Electrolux EW27WD55GS Manuale utente

27" WARMER DRAWER

Capacity

Features

Perfect Set™Electronic Controls

Blue LED Display

Automatic Shutoff – 4 hour

Humidity Control

Heating Element (Watts)

Luxury-Glide™Full-Extension Drawer Glides

Element “ON” Blue Indicator Light

Stainless Steel Drawer Interior

Half-Width Rack

Additional Features

Signature Soft-Arc Drawer Front and Handle Design

Specifications

Drawer Interior Dimensions –

Height

Width

Depth

Overall Exterior Dimensions –

Height

Width

Depth (to Front Drawer Corner)

(Fully Extended Including Handle)

Temperature Range

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating) @120 Volts‡

Amps@120 Volts

Minimum Circuit Required (Amps)

60" Electrical Cable

Approved for Under-Counter Installation

Product Weight

Shipping Weight

‡For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate

ground wire. Appliance must be grounded for safe operation.

NOTE: Always consult local and/or national electric codes. Refer to Product Installation Guide

for detailed installation instructions on the web at www.electroluxappliances.com.

Specifications subject to change.

1.3 Cu. Ft.

Yes

450

Yes

6-1/2"

17-15/16"

17-3/4"

11-1/4"

27"

23-3/8"

45"

80°F – 210°F

Right Center Rear

120V/60Hz/15A

0.45

3.75

Included

Yes

55 Lbs.

70 Lbs.

1.3 Cu. Ft. Stainless Steel Interior

Large capacity warmer drawer has 1.3 cubic feet

of usable space to keep an entire meal warm until

serving time. Stainless steel interior cleans up fast

and easily.

Bread Proofing

For best results, the Bread Proofing setting

provides the perfect combination of moisture and

warmth to raise dough evenly without cooking.

Moist or Dry Vent Control

Adjustable humidity controls deliver optimal serving

results by providing the precise amount of humidity

to ensure certain dishes stay moist while others

remain dry.

Half-Width Rack

Drawer features a convenient half-width rack

for small dishes and breads, also providing

loading flexibility to accommodate a variety of

prepared foods.

Warmer Drawer

EW27WD55G S

electroluxappliances.com

Wall OvensWarmer DrawersCooktopsBuilt-In Ranges

Freestanding

Ranges

MicrowavesVent HoodsDishwashersRefrigerators

FreezersUnder Counter

Warmer Drawer

EW27WD55G S

High standards of quality at Electrolux Major Appliances mean we are

constantly working to improve our products. We reserve the right to change

specifications or discontinue models without notice.

USA

•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •

electroluxappliances.com

CANADA

•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •

electroluxappliances.ca

27" Warmer Drawer Specifications

•

Product Weight – 55 Lbs.

•

Voltage Rating –120V/450W/60Hz/15 Amps

•

Connected Load (kW Rating) @120 Volts = 0.45kW

(For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.)

•

Amps @120V = 3.75 Amps

•

Recommended Circuit Breaker – 15 Amps

•

60" electrical cable supplied.

•

Full plywood base required, capable of supporting 100 Lbs.

•

Base must be level and cabinet front must be square.

•

Warmer Drawer can be used alone, or is approved to be used

in combination with any Electrolux Wall Oven. (Refer to Combination

Installation Specifications and drawing on this page.)

Note: For planning purposes only. Refer to Product Installation Guide

on the web at electroluxappliances.com for detailed instructions.

27" Warmer Drawer/27" Wall Oven Combination Specifications

•

To support Wall Oven when using in combination with Warmer Drawer,

two 3"-wide x 3/4" thick planks must be installed as a base, capable of

supporting 150 Lbs. Do NOT use full base, since planks are necessary

to allow for proper air displacement.

Note: For planning purposes only. Refer to Product Installation Guide

on the web at electroluxappliances.com for detailed instructions.

Warmer Drawer Stand-Alone Installation

23 5/8"min.

24"max.

41/2" min.

required

distance

to floor

9 7/8" min.

10 1/4"max.

25 1/2" min.

25 3/4" max.

Full plywood

base required to

support 100 lbs.

Overall depth with drawer fully extended

(includes handle) – 45"

13/4"

23 3/8"

265/8"

27" 111/4"

Power cord

location (right

center rear)

Two 3" wide

x 3/4" thick

planks must be

installed, capable

of supporting

150 lbs.

9 7/8" min.

10 1/4"max.

min.

*Critical dimension –

MUST be applied

**Electrical junction

box for Wall Oven

must be lower than

the Warmer Drawer

cutout

†

Maximum height

depends on critical

dimension (

max.**

Electrical

junction box

location

25 1/2"min.

25 3/4"max. Bottom

of oven

cutout

115/8"

min.*

23 5/8"min.

24"max.

27 1/8"min.

4" x 4"

opening

to route

armoured

cable

27 1/4"

min.

28 5/8"

max.

min.

†

27" Warmer Drawer/27" Single

Wall Oven Combination Installation
