Electrolux EWT1575D2SA Manuale utente

EWT1575D2SA

EN Top Load Washer User Manual

Thank you for choosing afirst class product from Electrolux, which hopefully will provide

you with lots of pleasure in the future. The Electrolux ambition is to offer awide variety

of quality products that make your life more comfortable. You find some examples on

the cover in this manual. Please take afew minutes to study this manual so that you can

take advantage of the benefits of your new machine. We promise that it will provide a

superior User Experience delivering Ease-of-Mind.Good luck!

Welcome to the world of Electrolux

The symbols you will see on some paragraphs of this booklet have the following

meaning:

The warning triangle and/or the key words(Warning!, Caution!) emphasize

information that is particularly important for your safety or correct functioning

of the appliance.

The information marked with this symbol provides additional instructions and

practical tips on the use of the appliance.

Tips and information about economical and ecological use of the machine are

marked with this symbol.

Our contribution to the protection of the environment;

we useenvironmentally friendly paper.

CONTENTS

Safety information

Product description

Control panel

Washing program

Use

Care and cleaning

Helpful hints in dealing with washing problem

Troubleshooting

Installation instruction

Environment concerns

Contact detail: Electrolux customer care

...........................................................................

......................................................................

.......................................................................................

............................................................................

.............................................................................................................

............................................................................

..................................................................

...........

...............................................................................

.................................................................

................................................................

........................

Technical information

SAFETY INFORMATION

In the interest of your safety and to

ensure the correct use,before

installing and first using the

appliance,read this user manual

carefully,including its hints and

warnings.

To avoid unnecessary mistakes

and accidents,it is important to

ensure that all people using the

appliance are thoroughly familiar

with its operation and safety

features.

Save these instructions and make

sure that they remain with the

appliance if it is moved or sold,

so that everyone using it through

its life will be properly informed

on appliance use and safety.

General safety

It is dangerous to alter the

specifications or attempt to modify

this product in any way.

Make sure that small pets do not

climb into the drum.To avoid this,

please check into the drum before

using the appliance.

Any objects such as coins,safety

pins,nails,screws,stones or any

other hard,sharp material can cause

extensive damage and must not be

placed into the machine.

Only use manufacturer’s

recommended quantities of fabric

softener and detergent. Damage to

the fabric or appliance can occur if

you exceed the recommended

amount.

This appliance is not intended for use

by persons (including children)with

reduced physical,sensory or mental

capabilities,or lack of experience and

knowledge,unless they have been

given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

Wash small items such as socks,

laces,washable belts etc in a washing

bag or pillow case as it is possible for

such items to slip down between the

tub and the agitator.

Do not use your washing machine to

wash articles with whale bones,

material without hems or torn material.

Always unplug the appliance and turn

off the water supply after use,clean

and maintenance.

Under no circumstances should you

attempt to repair the machine

yourself.Repairs carried out by

inexperienced persons may cause

injury or serious malfunctioning.

Contact your local Service Center.

Always insist on genuine spare parts.

This appliance is heavy. Care should

be taken when moving it.

When unpacking the appliance,

check that it is not damaged.If in

doubt,do not use it and contact the

Service Center.

If the appliance is installed on a

carpeted floor, please adjust the feet

in order to allow air to circulate freely.

Always be sure, that there is no water

leakage from hoses and their

connectionsafter the installation.

Any plumbing work requiredto install

this appliance should be carried out

by a qualified plumber.

Any electricalwork requiredto install

this appliance should be carried out by

a qualifiedelectrician.

Use

This applianceis designed for

domestic use. It must not be used for

purposes other than those for which it

was designed.

Only wash fabricswhich are designed

to be machine washed. Follow the

instructions on each garment label.

Do not overload the appliance.See the

relevant section in the user manual.

Garmentswhich have beenin contact

with volatile petroleumproducts

should not be machine washed. If

volatile cleaning fluids are used, care

should be taken to ensure that the

fluid is removed from the garment

before placing in the machine.

Never pull the power supply cable to

remove the plug fromthe socket;

always take hold of the plug itself.

Never usethe washing machineif the

power supply cable, the control

panel, the working surface or the

base are damagedso that the inside

of the washing machine is accessible.

Child safety

This washing machine is not intended

for use by young children or infirm

persons without supervision.

Young children should be supervised

to ensure that they do not play with

the appliance.

The packagingcomponents (e.g.plastic

film, polystyrene)can be dangerous to

children - dangerof suffocation! Keep

them out of children'sreach.

Keep all detergents in a safe place out

of children'sreach.

Make sure that children or pets do not

climb into the drum.

SAFETY INFORMATION

After having installed the appliance,

check that it is not standing on the

inlet and drain hose and the worktop

is not pressing the electrical supply

cable.

Before washing, ensure that all

pockets are empty and buttons and

zips are fastened. Avoid washing

frayed or torn articles and treat stains

such as paint, ink, rust, and grass

before washing.

WARNING:

May cause electric shock! if the

machine is not connected to an

earthed/ground system. DO NOT

touch the wet clothes and metal

parts.

Child Lock

412

Control Panel

Cabinet

4Water Inlet Valve

5Lid

6Detergent Box

Agitator

Main Cable with Plug

10 Drain Hose

11 Level Adjustment Feet

12 Water Inlet Hose

Auto Water Level

Your washing machine has selectable

“Auto” sensing water level option as

well as allowing you to choose a manual

water level if you wish. We recommend

you to use the Auto water level option to

ensure there is just the right amount of

water for the wash load in the machine.

This function is only available in Mixed

and Denim program.

Power Failure Recovery

This washing machine has last status

memory and whenever power supply

recovers, press on/off

button,

machine

will continue with the last status before

power supply was cut-off.

PRODUCT DESCRIPTION

Front Right

EWT1575D2SA

This machine is provided with child

safety lock option to prevent children

playing with the control panel.

1Autodose Box

7Lint Filter

Auto Tub Clean

Lock

This function locks the control panel to

prevent disruption. To activate, press

Delay End and Spin buttons simultaneously

for 2 seconds until the child lock`s

indicator lights up after launched. Press

again for 2 seconds to deactivate.

CONTROL PANEL

11 67 8 9 10

Rinse

Spin

AutoDose

This button allows you to manually

select required times of rinsing.

This button allows you to manually

select spin speed.(No Spin,Low,

Medium,High)

This option is to wash laundry and tub

at the same time.

It can be added or canceled by user itself.

Suitable for:Mixed、Denim.

This button allows you to manually select

your required Auto Dose`s level.

This function is invalid when insufficient

detergent is detected in box.

Power On/Off

Press this button to power on/off

your washing machine. The machine

will automatically power off if there is

no selection made within 5 minutes.

Program Selector

Press this button to choose the wash

program you want. The “Your Program

Guide” shown on page 7 will help you

in selecting the right program.

Delay End

You can set your washing machine

to finish your wash at a later time you

specify, choosing a delay of between

1to 24 hours.

Water Level

Choose the water level by pressing

Water Level button. Use only the

amount of water you need for the

wash load.

Options

Press this button to customise your

wash program with Soak or Air dry.

Start/Pause

Press this button to start and pause

washing program.

Delay time

The time displayed under this icon

indicates the time when the program

will end.

Option

Op on

WASHING PROGRAMS

Program Description Option

Cottons

Soak,Air Dry,Soak+Air

Dry,Lock,Delay End,

Water Level

Mixed

Quick 20

Delicates

Bedding

Denim

Rinse+Spin

Spin

Option Description

Soak

Air Dry

Suitable for washing cotton clothes that are

lightly soiled.

Suitable for washing daily clothes that are

lightly soiled and small quantity.

Suitable for washing shirts,casual pants and

other ordinary clothes.

Suitable for washing delicate items such as

silk and underwear.

Suitable for washing bulky items like blanket

or bedding.

Suitable for washing denim clothes.

Program only for rinsing and spinning.

Program only for spinning.

Soak,Air Dry,Soak+Air Dry,Au -

to Tub Clean,Lock,

Delay End,Water Level

Lock,Delay End,Water Level

Soak,Air Dry,Soak+Air

Dry,Lock,Delay End,

Water Level

Soak,Air Dry,Soak+Air

Dry,Lock,Delay End,

Soak,Air Dry,Soak+Air Dry,Au -

to Tub Clean,Lock,

Delay End,Water Level

Lock,Delay End,Water Level

Lock,Delay End

Add soak function to the wash program. This option will extend washing time.

This option will maintain the high speed spinning for a longer period of time

so that more water can be extracted.

AutoDose

Important note before use：

Do not put powder detergent into the autodose box.

Default dosage is based concentrated detergent type.

To select”Normal” detergent type,kindly press 2s on the “Autodose” button.

“ ” will be displayed on screen.Press 2s again ,it will switch to concentrated

detergent “ ”.

For detergent type, please refer to detergent packaging.

Max Load

（kg）

15.0

6.0

15.0

If you want to clean the auto dosing box, please contact your local Service Center.

For liquid detergent only

Sort Your Washing Into

Separate Wash Loads

Each load of washing should contain

clothing which needs the same washing

conditions. For example, you should not

wash delicate clothes with very dirty

work clothes.

Colour fast and non-colourfast fabrics

should be separated. Knowing the type

of fabrics you have and how dirty they

are will help when you make selections

from the wash program options.

Some fabrics are lint collectors and can

pick up lint, dirt and colour from other

fabrics which are lint producers. Some

examples are listed below:

Lint collectors

Corduroy

Synthetics

Permanent press

fabrics

Lint producers

Towels

Nappies

Chenille/

Candlewick

Make sure that you wash lint

collectors separately from lint

producers.

Check your clothes to avoid

damage

Empty all pockets. Close all hooks and

zippers to avoid snagging clothes.

Wash bras, pantyhose and other

delicates in a mesh laundry bag, which

you can purchase from your

supermarket.

Pre-treatment sprays and

stain removers

Pre-treatment sprays and stain

remover can damage plastic

components on your washing

machine.

If you use pre-treatment sprays or stain

removers, apply them to the clothing

well away from your washing machine.

Load the washing machine

USE

Over time you will learn what is the best

set-up of programs, detergent and load

sorting for different load types and soils.

These Washing Instructions are of a

general nature and you should get good

wash results by following them.

However, due tothe variables of fabric

types, soil levels, detergent types and

available program settings you may find

some combinations of these which do

not always result in the perfect wash.

If for example you see residuals of

detergent or soils on some items,

please read the section Residues on

washed items paragraph.

USE

Clothes must be loaded evenly

in the tub.

Clothes must not be wrapped

around in the tub.

The washing machine must not be

overloaded. Clothes must be able to

move around during washing.

Amixed load of large and small items will

wash cleaner than a full load of large

items. For example, sheets should be

small items.

Detergent

Please use detergent designed for top

load or front load washing machines.

It is best to use concentrated detergent.

Do not put too much detergent in

dispenser drawer. This will give you too

many suds causing low spin speeds,

poor rinsing and overloading the motor

during spin stages of the wash program.

Adding the detergent

1.Pull out the dispenser drawer.

2.Put proper detergent into it.

3.Pull back the dispenser drawer.

When using the washing machine for the

first time, check that the dispenser is set

for the type of detergent you will use. To

do this, proceed as follows:

Please add the detergent according to

the product instruction. Please add the

detergent properly if you have changed

the detergent.

Bleaching of clothes can help to

remove stains and heavy soiling.

Oxygen type - This is generally a

powder type bleach. Add bleach in the

left-side box of the drawer. Refer to

the instructions on the bleach container.

Attention:

1 Do not overfill the siphon cap for the

liquid bleach.

2 Liquid detergent and bleach should

not be added to the left-side box

simultaneously in order to avoid

chemical reaction.

Chlorine type - This type of bleach

should NOT be mixed with detergent.

Mix the bleach with water as per the

instructions on the container.

Adding Bleach

Bleach should NOT be used on silk, wool,

rayon or drip dry clothes.

accompanied by

Dose the amount as recommended by the

manufacturer and do not mix bleach with

detergent to avoid chemical reaction.

Do not overfill the siphon cap for the liquid

bleach.

When loading the clothes into your

washing machine, there are four things

to remember:

1.You can add softener, liquid detergent

and powder detergent to the right

dispenser by yourself.

2.Do not activate autodose together add

the liquid degergent,this will give you too

many suds causing low spin speeds,

poor rinsing and overloading the motor

during spin stages of the wash program.

What To Do After You Have

Finished Your Washing.

After washing course is completed••

the water tap must be turned off•

•If required•the water inlet hose

can be removed•

After using the washing

machine•please discharge the

water in the barrel out so as to

keep it dry•

Plug out the power socket for

maintenance•

Hang up power line and drain hose.

Wipe up the droplet and dirt in washing

machine barrel with clean soft cloth.

Leave lid open for a while. This

allows time for moisture inside the

washing machine to evaporate

and for any odours to disperse.

You must DISCONNECT the appliance

from the electricity supply, before you

carry out any cleaning or maintenance

work.

CleaningThe Dispenser

The dispenser needs to be cleaned

regularly, preferably after each wash.

Inspect the dispenser after each wash to

see if there is any residue of detergent.

To do this, proceed as follows:

Pull out the dispenser drawer until it

stops.

Pull out the drawer,press the snap

jiont of liquid detergent dispenser,

and remove it from runners.

Clean the dispenser drawer with hot

water and a brush, eg. an old

toothbrush.

Dry the drawer.

Before replacing the dispenser back

in its recess, clean the inside of the

recess with an old toothbrush.

Put the dispenser back into its

runners and close the drawer.

Cleaning of LintFilter

Following is the concrete operation

method•

1•Press the button andpullout the filter

screen•

CARE AND CLEANING

•

Indice

Altri manuali Electrolux Rondella

Electrolux

Electrolux EIFLW55HIW - 27" Front-Load Washer Manuale utente

Electrolux

Electrolux EFLS210TIS01 Manuale utente

Electrolux

Electrolux EWF 1487 HDW2 Manuale utente

Electrolux

Electrolux EW6F4842AB Manuale utente

Electrolux

Electrolux EWFLW65H - 27'' Front-Load Washer Manuale utente

Electrolux

Electrolux EWF 1000 Manuale utente

Electrolux

Electrolux Zanussi FC 1200W Manuale utente

Electrolux

Electrolux EW8T3372 Manuale utente

Electrolux

Electrolux DV430FHM-NN1 Manuale utente

Electrolux

Electrolux EW7F8669E6 Manuale utente

Electrolux

Electrolux EW 560F Manuale utente

Electrolux

Electrolux ESF4510LOX Manuale utente

Electrolux

Electrolux EWF12935S Manuale utente

Electrolux

Electrolux EW6F428B Manuale utente

Electrolux

Electrolux EWM 1042 NDU Manuale utente

Electrolux

Electrolux EWT 106511 W Manuale utente

Electrolux

Electrolux EWX 147410 W Manuale utente

Electrolux

Electrolux EW 869 F Manuale utente

Electrolux

Electrolux EWG 147540 W Manuale utente

Electrolux

Electrolux EWF8024P5WB Manuale utente

Electrolux

Electrolux EWF80743 Manuale utente

Electrolux

Electrolux WH 810 Manuale utente

Electrolux

Electrolux EWF 14118 Manuale utente

Electrolux

Electrolux EWF12942 Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente

Beko

Beko WKB 51231 PTMA Manuale utente
