kW.

•Gas appliance supplied for use with natural or LPG

gas, conversion jets supplied as standard.

•Large sized pan support in cast iron (stainless steel

as option) with long center fins to allow the use of

the largest down to the smallest pans.

•urners with optimized combustion.

•Flame failure device on each burner protects against

gas leakage when accidental extinguishing of the

flame occurs.

•Protected pilot light.

•The special design of the control knob system

guarantees against water infiltration.

•IPX5 water protection.

Construction

•Unit is 930 mm deep to give a larger working surface

area.

•All exterior panels in Stainless Steel with Scotch

rite finishing.

•AISI 304 stainless steel worktop, 2mm thick.

•Model has right-angled side edges to allow flush

fitting joints between units, eliminating gaps and

possible dirt traps.

Modular Cooking Range Line

900XP 2-Burner Gas Boiling

Top

odular Cooking Range Line

900XP 2-Burner Gas Boiling Top

The company eseves the ight to make modifications to the poducts

without pio notice. All infomation coect at time of pinting.

2014.04.23

Optional Accessories

•Junction sealing kitPNC 206086 ❑

•Draught diverter, 120 mm diameterPNC 206126 ❑

•Matching ring for flue condenser, 120 mm

diameterPNC 206127 ❑

•4 wheels, 2 swivelling with brake

(700/900XP). It is mandatory to install with

base supports for feet/wheels.

PNC 206135 ❑

•Support for bridge type installation,

800mmPNC 206137 ❑

•Support for bridge type installation,

1000mmPNC 206138 ❑

•Support for bridge type installation,

1200mmPNC 206139 ❑

•Support for bridge type installation,

1400mmPNC 206140 ❑

•Support for bridge type installation,

1600mmPNC 206141 ❑

•Support for bridge type installation,

400mmPNC 206154 ❑

•Single burner radiant plate for pan supportPNC 206170 ❑

•Water column with swivel arm (water

column extension not included)PNC 206289 ❑

•Water column extension for 900 linePNC 206290 ❑

•Stainless steel double grid for 2 burnersPNC 206298 ❑

•Chimney upstand, 400mmPNC 206303 ❑

•Flue condenser for 1/2 module, 120 mm

diameterPNC 206310 ❑

•Wok pan support for open burners

(700/900)PNC 206363 ❑

•ase support for feet or wheels - 400mm

(700/900XP)PNC 206366 ❑

•Kit town gas nozzles (G150) for 900 gas

boiling topPNC 206384 ❑

•Side handrail-right/left hand (900XP)PNC 216044 ❑

•Frontal handrail, 400mmPNC 216046 ❑

•Frontal handrail, 800mmPNC 216047 ❑

•Frontal handrail, 1200mmPNC 216049 ❑

•Frontal handrail, 1600mmPNC 216050 ❑

•Large handrail - portioning shelf, 400mmPNC 216185 ❑

•Large handrail - portioning shelf, 800mmPNC 216186 ❑

•2 side covering panels for top appliancesPNC 216278 ❑

•Pressure regulator for gas unitsPNC 927225 ❑

Modular Cooking Range Line

900XP 2-Burner Gas Boiling

Top

odular Cooking Range Line

900XP 2-Burner Gas Boiling Top

The company eseves the ight to make modifications to the poducts

without pio notice. All infomation coect at time of pinting.

2014.04.23

Front

Top

G=Gas connection

Side

Gas

Gas Power:

391000 (E9GGD200)40908 tu/hr (12 kW)

Gas Type Option:LPG;Natural Gas

Gas Inlet:1/2"

Natural gas - Pressure:7" w.c. (17.4 mbar)

LPG Gas Pressure:11" w.c. (27.7 mbar)

Key Inforation:

Front Burners Power:6 - kW

Back Burners Power:6 - 0 kW

Back Burners Dimension - mmØ 60

Front Burners Dimension - mmØ 60

Net weight:43 kg

Shipping weight:45 kg

Shipping height:540 mm

Shipping width:500 mm

Shipping depth:1020 mm

Shipping volume:0.28 m³

If appliance is set up or next to or against temperature sensitive

furniture or similar, a safety gap of approximately 150 mm should be

maintained or some form of heat insulation fitted.
